  • Page 1 User Manual POC-S176 Point-of-Care Terminal...
  • Page 2 Instructions for the User The document combines text and illustrations, providing a comprehensive overview of the system. The information is presented as sequential steps of action, allowing the user to learn directly how to use the device. The text provides explanations and instructs the user step-by-step in the practical use of the product, with short, clear instructions in easy-to-follow sequence.
  • Page 3 Repair of the device may also only be carried out by trained service personnel. Advantech recommends that a service contract be obtained with Advantech Service and that all repairs also be carried out by them. Otherwise the correct functioning of the device may be compromised.
  • Page 4 Maintenance: To properly maintain and clean the surfaces, use only the approved products or clean with a dry applicator. Caution! When servicing the device, always use replacement parts that meet Advantech standards. Advantech Medical cannot warrant or endorse the safe performance of third-party replacement parts for use with our medical device.
  • Page 5 When connecting electrical devices, the operator is responsible for ensuring that the resulting system meets the requirements set forth by the following standards: EN 60601-1 (IEC 60601-1) Medical electrical equipment Part 1: General requirements for safety EN 60601-1-1 (IEC 60601-1-1) Medical electrical equipment Part 1-1: General requirements for safety Collateral standard: Safety requirements for Medical electrical systems...
  • Page 6 List of Accessories Before installing your Point-of-Care Terminal, ensure that the following materials have been received: POC-S176 series Point-of-Care Terminal Accessories for POC-S176 – CD-ROM disc-"Drivers, User's manual and Utilities" –...
  • Page 7 Additional Information and Assistance Contact your distributor, sales representative, or Advantech's customer service cen- ter for technical support if you need additional assistance. Please have the following information ready before you call: Product name and serial number Description of your peripheral attachments Description of your software (operating system, version, application software, etc.)
  • Page 8 POC-S176 User Manual viii...

  • Page 9: Table Of Contents

    Contents Chapter General Information ......1 Introduction ....................2 Specifications .................... 2 Table 1.1: Touchscreen Specification ......... 4 LCD Specifications..................4 Dimensions ....................5 Figure 1.1 Dimensions of the POC-S176 ........5 Chapter System Setup ........7 A Quick Tour of the POC-S176..............8 Figure 2.1 Front view of the Point-of-care terminal......
  • Page 10 6.2.1 Installation for Windows XP ............30 Further Information ................. 34 Chapter Utilities and Hot Fixes ...... 35 Introduction ..................... 36 Wake up by External USB Device at S3 Resume (Wake up) ....36 7.2.1 Installation for Windows XP ............36 Chapter Operation Information ......

  • Page 11: Chapter 1 General Information

    Chapter General Information Sections include: ! Introduction ! Specifications ! LCD Specifications ! Dimensions...

  • Page 12: Introduction

    Introduction The POC-S176 is an Intel® Core Duo / Intel® Core 2 Duo Mobility processor- based computer that is designed to serve as a Point-of-Care terminal (POC.) It is a PC-based system with 17" color TFT LCD display, Single DVI-I Port, Dual on-board 10/100/1000 PCI-E Ethernet controller, Single COM port, Quad USB 2.0 port and a 24-bit stereo audio controller.
  • Page 13 Display interface SDVO interface: Chrontel 7307C Single channel DVI transmitter to support External Single display Display resolution: Supports 24-bit digital output (DVI-I port) resolutions up to 1600 x 1200 at 60 Hz Graphic chipset: Intel® Graphics Media Accelerator 950 engine Shared memory: Dynamic Video Memory Technology (DVMT) 3.0 to dynami- cally allocate up to 224 MB of system memory for graphics usage.

  • Page 14: Lcd Specifications

    Touchscreen (optional) Table 1.1: Touchscreen Specification Type Analog Resistive Resolution Continuous Light Transmission Controller RS-232 interface (uses COM3) Power Consumption +5V@200 Ma Software Driver Supports Windows 2000,Windows XP Durability (touches in a lifetime) 30 million Note! The Point-of-Care Terminal with the optionally installed touchscreen will share COM3.

  • Page 15: Dimensions

    Dimensions Figure 1.1 Dimensions of the POC-S176 A. Audio Control Button B. Power Light C. Brightness Control Button POC-S176 User Manual...
  • Page 16 C B A A. 4-pin mini-DIN DC connector B. USB 2.0 ports x 2 C. USB 2.0 ports x 2 D. DVI port E. 10/100/1000 Base-T Ethernet interface (RJ-45) F. 10/100/1000 Base-T Ethernet interface (RJ-45) G. Isolated RS-232/422/485 COM port (By jumper setting) POC-S176 User Manual...

  • Page 17: Chapter 2 System Setup

    Chapter System Setup Sections include: ! A Quick Tour of the POC-S176 ! Installation Procedures ! Running the BIOS Setup Pro- gram ! Installing System Software ! Installing the Drivers...

