x1
Cooee Monitor Wall
CAUTION
• Clear open space for install
0
• May need need a sturdy table.
• + 65lbs lift required
1
2 Person Lift
a.
Lay Monitor wall on table.
PAGE 1
CONTENTS FOR Cooee Monitor Wall
x1
Monitor Wall
Metal Base
Plates
x4
x16
3/8"
Flange Nut
Flange Nut
Tools you will need:
Two Person
7mm Spanner
Install
COOEE
MONITOR WALL
ASSEMBLY GUIDE
x2
x4
Lockable
Castors
x8
M4
3/8" Washer
15/16" Spanner
b.
Hang bottom end off the table
to allow for base assembly.
x16
M4 Countersunk
Bolts
x4
3/8" 5" Long
Hex Bolt
Quick grip
Min 10"[254mm]
Overhang
Advertisement
Related Manuals for Func COOEE
Summary of Contents for Func COOEE
- Page 1 COOEE MONITOR WALL ASSEMBLY GUIDE CONTENTS FOR Cooee Monitor Wall Monitor Wall Metal Base Lockable M4 Countersunk Plates Castors Bolts 3/8” 3/8” Washer 3/8” 5” Long Flange Nut Flange Nut Hex Bolt Cooee Monitor Wall Tools you will need: CAUTION •...
- Page 2 COOEE MONITOR WALL ASSEMBLY GUIDE Lay metal bases on Monitor Wall. Clamp with quick grip. Ensure Holes are aligned. Torque= 45Ft-Lb Insert 3/8 bolt, Washer and Flange Nut. Clamp with quick grip. Tighten bolts in Ensure all bolts are in the same direction order and repeat to prevent one bolt tighter than the other.
- Page 3 MOUNTING AREA Mount Fixed TV Mount in the Blue area above. Avoid damaging cables while drilling or screwing. Mounting screws must not exceed 1.5in long. Typical TV Mount shown above (this is a representation only. Assembled Cooee Monitor Wall PAGE 3...
- Page 4 • Do not screw or drill anywhere unless • Do not load one side of the wall heavy acces- stated on the Func Assembly guide. sories, as it increase the chance of tipping. • Recommend TV Mount to be as slim as •...
