- Page 1 HULALA ITEM NO. TVHM0634 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 1/22...
- Page 2 MAINTAINANCE AND WARNING Keep furniture away from heat. Do not clean furniture with harsh cleansers or polish. Do not use detergents, Solvents, abrasives, spray packs or leather cleaner. Use non-color mild soap with warm water clean spills(Mix 1:10 soap to water) Do not place furniture under direct sunlight, material will possibly fade over time.
- Page 3 ASSEMBLY INSTRUCTIONS 3/22...
- Page 4 PARTS LIST Top panel Bottom panel Back panel Left side panel Middle vertical panel right Middle vertical panel left Right side panel Fixed shelf panel 4/22...
- Page 5 PARTS LIST Side adjustable panel Front rail Middle adjustable panel Drawer front Drawer side left Drawer side right Drawer bottom Drawer back Left door Right door 5/22...
- Page 6 HARDWARE LIST Screw Allen wrench Magnet ø3x15mm Plastic circle Shelf holder Knob bolt Screw ø4x19mm ø3x15mm Bracket Screw Expansion nut ø7x35mm Plastic belt Screwdriver SPARE Screw ø3x15mm Be sure to check all packing material carefully for small parts, which may have come loose inside the carton during shipment.
- Page 7 ASSEMBLY INSTRUCTIONS Step 1 E&F Attach magnet (2) to middle vertical panel left(E) and middle vertical panel right(F) with screw(3). Tight screw with screwdriver(13). 7/22...
- Page 8 ASSEMBLY INSTRUCTIONS Step 2 E&F E&F H&I H&I Attach fixed shelf panel (H) and front rail(I) to middle vertical panel left(E) and middle vertical panel(F) as image. And tight them with allen wrench(1). 8/22...
- Page 9 ASSEMBLY INSTRUCTIONS Step 3 E&F E&F Attach preassemble unit at step 2 to bottom panel(B) , and tight it with Allen wrench(1). 9/22...
- Page 10 ASSEMBLY INSTRUCTIONS Step 4 D&G D&G Attach left side panel(D) and right side panel(G) to preassemble unit at step 3 , and tight it with Allen wrench(1). 10/22...
- Page 11 ASSEMBLY INSTRUCTIONS Step 5 D&E&F&G D&E&F&G Attach top panel(A) to preassemble unit at step 4 and tight it with Allen wrench(1). 11/22...
- Page 12 ASSEMBLY INSTRUCTIONS Step 6 Attach plastic circle(4) to back panel(C ). Attach back panel( C) to the preassemble unit at step 5 with screw (3), tight screw with screwdriver(13). 12/22...
- Page 13 ASSEMBLY INSTRUCTIONS Step 7 shelf holder can be adjusted up or down Insert shelf holder(5) to preassemble unit at step 6 , and attach adjustable shelf (K/J) to it. 13/22...
- Page 14 ASSEMBLY INSTRUCTIONS Step 8 M&N The grooves must be align completely. Attach drawer side left(M) and drawer side right(N) to drawer back (O) , tight it with allen wrench(1),slide drawer bottom side (P) to them. 14/22...
- Page 15 ASSEMBLY INSTRUCTIONS Step 9 M&N The grooves must be align completely. Attach drawer front (L) to preassemble unit at step8, tight it with allen wrench(1). 15/22...
- Page 16 ASSEMBLY INSTRUCTIONS Step 10 female slider male slider × √ Make sure to move the ball bearing to front end, carefully align male and female slides before insert drawer box. Attach drawer to preassemble unit at step 9. 16/22...
- Page 17 ASSEMBLY INSTRUCTIONS Step 11 17/22...
- Page 18 ASSEMBLY INSTRUCTIONS Q&R Step 12 Q&R Q&R Attach left door(Q) and right door(R) to preassemble unit at step 11, attach konb(6) to left door(Q) and right door(R) with bolt(7), tight bolt with screwdriver(13). 18/22...
- Page 19 ASSEMBLY INSTRUCTIONS Step 13 Attach bracket(9) to preassemble unit at step 12 with screw(8), and tight screw with screwdriver(13). 19/22...
- Page 20 ASSEMBLY INSTRUCTIONS Step 14 Drill hole on the wall , and insert expansion nut(10) , then attach bracket(9) to it with screw(11), tight screw with screwdriver(13). 20/22...
- Page 21 ASSEMBLY INSTRUCTIONS Step 15 Furniture Furniture Wall Wall Attach the unit to the wall plastic belt(12) Anti-tipping hardware must be used for this product to avoid tipping and injury. 21/22...
-
Page 22: Warranty
WARRANTY We strive to offer high-quality products, and we also try our best to satisfy each and every customer that orders from us with product or service as needed. We provide 30 days warranty starting from the time you receive the item. Each customer must provide a record of their order such as the order number, or item receipt for any items that are out of the warranty period you may also still receive replacement parts by purchasing them...