  • Page 18: A Quick Tour Of The Poc-S176

    A Quick Tour of the POC-S176 Before you start to set up the POC-S176, take a moment to become familiar with the locations and purposes of the controls, drives, connections and ports, which are illus- trated in the figures below. When you place the POC-S176 upright on the desktop, its front panel appears as shown in Figure 2.1.

  • Page 19: Installation Procedures

    Installation Procedures 2.2.1 Connecting the Power Cord The POC-S176 could only be powered by a DC power adapter (SINPRO Model No. MPU100-107). Be sure to always handle the power cords by holding the plug ends only. Follow these procedures in order: Connect the female end of the power adapter to the DC jack of the panel PC.

  • Page 20: Running The Bios Setup Program

    Running the BIOS Setup Program Your POC-S176 has more than likely been properly set up and configured by your dealer prior to delivery. You may still find it necessary to use the BIOS (Basic Input- Output System) setup program to change system configuration information, such as the current date and time or your type of hard drive.

  • Page 21: Installing The Drivers

    Figure 2.4 File directory "Drivers and Utilities" CD-ROM Note! The drivers and utilities used for the POC-S176 panel PCs are subject to change without notice. If in doubt, check Advantech's website or con- tact our application engineers for the latest information regarding drivers and utilities.
  • Page 22 POC-S176 User Manual...

  • Page 23: Chapter 3 Chipset And Graphics Setup

    Chapter Chipset and Graphics Setup Sections include: ! Introduction ! Installation of Chipset Driver...

  • Page 24: Introduction

    Introduction The POC-S176 has an onboard display interface. The specifications and features are described in the following section: 3.1.1 Chipset The POC-S176 uses Mobile Intel® 945GME Express chipset for its graphic control- ler. It supports SDVO device, and CRT monitors. The Mobile Intel® 945GM Express Chipsets are designed for use with Intel’s next generation mobile platform, Intel®...

  • Page 25: Installation Of Chipset Driver

    Installation of Chipset Driver Complete the following steps to install the Chipset driver. Follow the procedures in the flow chart that apply to the operating system that you are using within your POC- S176. Important! The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which appear on your screen.

  • Page 26: Installation For Windows Xp

    3.2.1 Installation for Windows XP Step 1-1: Double Click “setup.exe” in D:\Driver\CHIPSET\XP folder. The Install dia- log will appear. Step 1-2: Click 'Next' to continue. Step 1-3: Read the License Agreement and click “Yes” to proceed. POC-S176 User Manual...
  • Page 27 Step 1-4: Read the file information screen and click “Next” to proceed. Step 1-5: When the 'Setup COMPLETE' message appears click 'Finish' to restart your computer. POC-S176 User Manual...
  • Page 28 Step 2-1: Double Click “setup.exe” in D:\Driver\GRAPHICS\XP folder. The Install dialog will appear. Step 2-2. Click 'Next' to continue. Step 2-3. Read the License Agreement and click “Yes” to proceed. POC-S176 User Manual...
  • Page 29 Step 2-4. Read the file information screen and click “Next” to proceed. Step 2-5. When the 'Click Next to continue' message appears click 'Next' to pro- ceed. POC-S176 User Manual...
  • Page 30 Step 2-6. When the 'Setup Is Complete' message appears click 'Finish' to restart your computer. POC-S176 User Manual...

  • Page 31: Chapter 4 Audio Interface

    Chapter Audio Interface Sections include: ! Introduction ! Installation of Audio Driver ! Further Information...

  • Page 32: Introduction

    Introduction The POC-S176's onboard audio interface provides high-quality stereo sound by using the ALC888 audio controller from Realtek. The ALC888 series are high perfor- mance 7.1+2 channel High Definition Audio Codecs providing ten DAC channels that simultaneously support 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs.

  • Page 33: Installation For Windows 2000/Xp

    4.2.1 Installation for Windows 2000/XP Double Click “setup.exe” in D:\Driver\AUDIO\XP folder. The Install dialog will appear. Click “Next” to continue. The install program will install the driver and utility. It will spend a period of time processing. When the 'InstallShield Wizard Complete' message appears click 'Finish' to restart your computer.

  • Page 34: Further Information

    Further Information For further information about the audio interface installation on your POC-S176, including driver updates, troubleshooting guides and FAQ lists please visit the follow- ing web resources: Realtek website: www.realtek.com.tw Advantech websites: www.advantech.com www.advantech.com.tw POC-S176 User Manual...

  • Page 35: Chapter 5 Pci Express Ethernet Interface

    Chapter PCI Express Ethernet Interface Sections include: ! Introduction ! Installation of Ethernet Driver ! Further Information...

  • Page 36: Introduction

    Introduction The POC-S176 is equipped with the high performance PCIe Ethernet chipset Realtek RTL8111B which is fully compliant with IEEE 802.3 10/100/1000 Mbps standards. The Ethernet port provides a standard RJ-45 jack. Installation of the Ethernet Driver 5.2.1 Installation for Windows XP Double Click “Setup.exe”...

