2 Schematic Checklist
Figure 9 shows the schematic of the external signal.
The external signal can be input to the XTAL's P end through a DC blocking capacitor (about 20 pF). The XTAL's
N end can be floating. The signal should meet the following requirements:
Input to XTAL's P End
Sine wave or square wave
2.5 RF
The RF circuit of the ESP32-C6 series of chips is mainly composed of three parts, the RF traces on the PCB
D
board, the chip matching circuit, the antenna and the antenna matching circuit.
For the RF traces on the PCB board, 50 Ω impedance control is required.
Chip matching circuit must be placed close to the chip. It is mainly used to adjust the impedance point and
suppress harmonics. The CLC structure is preferred, and a set of LC can be added if space permits. The CLC
matching circuit is shown in Figure 10.
For the antenna and the antenna matching circuit, to ensure the radiation performance, the antenna's
characteristic impedance must be around 50 Ω. Adding a CLC matching circuit near the antenna is
recommended to adjust the antenna. However, if the available space is limited and the antenna impedance point
C
can be guaranteed to be 50 Ω by simulation, then there is no need to add a matching circuit near the
5
antenna.
B
Figure 11 shows the general process of RF tuning. Please be noted the matching parameters are subject to the
RF tuning of PCB board, which depends greatly on the antenna and PCB layout. The initial value of the resistor
can be 0 Ω. For ESP32-C6 series of chips, it is recommended to set the S11 parameter in the figure below to
30+j0 Ω and the center frequency is 2442 MHz.
If the RF function is not required, the RF pin can be left floating.
