- Page 1 IBDRW100 IBDRW100-EX DIN Rail Box PC Intel Celeron Bay Trail-M N2930 User Guide Version 3.0 Document Part Number: 917111171001 Please read this instructions carefully before using this product, and save this manual for future use.
-
Page 2: Table Of Contents
2.2.15 RS422, RS485 Terminal Resistor (JP12,JP13, JP17, JP18) 2.2.16 USB 2.0 + LAN Connector (USBLAN2) 2.2.17 RS422, RS485 Select (JP16, JP19, JP20) 2.2.18 RS232, RS422, RS485 Select (JP8, JP9) Chapter 3: Initial Setup 3.1 DIN Rail Mounting Setup 3.2 Cable ARM Bracket Installation (Optional for IBDRW100-EX) -
Page 3: Preface
Preface 3.3 Enclosure for IBDRW100-EX Chapter 4: Driver Installation 4.1 Chipset Driver Installation 4.2 Graphic Driver Installation 4.3 Ethernet Driver Installation 4.4 Audio Driver Installation 4.5 USB 3.0 Installation 4.6 COM Port Driver Installation Chapter5: BIOS Setup 5.1 BIOS Introduction 5.1.1 BIOS Setup and Boot Procedure... -
Page 4: Preface
IBDRW100/ IBDRW100-EX User Manual Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. - Page 5 Preface Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. Note: A note is used to emphasize helpful information Important:...
- Page 6 IBDRW100/ IBDRW100-EX User Manual Safety Precautions For your safety carefully read all the safety instructions before using the device. Keep this user manual for future reference. Always disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning.
-
Page 7: Chapter 1: Introduction
With a compact size and small form factor as well as front accessible I/Os, Winmate IBDR is very convenient for wiring and DIN-rail installation in the control cabinet. The Wide operation temperature and Industrial serial port design makes this unit a perfect communication even in harsh and critical location. -
Page 8: Packing List
IBDRW100/ IBDRW100-EX User Manual 1.3 Packing List AC to DC 12V 36W Terminal Block 3 pin to DC Power Cable Power Adapter 2.5Ø female adapter cable DIN Rail Mounting Clip User Manual Driver CD ... -
Page 9: Chassis Dimensions
Chapter 1: Introduction 1.4 Chassis Dimensions Unit: mm... -
Page 10: Description Of Parts
IBDRW100/ IBDRW100-EX User Manual 1.5 Description of Parts Front 1. VGA 2. RS232/422/485 3. LAN 4. LAN 5. USB 6. Audio Jack Rear 7. Isolated RS422 default (RS485 as optional) 8. DIDO 9. Power terminal Block (9-36V DC IN) -
Page 11: Chapter 2: Hardware Installation
Chapter 2: Hardware Installation Chapter 2: Hardware Installation 2.1 Motherboard Connectors Description The following figures show the connectors on Winmate IBDRW and the following sections give you detailed information about function of each peripheral. The figure below shows motherboard connector locations:... -
Page 12: Connector Pin Assignment
IBDRW100/ IBDRW100-EX User Manual The table below shows each of Motherboard connectors and its functions. Item Description Connectors AUDIO1 Audio connector COM2 RS422, RS485 CON3 COM+VGA connector CON4 Isolator DIDO DIDO1 Digital Input/ Output connector DUALLAN1 DUAL LAN connector DVI connector... -
Page 13: Rs422, Rs485 (Com2)
Chapter 2: Hardware Installation 2.2.2 RS422, RS485 (COM2) Signal Name Signal Name ISO_485TXRX- ISO_422RX- ISO_485TXRX+ ISOGND ISO_422RX+ ISOGND 2.2.3 COM1 + VGA (CON3) RS422/485 Signal Name Signal Name DCD4/485TXRX- G_FILTER SRD4/485TXRX+ B_FILTER STD4/422RX+ DTR4/422RX- NDSR1 NRTS1 NCTS1 VGA_5V NRI1 R_FILTER 2.2.4 Isolator DIDO (CON4) Signal Name Signal Name... -
