Document Version 1.0
Document Part No. 91521110112D
Please read these instructions carefully before using this product, and save this manual for future use.
4.3"/7"/ 10.1"
EL-Series HMI
ARM A53 Quad Core 2.0GHz
User Guide
Model No. W04IM3S-ELT1
W07IM3S-ELT1
W10IM3S-ELH2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Winmate EL Series

  • Page 1 4.3”/7”/ 10.1” EL-Series HMI ARM A53 Quad Core 2.0GHz Model No. W04IM3S-ELT1 W07IM3S-ELT1 W10IM3S-ELH2 User Guide Document Version 1.0 Document Part No. 91521110112D Please read these instructions carefully before using this product, and save this manual for future use.
  • Page 2: Table Of Contents

    3.4 Using the On-Screen Keyboard ....................28 3.4.1 Entering Text ........................28 3.4.2 Editing Text ........................31 3.5 Display Settings ........................33 3.6 Language and Keyboard Settings ..................... 34 3.7 About tablet ..........................37 Chapter 4: Winmate Kiosk Manager ................... 38...
  • Page 3 Preface 4.1 Lock Applications Launcher ...................... 38 4.2 Change Password ........................44 4.3 Unlock Applications Launcher ....................45 Chapter 5: Networks and Wireless Devices ................48 5.1 Connecting to Wi-Fi Networks (Optional) .................. 48 5.1.1 Turning on Wi-Fi and Connecting to Wi-Fi Networks ............48 5.1.2 Adding Wi-Fi Network .....................
  • Page 4: Preface

    EL-Series HMI Panel PC User Manual Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
  • Page 5 Preface Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. NOTE: A note is used to emphasize helpful information IMPORTANT:...
  • Page 6 EL-Series HMI Panel PC User Manual Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
  • Page 7 Preface  Never open the equipment. For safety reasons, only qualified service personnel should open the equipment.  All cautions and warnings on the equipment should be noted. *Let service personnel to check the equipment in case any of the following problems appear: o The power cord or plug is damaged.
  • Page 8: About This User Manual

    • EN 60950-1:2006/A11:2009/A1:2010/A12:2011/ A2:2013 About This User Manual This User Manual provides information about using the Winmate® E L-Series HMI. This User Manual applies to the EL-Series HMI –W04IM3S-ELT1, W07IM3S-ELT1, W10IM3S-ELH2. It includes:  EL-Series HMI User Manual – contains detailed description on how to use the HMI device, its components and features.
  • Page 9: Chapter 1: Introduction

    Chapter 1: Introduction Chapter 1: Introduction Congratulations on purchasing Winmate® E L-Series HMI. Winmate® continues developing new generation of Human Machine Interfaces for Industry 4.0 and Internet of Things (IoT). Our EL- Series HMI runs on Android 11 operating system that allows installing the latest applications (APPs).
  • Page 10: Package Contents

    EL-Series HMI Panel PC User Manual 1.2 Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: AC Adapter Quick Start Guide...
  • Page 11: Description Of Parts

    Chapter 1: Introduction 1.3 Description of Parts This section describes appearance, connectors’ layout and mechanical dimensions of EL-Series HMI. 1.3.1 W04IM3S-ELT1 ; EL-Series HMI 4.3” Unit: mm 1.3.2 W07IM3S-ELT1 ; EL-Series HMI 7” Unit: mm...
  • Page 12: W10Im3S-Elh2; El-Series Hmi 10.1

    EL-Series HMI Panel PC User Manual 1.3.3 W10IM3S-ELH2; EL-Series HMI 10.1” Unit: mm...
  • Page 13: Chapter 2: Getting Started

    Chapter 2: Getting Started Chapter 2: Getting Started This chapter provides information on how to connect the HMI device to the source of power, connector pinouts and the guideline to turn on/off the HMI device. 2.1 Powering On 2.1.1 AC Adapter Components 3 Pin Terminal Block to AC Adapter Power Cord...
  • Page 14: Power Considerations

    EL-Series HMI Panel PC User Manual 2.1.2 Power Considerations The HMI device operates on external DC power. Use the AC adapter included in the package. CAUTION/ATTENTION Use only the AC adapter included in your package (Rating: Output 12~24V). Using other AC adapters may damage the device. Utiliser seulement le convertisseur AC inclu avec votre appareil (Puissance: Sortie 12~24V).
  • Page 15: Connector Pinouts

    Chapter 2: Getting Started 2.2 Connector Pinouts 2.2.1 DC Input Connector Terminal Block DC power source input is a 3 pin terminal block connector. Power Input is 12V DC in. Minimum Voltage 12V Maximum Voltage 24V Voltage IMPORTANT: Support PoE (optional), requires IEEE 802.3at 25W power input 2.2.2 USB 2.0 Connector Use USB A Type (USB2.0) connector to connect your HMI device to other USB2.0 compatible devices.
  • Page 16: Turning On And Off The Hmi Device