  • Page 37: Further Information

    When the ‘InstallShield Wizard Complete’ message appears click “Finish” to fin- ish the install program. Further Information For further information about the installation on your POC-S176, including driver updates, troubleshooting guides and FAQ lists please visit the following web resources: Realtek website: www.realtek.com.tw Advantech websites: www.advantech.com www.advantech.com.tw POC-S176 User Manual...
  • Page 38 POC-S176 User Manual...

  • Page 39: Chapter 6 Touch Panel Interface

    Chapter Touch Panel Interface Sections include: ! Introduction ! Installation of Touch Panel Driver ! Further Information...

  • Page 40: Introduction

    Introduction The POC-S176 is supported with a system integrated touch panel. The touch panel controller is control by the system COM3 interface. Installation of Touch Panel Driver 6.2.1 Installation for Windows XP Double Click “setup.exe” in D:\Driver\TOUCHSCREEN\XP and VISTA folder. The Install dialog will appear.
  • Page 41 Click “Next” to continue. Because POC-S176’s touch controller is controlled by COM3, please do not select the “Install PS/2 interface driver”. Click “Next” to continue. Please select “None” for Do 4 point calibration, the driver install program will do this 4 point calibration when the install completes. POC-S176 User Manual...
  • Page 42 Click “Next” to continue. Please select “Support Multi-Monitor System”. Click “Next” to continue. If you want to change the driver destination folder, you can click the “Browse” button to change the folder. POC-S176 User Manual...
  • Page 43 Click “Next” to continue. Click “Yes” to continue. The install program will search the touchscreen controller, and find it on COM3. POC-S176 User Manual...

  • Page 44: Further Information

    Please touch each “X” icon at the corners until the icon stops blinking. Further Information For further information about the installation on your POC-S176, including driver updates, troubleshooting guides and FAQ lists please visit the following web resources: Advantech websites: www.advantech.com www.advantech.com.tw POC-S176 User Manual...

  • Page 45: Utilities And Hot Fixes

    Chapter Utilities and Hot Fixes Sections include: ! Introduction ! Wake up by External USB Device at S3 Resume (Wake up)

  • Page 46: Introduction

    Introduction The POC-S176 system needs a specific utility or hot fix to support special functions. Wake up by External USB Device at S3 Resume (Wake up) POC-S176 support three different sleep (suspend) modes, they are: S1: Power On Suspend, system will stop the clock, turn off the LCD backlight, but keep all power on.

  • Page 47: Operation Information

    Chapter Operation Information Sections include: ! Plug in the Power Adapter ! Thermal ! Disconnect the Power ! Point-of-Care Terminal Clean- ing and Disinfecting ! General Safety Guide...

  • Page 48: Plug In The Power Adapter

    Plug in the Power Adapter Always leave space around your power adapter. Do not use this equipment in a loca- tion where airflow around the power adapter or computer is confined. Always discon- nect the power adapter before opening the computer to perform procedures such as installing memory or removing the hard disk.

  • Page 49: Point-Of-Care Terminal Cleaning And Disinfecting

    Point-of-Care Terminal Cleaning and Disinfecting During normal use of the POC (Point-of-Care Terminal) the device may become dirty and should be regularly cleaned. Steps: Prepare cleaning agent per manufacturer’s instructions or hospital protocol. Wipe the POC with a clean cloth that has been moistened in the cleaning solu- tion.

  • Page 50: General Safety Guide

    General Safety Guide For your own safety and that of your equipment, always take the following precau- tions. Disconnect the power plug (by pulling the plug, not the cord) if any of the following conditions exists: You want to remove any parts The power cord or plug becomes frayed or otherwise damaged You spill something into the case Your computer has been dropped or the case has been otherwise damaged...

  • Page 51: Appendix A Description Of Connectors

    Appendix Description of Connectors...

  • Page 52: Description Of Connectors

    Description of Connectors Figure A.1 Top Side Global View of POC-S176 Motherboard indicates all connectors’ location. POC-S176 User Manual...
  • Page 53 Figure A.2 Bottom Side Global View of POC-S176 Motherboard indicates all connectors’ location. POC-S176 User Manual...
  • Page 54 Description Description CPU FAN (Reserved) SATA Power Connector 2 DDR 2 S.O. DIMM Socket Con- System FAN (Reserved) nector* 2 Touch Enable Volume Up/Down Mini PCI-E Socket Switch Connector Inverter Connecter Mini PCI Socket COM1 Jack BIOS Socket RJ-45 Jack (LAN 0) Touchscreen I/F Connector RJ-45 Jack (LAN 1) Internal Audio Connector...

  • Page 55: Appendix B Windows Display Hot Key Function

    Appendix Windows Display Hot Key Function...

  • Page 56: Windows Display Hot Key Function

    Windows Display Hot Key Function If user want to switch the display content to a different display device, such as: 1) Internal LCD Panel (Notebook) 2) External CRT Monitor (Monitor) 3) External DVI Monitor (Digital Display) The user can press the Hot keys below to switch the display device. Hot Key Display Device Ctrl+Alt+F1...
  • Page 57 POC-S176 User Manual...
  • Page 58 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2009...