Page 14: Dual Lan (Duallan1)
IBDRW100/ IBDRW100-EX User Manual 2.2.6 Dual LAN (DUALLAN1) Signal Name Signal Name LAN3_MDI0_IN+ LAN3_MDI0_IN- LAN3_MDI1_IN+ LAN3_100_10_G LAN3_MDI1_IN- LAN3_1000_O LAN3_MDI2_IN+ LAN3_ACTIVE_Y LAN3_MDI2_IN- LAN3_VDD33 LAN3_MDI3_IN+ LAN4_100_10_G LAN3_MDI3_IN- LAN4_1000_O LAN4_ACTIVE_Y LAN4_VDD33 LAN4_MDI0_IN+ LAN_GND LAN4_MDI0_IN- LAN_GND LAN4_MDI1_IN+ LAN_GND LAN4_MDI1_IN- LAN4_MDI2_IN+ LAN_GND LAN4_MDI2_IN- LAN_GND LAN4_MDI3_IN+ LAN_GND 2.2.7 DVI Connector(J3) -
Page 15: Mini Pcie X1 Connector (Minipcie1 Full And Half Card)
Chapter 2: Hardware Installation 2.2.9 Mini PCIE x1 Connector (MINIPCIE1 Full and Half Card) 2.2.10 Panel1 (PANEL1) Signal Name Signal Name +V5S +V3.3S SATA_LED# PWRBTN# FP_RST_N +V5A 2.2.11 SSD1 Mini PCIE x1 Connector (SSD1 Full Card) 2.2.12 USB1 USB2.0 Signal Name Signal Name USBVCC USBVCC... -
Page 16: Usb 2.0 + Usb3.0 + Lan Connector (Usblan3)
IBDRW100/ IBDRW100-EX User Manual 2.2.13 USB 2.0 + USB3.0 + LAN Connector (USBLAN3) Signal Name Signal Name +5VUSB3.0 LAN1_MDI0_IN+ U2DN0 LAN1_MDI0_IN- U2DP0 LAN1_MDI1_IN+ UGND LAN1_MDI1_IN- U3RXDN1 LAN1_MDI2_IN+ U3RXDP1 LAN1_MDI2_IN- UGND LAN1_MDI3_IN+ U3TXDN1 LAN1_MDI3_IN- U3TXDP1 LAN1_DGND +5VUSB3.0 LAN1_VDD33 U2DN1 LAN1_ACTIVE_Y U2DP1... -
Page 17: Usb 2.0 + Lan Connector (Usblan2)
Chapter 2: Hardware Installation 2.2.16 USB 2.0 + LAN Connector (USBLAN2) Signal Signal Name Name USB5V TX2+ USB- TX2- USB+ TX3+ TX3- USB5V TX4+ USB- TX4- USB+ DGND LEDGN YLED TX1+ OLED TX1- GLED 2.2.17 RS422, RS485 Select (JP16, JP19, JP20) 1-2 : RS485 2-3 : RS422 2.2.18 RS232, RS422, RS485 Select (JP8, JP9) -
Page 18: Chapter 3: Initial Setup
IBDRW100/ IBDRW100-EX User Manual Chapter 3: Initial Setup 3.1 DIN Rail Mounting Setup Please follow these steps to mount the IBDRW hook kit on a DIN rail Screw the provided DIN-rail Kit on the rear side of the box as the diagram shown below. -
Page 19: Cable Arm Bracket Installation (Optional For Ibdrw100-Ex)
Chapter 3: Initial Setup 3.2 Cable ARM Bracket Installation (Optional for IBDRW100-EX) In hazardous locations, sparks caused by the movement from a cable and connector which is even slightly loose could lead to a disaster and to prevent this, cable arm bracket can be use to secure some LAN, USB and Audio connectors. -
Page 20: Enclosure For Ibdrw100-Ex
User may also include secure mounting (hence the DIN Rail design) or mounting in specially designed enclosure boxes. The pictures below show an IP54-spec enclosure box Winmate uses for the IBDRW100-EX to meet ATEX and C1D2 certification. This enclosure box is designed for ATEX (increased safety) protection are ideal for deployment in hazardous location including ... - Page 21 Please check the tightness of the connections / wires Follow these steps to install the IBDRW100-EX inside of the enclosure box: Attached DIN Rail adapter to the IBDRW100-EX Box PC using the screws provided Mount the DIN rail inside of the enclosure Box...
-
Page 22: Chapter 4: Driver Installation
IBDRW100/ IBDRW100-EX User Manual Chapter 4: Driver Installation 4.1 Chipset Driver Installation Step 1. Insert the CD that comes with the motherboard. Open the file document “Chipset Driver”. Step 2. Click on “infinst_auto.exe“ to install driver. - Page 23 Chapter 4: Driver Installation Step 3. Click on “Yes “ to agree License Step 4. Click on “Next“ to install driver.