    EL-Series HMI Panel PC User Manual TX1+ TX1- TX2+ TX2- TX3+ TX3- TX4+ TX4- 2.3 Turning On and Off the HMI Device This section describes how to turn on and off the HMI device. To turn on the HMI device: 1.
  • Page 17 Chapter 2: Getting Started 3. Disconnect the HMI device from the power source (if necessary).
  • Page 18: Resetting To Factory Defaults

    EL-Series HMI Panel PC User Manual 2.4 Resetting to Factory Defaults To reset the device to factory defaults: 1. Slide from the bottom side, then open Settings app. 2. Tap System , user can select to back up application data, Wi-Fi passwords and other settings to Google servers by tapping Backup My Data.
  • Page 19 Chapter 2: Getting Started 4. Tap Reset options. 5. Tap Erase all data(factory reset) to reset the HMI.
  • Page 20 EL-Series HMI Panel PC User Manual 6. Read all the available information and then press Erase all date to erase all the data in storage such as music or photo. 7. Press Erase all date to erase all your personal information and downloaded apps.
  • Page 21: Chapter 3: Using The Hmi Panel Pc

    Chapter 3: Using the HMI Panel PC Chapter 3: Using the HMI Panel PC This chapter explains how to use the buttons, status icons, and controls of the S-series HMI running on Android 11 operating system and provides instructions on entering and capturing data. 3.1 Using the Touch Screen The touchscreen supports the core gestures for Android.
  • Page 22: Using The Home Screen

    EL-Series HMI Panel PC User Manual 3.2 Using the Home Screen Home screen is the starting point to access all the features on your HMI Device. It displays application icons, widgets, shortcuts, and other features. User can personalize the home screen. See “Personalizing home screen”.
  • Page 23: Personalizing Home Screen

    Chapter 3: Using the HMI Panel PC 3.2.1 Personalizing Home Screen User can add application icons, shortcuts, widgets, and other items to any part of any home screen where there is free space. User can also switch the wallpaper. To change wallpaper on the HOME SCREEN: 1.
  • Page 24 EL-Series HMI Panel PC User Manual 3. In the Wallpaper menu select the location of wallpaper, and then tap the type of item you want to add. To move an item on the HOME SCREEN: 1. Tap and hold the item you want to move, until it can be moved. Drag it to a new location on the screen.
  • Page 25 Chapter 3: Using the HMI Panel PC 2. Place the item where you want to put it and lift your finger. To remove items from the HOME SCREEN: 1. Tap and hold the item you want to remove. The launcher icon will show Remove on the top of the screen.
  • Page 26: Viewing Other Parts Of The Home Screen

    EL-Series HMI Panel PC User Manual 3.2.2 Viewing other parts of the Home Screen 1. Slide your finger left or right across the Home screen. Extensions to the Home screen provide extra space for APPS, shortcuts, and other items.
  • Page 27 Chapter 3: Using the HMI Panel PC 2. Swipe from the bottom of the main desktop, to view the entire APPS on the device.
  • Page 28: Status And Notification Icons

    EL-Series HMI Panel PC User Manual 3.3 Status and Notification Icons The status bar appears at the top of every screen. On the left are notification icons and on the right are status icons, along with the current time. 3.3.1 Notification Icons Pull down from the left top of the screen to get the notifications area.
  • Page 29: Using The On-Screen Keyboard

    Chapter 3: Using the HMI Panel PC 3.4 Using the On-Screen Keyboard User will be able to enter text using the On-Screen Keyboard. Some applications will launch the keyboard automatically. In others, user needs to touch a text field where user wants to enter text to launch the keyboard.
  • Page 30 EL-Series HMI Panel PC User Manual 4. To enter symbols and other characters, tap and hold one of the top-row keys and slide your finger up to the list of the options. Lift your finger when you find your selection.
  • Page 31 Chapter 3: Using the HMI Panel PC 5. To view additional symbols, tap on the numeric keyboard. 6. To close the On-Screen keyboard, press the back button on the top.
  • Page 32: Editing Text

    EL-Series HMI Panel PC User Manual 3.4.2 Editing Text To select text: 1. Double-tap the text you want to select. 2. Tap to select all the sentences in the menu that appears, the selected text is highlighted in green, with a tab at each end of the selected word. 3.
  • Page 33 Chapter 3: Using the HMI Panel PC To Paste Text: 1. After Cut or Copy the text, see the section above “To Cut or Copy Text”. 2. Place the cursor in the text field where you want to paste the text, user can paste text that you copied from one application into a text field in any application.
  • Page 34: Display Settings

