x1
Mini Presentation
Wall
CAUTION
• Clear open space for install
0
• May need need a sturdy table.
• + 65lbs lift required
1
2 Person Lift
a.
Lay Mini Presentation Wall
on table.
PAGE 1
CONTENTS FOR Cooee Tool Wall
x1
Mini Presentation
Wall
x4
x8
Lockable
3/8"
Castors
Flange Nut
Tools you will need:
Two Person
Install
Mini Presentation
ASSEMBLY GUIDE
x2
x4
Pen Tray
Metal Base
Plates
x16
x16
M4
3/8" Washer
Flange Nut
7mm Spanner
15/16" Spanner
b.
Hang bottom end off the table
to allow for base assembly.
COOEE
Wall
x16
M4 Countersunk
Bolts
x8
3/8" 3.5" Long
Hex Bolt
Quick grip
Min 10"[254mm]
Overhang
Advertisement
Related Manuals for Func COOEE
Summary of Contents for Func COOEE
- Page 1 COOEE Mini Presentation Wall ASSEMBLY GUIDE CONTENTS FOR Cooee Tool Wall Mini Presentation Pen Tray Metal Base M4 Countersunk Wall Plates Bolts Lockable 3/8” 3/8” Washer 3/8” 3.5” Long Castors Flange Nut Flange Nut Hex Bolt Mini Presentation Wall Tools you will need: CAUTION •...
- Page 2 COOEE Mini Presentation Wall ASSEMBLY GUIDE Lay metal base’s on Mini Presentation Wall. Clamp with quick grip. Ensure Hole’s are aligned. Torque= 44.25Ft-Lb Insert 3/8 bolt, Washer and Flange Nut. Clamp with quick grip. Tighten bolts in Ensure all bolts are in the same direction order and repeat -to prevent one bolt tighter than the other.
- Page 3 COOEE Mini Presentation Wall ASSEMBLY GUIDE 2 Person Lift Lift Mini Presentation Wall onto the ground. Stand up and ensure Mini Presentation wall is able to move and castors can be locked. Insert Pen Tray Acoustic PET Assembled Mini Presentation Wall...