- Page 24 IBDRW100/ IBDRW100-EX User Manual Step 5. Click on “Next“ to install driver. Step 7. Click on “Yes, I want to restart this computer now“ to go on.
-
Page 25: Graphic Driver Installation
Chapter 4: Driver Installation 4.2 Graphic Driver Installation IB32 Motherboard is equipped with Intel SoC Integrated Device. The Intel Graphic Drivers should be installed first, and it will enable “Video Controller (VGA compatible). Follow the instructions below to complete the installation. You will quickly complete the installation. Step 1. - Page 26 IBDRW100/ IBDRW100-EX User Manual Step 3. Click on “Next “ to install Driver. Step 4. Click on “Yes “ to agree License.
- Page 27 Chapter 4: Driver Installation Step 5. Click on “Next “ to install Driver. Step 6. Click on “Next “ to install Driver.
-
Page 28: Ethernet Driver Installation
IBDRW100/ IBDRW100-EX User Manual Step 7. Click on “Yes, I want to restart this computer now“ to go on. 4.3 Ethernet Driver Installation The Users must make sure which operating system you are using in the IB32 Motherboard before installing the Ethernet drivers. Follow the steps below to complete the installation of the Intel WG82574L Gigabit Ethernet controller LAN drivers. - Page 29 Chapter 4: Driver Installation Step 3. Click on “Update Driver” to execute the setup. Step 4. Click on “Browse my computer for driver software“ to install driver.
- Page 30 IBDRW100/ IBDRW100-EX User Manual Ste .5. Choose the path to install driver. Step 6. Click on “Close“ and go on.
-
Page 31: Audio Driver Installation
Chapter 4: Driver Installation 4.4 Audio Driver Installation The ALC886 series are high-performance 7.1+2 Channel High Definition Audio Codecs providing ten DAC channels that simultaneously support 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. -
Page 32: Usb 3.0 Installation
IBDRW100/ IBDRW100-EX User Manual Step 3. Click on “Yes, I want to restart my computer now” to finish installation. 4.5 USB 3.0 Installation IB32 Motherboard is designed with Intel® USB 3.0 eXtensible Host Controller. You need to install the Intel® USB 3.0 eXtensible Host Controller driver to enable the function. - Page 33 Chapter 4: Driver Installation Step 5. Review Readme File Information and click “Next” to proceed. Step 6.When the “Setup Progress” is complete click “Next” to proceed.
- Page 34 IBDRW100/ IBDRW100-EX User Manual Step 7.When the “Setup Progress” is complete click “Next” to proceed. Step 8. Lastly, the “Setup Complete” screen appears so click “Finish” to restart your computer.
-
Page 35: Com Port Driver Installation
Chapter 4: Driver Installation 4.6 COM Port Driver Installation Step 1. If the system is WIN7 please first do close UAC.(Refer following “Disabling User Account Control (UAC) in Windows 7”) Step 2. Extract the Patch_0408.zip to a folder. Step 3. Double-click batch file (patch.bat) will install driver. Step 4. - Page 36 IBDRW100/ IBDRW100-EX User Manual Step 5. You will need to restart your computer for driver install success. Type in this command from the Run menu: C:\Windows\System32\UserAccountControlSettings.exe Or uac To turn off UAC, move the slider to the Never notify position, and then click OK. If you're prompted for an administrator password or confirmation, type the password or provide confirmation.
-
Page 37: Chapter5: Bios Setup
Chapter5: BIOS Setup Chapter5: BIOS Setup 5.1 BIOS Introduction 5.1.1 BIOS Setup and Boot Procedure BIOS stand for “Basic Input Output System” and it is the most basic communication between user and the hardware. To enter BIOS Setup, the [DEL] key must be pressed after the USB controller has been initialized as soon as the following message appears on the monitor during Power On Self-Test (POST): “Press DEL to run SETUP”... -
Page 38: Bios Menu
IBDRW100/ IBDRW100-EX User Manual 5.2 BIOS Menu 5.2.1 Main Immediately after the [DEL] key is pressed during startup, the main BIOS setup menu appears: BIOS setting Description Setting options Effect This is current time setting. The time is Adjustment of the... -
Page 39: Advanced
Chapter5: BIOS Setup BIOS Advance Setup Utility BIOS Setting Description Enable and disable BIOS support for Intel Active Management Intel AMT Support Technology Enable and disable the boot interruption <Ctrl+P> to call up Intel AMT Setup Prompt Intel Management Engine BIOS Extention (MBEx) configuration page Enable Client Initiated Remote Access (CIRA) Fast Call for AMT CIRA Request Trig... - Page 40 IBDRW100/ IBDRW100-EX User Manual BIOS Setting Description Setting Effect options Opens ACPI Settings Configures ACPI settings Enter submenu Opens SMART Settings Configures SMART settings Enter submenu Configures System Super IO Opens Super IO Configuration Enter Chip parameters submenu Opens Hardware Monitor...
