After studying each department's needs, Smith decides to:
create separate workgroups for each department within the two
organizations
connect the workgroups to each other through an internal bridge
Table 2-3 provides an in-depth examination of the reorganization of
each department.
Table 2-3

Network Reorganization

Ethernet
Department Module Type
Technical 24-Port
Publications
CAD Department 24-Port
Engineering 24-Port
Department
Technical Support 24-Port
Sales 24-Port
Marketing 24-Port
As Table 2-3 indicates, Smith has divided six organizations within her
company into separate workgroups (WG1 to WG6). This enables the
workgroups to access shared resources and communicate with each
other without using the hub's backplane.
detailed example of each workgroup configuration.
Module Workgroups
Module
Slot step Workgroup
next step next
6 WG1
6 WG2
8 WG3
1 WG4
3 WG5
3 WG6
Figure 2-4
2-11
Ports Used
1 - 7
9 - 23
1 - 22
2 - 24
1 - 9
11 - 23
provides a