    EL-Series HMI Panel PC User Manual 3.5 Display Settings Use the display settings to configure brightness and other screen settings. 1. Swipe from the bottom of the main desktop, tap Settings , and then tap Display Display  Brightness level – for adjusting the brightness of the screen. ...
  • Page 35: Language And Keyboard Settings

    Chapter 3: Using the HMI Panel PC 3.6 Language and Keyboard Settings Use the Language & keyboard settings to select the language for the text on your HMI and for configuring On-Screen Keyboard, including words that you have added to its dictionary. 1.
  • Page 36 EL-Series HMI Panel PC User Manual  Keyboard & input methods o On-screen Keyboard – shows default Android Keyboard (AOSP). o Physical Keyboard – allows the user to apply physical keyboard settings if connected.  Appearance & layouts o Theme – to select the theme of layout. o Custom input styles –...
  • Page 37 Chapter 3: Using the HMI Panel PC o Personalized suggestions – learn from your communications and typed data to improve suggestions. o Suggest contact names – use names from Contacts for suggestions and corrections. o Next-word suggestion – use previous word in making suggestion. ...
  • Page 38: About Tablet

    EL-Series HMI Panel PC User Manual Changing the Keyboard Language The current keyboard language is displayed on the Space key and user can switch languages. 1. Tap and hold the space key. 2. Without lifting the finger, slide it to the left or right until the language you want to use appears in the center of the small window above the Space Key.
  • Page 39: Chapter 4: Winmate Kiosk Manager

    Chapter 4: Winmate Kiosk Manager Chapter 4: Winmate Kiosk Manager The S-Series HMI comes with preinstalled APP named Winmate® Kiosk Manager (WKM). This application lets the device manager to lock the launcher. When the launcher is locked the user can only use one application assigned by the device manager.
  • Page 40 EL-Series HMI Panel PC User Manual 2. Press Clear and Reset Default Home.
  • Page 41 Chapter 4: Winmate Kiosk Manager 3. Select Restrict Home then Always. The system will automatically be locked on selected Apps. 4. Click the gear icon on the upper right corner. Then choose Change UI.
  • Page 42 EL-Series HMI Panel PC User Manual 5. Input the default password: password 6. Choose the layout UI, then press the empty slot to add/remove apps.
  • Page 43 Chapter 4: Winmate Kiosk Manager 7. Click Add App. 8. Select applications you want to lock. For example, Ethernet.
  • Page 44 EL-Series HMI Panel PC User Manual 9. Click SAVE AND EXIT.
  • Page 45: Change Password

    Chapter 4: Winmate Kiosk Manager 4.2 Change Password 1. In the UI edit page, select the CHANGE PASSWORD. Or, in the main Apps window, select the Kiosk Manager . Select Password Manager to start your settings.
  • Page 46: Unlock Applications Launcher

    EL-Series HMI Panel PC User Manual 2. The default password is “password”. Enter a new password in New Password field, and then tap Change Password. 4.3 Unlock Applications Launcher 1. Slide down the top bar and press Kiosk Manager icon, click Exit and please enter the password to login (the default password is password).
  • Page 47 Chapter 4: Winmate Kiosk Manager 2. Click Clear and Reset Default Home.
  • Page 48 EL-Series HMI Panel PC User Manual 3. Select Quickstep, and press ALWAYS. 4. Restart the system and you will go back to the normal Launcher.
  • Page 49: Chapter 5: Networks And Wireless Devices

    Chapter 5: Networks and Wireless Devices Chapter 5: Networks and Wireless Devices This chapter explains how to connect the S-Series HMI to network and peripheral devices. 5.1 Connecting to Wi-Fi Networks (Optional) 5.1.1 Turning on Wi-Fi and Connecting to Wi-Fi Networks 1.
  • Page 50 EL-Series HMI Panel PC User Manual 3. Tap Wi-Fi . The device scans for available Wi-Fi networks and displays the list of it. Secured networks are indicated with a lock icon. If the HMI finds a network that you have connected previously, it connects to it automatically.
  • Page 51: Adding Wi-Fi Network

    Chapter 5: Networks and Wireless Devices 5. To check the details about the speed, security, address and related settings, tap its name in the Wi-Fi settings screen. 5.1.2 Adding Wi-Fi Network 1. Turn on Wi-Fi, in the Wi-Fi settings screen, tap + Add network (at the bottom of the list of discovered networks).
  • Page 52 EL-Series HMI Panel PC User Manual...
  • Page 53: Connecting To Bt Devices (Optional)