- Page 41 Chapter5: BIOS Setup 5.2.3.1 USB Configuration BIOS Setting Description Setting Effect Option Legacy USB User can enable or Disable Will keep USB devices Support disable USB port. available only for EFI applications. Enable Enable all the USB devices USB 3.0 Support User can enable or Enable Enable USB 3.0 is enable disable USB 3.0 (XHCI)
-
Page 42: Chipset
IBDRW100/ IBDRW100-EX User Manual 5.2.4 Chipset 5.2.4.1 Chipset North Bridge Parameters BIOS Setting Description Setting Effect options Provides onboard Opens Intel IGD Configuration Enter graphics-related submenu configuration options Configures IGD – LCD Opens IGD – LCD Control Enter setting submenu... - Page 43 Chapter5: BIOS Setup 5.2.4.2 Chipset South Bridge Parameters BIOS Setting Description Setting Effect options Disables this Disable Configures function Azalia HD Audio Enables this onboard audio Enable function function Provides user with Enable / Disable USB Configuration USB 2.0(EHCI) this function configuration Enable / Disable options for the USB...
- Page 44 IBDRW100/ IBDRW100-EX User Manual a specific PCI port 3 this function Express channel and speed configuration Disables this Disable Configures high function High Precision Timer precision timer Enables this Enable (HPET) in the function operating system The System stays off upon the return...
-
Page 45: Security
Chapter5: BIOS Setup 5.2.5 Security Allows user to configure an administration or user password, user must enter the administrator or user password at system startup and when entering BIOS setup BIOS Setting Description Setting Effect options Displays whether or not an Administrator Password Enter Enter Password... - Page 46 IBDRW100/ IBDRW100-EX User Manual 5.2.5.1 Security Boot Menu BIOS Setting Description Setting options Effect Disables this Disable Displays the current boot function Secure Boot Enables this state Enable function Disables this Disable Allows user to configure function Secure Boot Mode...
-
Page 47: Boot
Chapter5: BIOS Setup 5.2.6 Boot BIOS Setting Description Setting options Effect Allows user to Set the prompt configure the number Setup Prompt Timeout Enter timeout of seconds to stay in BIOS setup prompt screen Enables or disables Remains On Numlock feature on Boot NumLock State the numeric keypad Remains Off... -
Page 48: Save & Exit
IBDRW100/ IBDRW100-EX User Manual the OS boot process. (Default: Disabled) Specifies the overall Hard drive as the Boot Option#1 Boot Option Priority boot order from the first priority (hard drive) available devices Specifies the boot Enter the order for a specific device type,... - Page 49 Chapter5: BIOS Setup Setting BIOS Setting Description Effect options Saves the changes Enter <Yes> This saves the changes to the CMOS and exits Return to the BIOS Save Changes and the BIOS Setup Setup Main Menu Esc <No> Exit program This exits the BIOS Setup Saves the changes Enter <Yes>...
-
Page 50: Using Recovery Wizard To Restore The System
IBDRW100/ IBDRW100-EX User Manual 5.3 Using Recovery Wizard to Restore the System Our system has a dedicate recovery partition stored on the hard drive of the PC to enable quick one-key recovery process. This partition occupies about 11GB of the storage space, and comes built-in to each Panel PC and Box PC. -
Page 51: Appendix
Edition standard and equivalent CSA C22.2 No 60950-1-07, 2 Edition Standard N.A. Safety for HazLoc Class 1 Division 2, Groups A,B,C,D,T4 (Optional for IBDRW100-EX) Certification by Underwriter Laboratories to ANSI/ISA-12.12.01-2012 standard and equivalent CAN/CSA C22.2 No 213-M1987 Standard Explosive Atmosphere Directive (optional for IBDRW100-EX) Certification with ATEX Directive 94/9/EC;... - Page 52 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
