Summary of Contents for Winmate EAC PRO-IK90
- Page 1 EAC PRO-IK90 Quick Start Guide V2.0 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 91521117100C Please read these instructions carefully before using this product, and save this manual for future use.
- Page 2 FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including interference that may cause undesired operation.
- Page 3 Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We assume no responsibility or liability...
- Page 4 Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance. You may need the following information ready before you call: ...
-
Page 5: Table Of Contents
CONTENTS INTRODUCTION Features Ordering Information Package Contents Product Overview Front Side I/O Connectors LED Indicators INSTALLATION Hardware Installation Connecting the Power Connecting the Power Power Consumption Reference Backplane Board Jumpers and Connectors Backplane Board Connectors Backplane Board Jumpers GETTING STARTED How to Enable Watchdog Using Recovery Wizard to Restore Computer SPECIFICATIONS... -
Page 7: Introduction
IK90 with 6th Generation Intel® Xeon E3 or Core™ i7/i3 processors and C236 chipset offers high performance computing power and outstanding video processing. Abundant I/O ports and PCI/ PCIe expansion make EAC PRO-IK90 suitable for Factory Automation, Machine Vision, Surveillance, Machine Automation and other high-performance applications. -
Page 8: Package Contents
Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: EAC PRO-IK90 Quick Start Guide Driver CD & User... - Page 9 Your package may include optional accessories based on your order: WLAN External Antenna WWAN External Antenna 39700000000E 39700000000F...
-
Page 10: Product Overview
Product Overview Front Side I/O Connectors LED Indicators EAC PRO-IK90 Embedded Computer provides four SSD/HDD LED indicators and one WWAN/ WLAN LED indicator for status monitoring. LED Indicator Color Description Slot is empty; module is not yet discovered by the system. -
Page 11: Installation
INSTALLATION Hardware Installation SATA HDD Installation (I) SATA HDD Installation (II) 1. Loosen a thumbscrew on the front panel 1. Loosen six screws on the right side cover. by hand. 2. Loosen one screw on the SATA HDD 2. Withdraw thumbscrew and open the slot. - Page 12 PCI/ PCIe Card Installation PCI/ PCIe Card Dimensions, mm IMPORTANT: Before recovery, remove the PCI/ PCIe card. When installing PCIe card, you need to change JP1 jumper settings located on the Backplane Board. DO NOT Connect any external power to PCI/ PCIe card.
-
Page 13: Connecting The Power
Connecting the Power The DC power supply connector of the EAC PRO-IK90 Embedded Computer is on the front panel. The DC power input for the EAC PRO-IK90 allows a voltage input range from 9 V DC to 36 V DC. - Page 14 Connecting to DC Power Connect open wire cable (not supplied by Winmate) to 9-36V DC, maximum power source 220W.
-
Page 15: Power Consumption Reference
Platforms tested for this data have available CFast Card, SATA HDD. No internal PCI/PCIe/ slots are occupied. Information is presented for reference only. Actual power consumption will vary with different attached devices and platform operations. Power consumption EAC PRO-IK90/7 CPU i7-6700TE Power Off Idle mode Full Load Power consumption (W) 32.16... -
Page 16: Backplane Board Jumpers And Connectors
Backplane Board Jumpers and Connectors BP1 Board Top Side (Top View) *PCIE PEG x16 Slot (CN1) depends on SKU1 or SKU2. -
Page 17: Backplane Board Connectors
Backplane Board Connectors Fan Connector (FAN2) Smart fan is connected to FAN2 by default. Sensor chip is located on the BP1 board. Pin № Signal Name +12VS Sense Pin Sensor Chip Behavior: Connector Description FAN1 Always turn on FAN2 Smart fan: when sensor cheap reaches the temperature of 75 degrees, smart fan turns on. -
Page 18: Backplane Board Jumpers
Backplane Board Jumpers Jumper: PCIe x16, PCIe x8 (JP1) When you install PCIe card it is required to change Jumper: PCIe x16, PCIe x8 (JP1) settings. Pin № CN1 (PCIE x16) CN2 (PCIE x8) Jumper ISO_COM (JP7) When you use DI/DO, it is required to change Jumper ISO_COM settings to switch the internal voltage. -
Page 19: Getting Started
GETTING STARTED How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center. Refer to the User Manual for more details. - Page 20 3. In Watchdog utility window set countdown time and periodically feed time, or disable watchdog. Example: Every 10 min watchdog will monitor the system, in case any error occurs the system will restart automatically when the countdown time reaches Every 9 min watchdog timer will be reset to 10 min.
-
Page 21: Using Recovery Wizard To Restore Computer
Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. Important: Before starting the recovery process, remove the PCI/ PCIe card and CFast card. -
Page 22: Specifications
SPECIFICATIONS Model Name EAC PRO-IK90 Intel® Xeon® E3-1268L V5 Processor (8M Cache, 2.4 GHz up to 3.40 GHz) 35W Intel® Core™ i7-6700TE Processor (8M Cache, 2.4 GHz up to 3.40 GHz) 35W Intel® Core™ i3-6100TE Processor Processor (4M Cache, 2.70 GHz) 35W... - Page 23 Codec Audio Codec ALC283 Audio Connectors Line Out, Mic in (3.5mm Jack) 2 x USB 2.0 Pin header 1 x USB 3.0 Dongle 2 x COM ports pin header (RS-232) Serial Port 2 x COM pin header (UART) PS/2 1 x PS/2 pin header Internal I/O Parallel Port 1 x LPT port pin header...
- Page 24 Storage Temp. -20~60° C (-4~140° F) (Excl. HDD/ SSD/ CFast) EMC & Safety CE, FCC Certificate Shock &Vibration IEC60068-2-278, IEC60068-2-64 Operating Windows® 10 IoT Enterprise (64bit) System Windows® Embedded 8.1 Industry Pro (64bit) (Optional)
-
Page 25: Appendix
APPENDIX Appendix A: System Dimensions Top View Bottom View Front View Rear View Left Side View Right Side View... -
Page 26: Appendix B: Software Developer Support
You can download drivers and Software Development Kit (SDK) and Drivers from Winmate Download Center Winmate File Share. Winmate Download Center http://www.winmate.com.tw/>Support > Download Center > Embedded Computing > EAC PRO-IK90 Or follow the link below: http://www.winmate.com/DownCenter/DownLoadCenter.asp?DownType=2907 Winmate File Share http://www.winmate.com/ >... - Page 27 NOTES _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________...
- Page 28 NOTES _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ _________________________________________________________________ ___________________________________________________________________________...
- Page 30 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