    Chapter 5: Networks and Wireless Devices 2. Input the SSID (name) of the network, if the network is secured, tap the security menu and then tap the type of security deployed on the network. 3. Enter any required security credentials. 4.
  • Page 54: Connecting The Bt Device

    EL-Series HMI Panel PC User Manual 3. Tap Connected Devices preferences, and the toggle the on/off switch on the top-right hand side to turn on the BT. 5.2.2 Connecting the BT Device 1. Swipe from the bottom of the main desktop, tap Settings 2.
  • Page 55 Chapter 5: Networks and Wireless Devices 4. Select the device to be paired.
  • Page 56: Disconnecting Bt Device

    EL-Series HMI Panel PC User Manual 5.2.3 Disconnecting BT Device 1. Tap the device in the BT settings screen. 2. Tap FORGET to disconnect.
  • Page 57: Connecting To Computer Via Usb

    Chapter 5: Networks and Wireless Devices 5.3 Connecting to Computer via USB User can connect their HMI to a computer with USB cable to transfer files between HMI and computer. Important: When connecting your HMI to a computer and inserting its USB storage or SD card, user must follow the computer’s instructions for connecting and disconnecting USB device, to avoid damaging or corrupting files.
  • Page 58: Usb Debugging Settings

    EL-Series HMI Panel PC User Manual 5.3.2 USB Debugging Settings To permit debugging tools on a computer to communicate with User’s HMI via USB Connection. 1. Connect HMI to the computer via USB cable. 2. Swipe from the bottom of the main desktop, tap Settings , tap About tablet...
  • Page 59 Chapter 5: Networks and Wireless Devices 3. Tap Build number 7 times to access the developer mode.
  • Page 60 EL-Series HMI Panel PC User Manual 4. Pull down the screen to open notification panel. Tap USB debugging connected.
  • Page 61 Chapter 5: Networks and Wireless Devices 5. In the Developer options user can choose the action to perform. Important: Carefully follow your computer’s instructions to un-mount the USB storage or SD card. Disconnect USB device not properly can cause a loss of important data or information.
  • Page 62: Chapter 6: Mounting

    EL-Series HMI Panel PC User Manual Chapter 6: Mounting This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. 6.1 Cable Mounting Considerations For a nice look and safe installation, make sure cables are neatly hidden behind the HMI device. Refer to Chapter 2.1 for the cable installation instruction.
  • Page 63: Mounting Guide

    Chapter 6: Mounting 6.3 Mounting Guide EL-series HMI devices come with different mounting options suitable for most of the industrial and commercial applications. The main mounting approach is rear mount - very user-friendly in terms of installation. Refer to sub-sections below for more details. CAUTION/ ATTENTION Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury.
  • Page 64: Panel Mount

    EL-Series HMI Panel PC User Manual 6.3.2 Panel Mount Panel Mount solution is suitable for many applications where HMI should be embedded in the machine. With this mounting solution flat surface leave no bezel in the front. In addition to elegant design, rear mount solution is making the HMI unit easy to clean and maintain.
  • Page 65: Appendix A: Product Specifications

    Appendix A:Product Specifications Appendix A: Product Specifications Model Name W04IM3S-ELT1 W07IM3S-ELT1 W10IM3S-ELH2 Display 7” 10.1” Size/ Type 4.3” 1280x800 Resolution 480x272 1024x600 350 nits Brightness 400 nits 320 nits 800:1 Contrast Ratio 900:1 1000:1 Viewing Angle 80, 60, 80, 80 75, 75, 75, 70 85, 85, 85, 85 Projected Capacitive Multi-...
  • Page 66 EL-Series HMI Panel PC User Manual Note: 1. The product shown in this datasheet is a standard model. For diagrams that contain customized or optional I/O, please contact the Winmate Sales Team for more information. 2. All specifications are subject to change without prior notice.
  • Page 67: Appendix B: Ota Update Guide

    Appendix B: OTA Update Guide Appendix B: OTA Update Guide OTA is a tool which can help you to update OS image. To receive Android OS image file, contact our sales representatives. Once you get the image file follow the guideline below. 1.
  • Page 68 EL-Series HMI Panel PC User Manual 4. After the system shows Found OTA File !!!, tap Update Image. 5. Click on the image update file. Tap OK.
  • Page 69: Appendix C: Os Image Update Guide

    Appendix B: OTA Update Guide 6. Wait for the update. 7. Tap Reboot Now. Important: Do not disconnect the power source! Appendix C: OS Image Update Guide To receive OS image update guide please contact Winmate at https://www.winmate.com/...
  • Page 70 NOTE...
  • Page 71 NOTE...
  • Page 72 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © 2024 Winmate Inc. All rights reserved.
