Advantech PCE-2033 Startup Manual

PCE-2033/2133 Compact Industrial Computer
System with 12th/13th Gen Intel
Socket (LGA 1700)
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• PCE-2033/2133 Startup Manual
• Warranty card
• I/O bracket
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
https://www.adobe.com/acrobat/pdf-reader.html
(Acrobat is a trademark of Adobe).
Specifications
Standard Functions
• CPU: LGA1700 12th/13th Gen Intel
eron /Pentium
® ®
• BIOS: AMI 256Mb (Q670E)/128Mb (H610E) SPI BIOS
• Chipset:
- PCE-2033: Intel H610E chipset
®
- PCE-2133: Intel Q670E chipset
®
• System memory: Supports dual channel DDR5 SO-
DIMM-4800 MHz, 32 GB per slot without ECC function;
Max. capacity is 64 GB.
Note: Due to the inherent limitations of the PC architec-
ture, the system may not fully detect 64 GB RAM
when 64 GB RAM is actually installed.
• SATA interface: The SATAIII connector supports data
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCE-2033/2133 series Rev. A1.
Part No. 2041213301
Printed in China
Core™ i7/i5/i3/Cel-
®
2nd Edition
December 2023
Core™ i CPU
®
Specifications (Cont.)
transmission rates up to 600 MB/s. The SATAIII port sup-
ports Advanced Host Controller Interface (AHCI) technol-
ogy. Q670E can support RAID 0, 1, 5, 10.
• M.2 socket: One M.2 socket supports up to PCIe x4 Gen
4 M-Key 2280 type storage devices (PCE-2133 only).
• Serial ports: 2 serial ports: COM1, COM2 are RS-
232/422/485, with BIOS menu options.
• Watchdog timer: 1~255 sec/min timer level intervals
• USB 3.2/2.0: 8 x USB ports:
- PCE-2133: 8 x USB 3.2 Gen 2
- PCE-2033: 4 x USB 3.2 Gen1, 4 x USB 2.0
Graphics
• Chipset: CPU integrated graphics controller
• Display memory: 1 GB maximum shared memory with 2
GB and above system memory installed
• HDMI: Resolution up to 4096 x 2160 @ 60 Hz refresh rate
• VGA: Resolution up to 1920 x 1200 @ 60 Hz refresh rate
• DP: Resolution up to 4096 x 2160 @ 60 Hz via optional
cable
Ethernet Interface
• Interface:
- LAN1: 10/100/1000Mbps
- LAN2: 10/100/1000/2500Mbps
• Controller:
- PCE-2133: LAN1: Intel
- PCE-2033: LAN1: Intel
Audio
• Line-out
• Mic-in
Storage
• NVMe M.2: 1 (PCE-2133 only)
• SATA: 2 via gold finger to backplane
• mSATA x 1:
- PCE-2133
: mSATA / Mini PCIe by Hardware Auto
detection
- PCE-2033
: mSATA
Mechanical and Environmental
• Dimensions (L x W): 188.6 x 127 mm (7.43" x 5")
• Power Consumption:
Intel Core™ Intel I9-12900E, 32GB DDR5 x 2
® ®
Maximum: DC: 19 ~ 24 V
• Operating Temperature: 0 ~ 45°C (depending on
CPU)
• Weight: 0.38 kg
PCE-2033/2133 Startup Manual 1
I219LM, LAN2: Intel I226V
®
®
I219V, LAN2: Intel I226V
®
®
, 8A ~ 6.5A
DC
