Using 90° Cable
Connectors
1 Remove the hex nut from the bottom of the 50-pin module connector.
2 Attach the tie-wrap bracket to the 24-Port module using the phillips
3 Insert the tie-wrap through the opening on the tie-wrap bracket.
4 Attach the 90
3Com recommends that you use 180
however, you currently use 90
procedure to fasten the tie-wraps to your connector.
Perform this procedure prior to installing the module into the
CoreBuilder 5000 hub.
head screw provided in the tie-wrap kit (see
Tie-wrap
bracket
Phillips head
screw
Figure 3-5

Attaching the Tie-Wrap Bracket to the 24-Port Module

o
cable connectors to the module connector on the
24-Port module as shown in
Installing the Module
o
connectors with this module. If,
o
cable connectors, use the following
Figure
Top
Insert the tie-wrap
through the opening on
the tie-wrap bracket
Figure 3-6.
3-11
3-5).
