2.4.2 RTC (optional)

ESP32-C6 supports main crystal division, an external 32.768 kHz crystal, or an external signal e.g. an
oscillator to act as the RTC sleep clock, suitable for applications that require high-precision RTC clocks such as
4
8
scenario which requires the Bluetooth wake-up function.
GND
VCC
Figure
8
shows the schematic for the external 32.768 kHz crystal.
Notice:
• Please note the requirements for the 32.768 kHz crystal.
– Equivalent series resistance (ESR) ⩽ 70 kΩ.
– Load capacitance at both ends should be configured according to the crystal's specification. For reference,
see Section 2.4.1.
• The parallel resistor R is used for biasing the crystal circuit (5 MΩ < R ⩽ 10 MΩ). In general, you do not need to
populate the resistor.
• If the RTC source is not required, then the pins for the external 32.768 kHz crystal can be used as GPIOs.
