- Page 1 ITEM NO. TVSBSD0455 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 1/20...
- Page 2 MAINTAINANCE AND WARNING Keep furniture away from heat. Do not clean furniture with harsh cleansers or polish. Do not use detergents, Solvents, abrasives, spray packs or leather cleaner. Use non-color mild soap with warm water clean spills(Mix 1:10 soap to water) Do not place furniture under direct sunlight, material will possibly fade over time.
- Page 3 PARTS LIST...
-
Page 4: Explosive View
Explosive View... - Page 5 HARDWARE LIST M6*25mm SPARE Be sure to check all packing material carefully for small parts, which may have come loose inside the carton during shipment.
- Page 6 ASSEMBLY INSTRUCTIONS Prepare the part #7. 1）Separate metal slider to part V and W as the picture show. 2) Attach the metal slider V to the part 7. align the U hole in the metal slider V to the pre-drilled screw hole in part 7, screw in screw E and tighten by screwdriver N.
- Page 7 Prepare the part 5 and 6 (continue) align the hole in the pre-drilled hole in part 5 and 6, insert the wooden dowel D by hand and screw in cam bolt A by screwdriver N. Assemble the part 15 and 16.
- Page 8 Prepare the part 8 and 9. align the hole in part 8 and 9, insert the wooden dowel D by hand, screw in Cam bolt A and tighten by screwdriver N as the picture show. Attach the part 8,9 to the part 4. Align the hole in part 4, insert the nut B into the hole in part 4 as the picture show, then insert the wooden dowel D and Cam bolt A in part 8 and 9 into part 4, tighten the nut B by screwdriver N.
- Page 9 Prepare the part 1. Align the hole in part 1, insert the wooden dowel D by hand, screw in Cam bolt A and tighten by screwdriver X as the picture show. Step 8 Attach the part 1 to the finished part in step 6.
- Page 10 Install the part 10 and 11 into finished part in step 8. 1）Prepare the part 11. install the part Q into part 11 by hand. 2）Slide the part 10 and 11 into the groove in part 8, 9 and 1. 3）Insert the wooden dowel D into part 8 and 9 by hand as the picture show.
- Page 11 O*4 B*4 Attach the part 7 to the finished part in step 10. insert the nut B into part 7, align the wooden dowel D and cam bolt A into part 7, tighten the nut B by screwdriver N. then cover the nut by part O. Slide the part 17 into the groove in part 3, 5, 6 and 7.
- Page 12 Attach the part to the finished part in step 12. Align the hole in the part 2 to the hole in part 5, 6 and 7, insert the wooden dowel in part 5,6 and 7, screw in the screw C and tighten by Allenkey P. J*12 Attach the part 16 to the part 12, then attach the part 12 and 13 to the part 2.
- Page 13 Install the part U. align the hole in part U to the hole in part 12, 13, screw in the screw E and tighten by screwdriver N. DO NOT FULLY TIGHTEN! Assemble the part 14 to the part 12 and 13. Align the hole in the part 14 to the hole in part U, screw in the screw E and tighten by screwdriver N.
- Page 14 Assemble the part F and part hook of anti-collapse R as the picture show. 1） Insert the part F into the space between the part 5,6,10,11 and 17. screw in screw E and tighten by screwdriver N. 2）Align the hole in part R to the part 1, screw in and tighten the screw E by screwdriver N. 14 20...
- Page 15 Install the door. 1) Insert the wheel in part N into the groove in part 2 in 30° angle as the picture show 2) Push the part 18 towards the cabinet, 3) Move the door to the corner, push out the tongue of the part N to hole in part 1 to fix the door.as the picture show 15/20...
- Page 16 Prepare the drawers(1). Align the hole in part 19, screw in and tighten the cam bolt A by screwdriver X. Align the hole in the part 19 to the hole in part H, screw in and tighten the screw G by screwdriver X.
- Page 17 Prepare the drawers(3). Attach the metal slider part W to the part 20 and 21 as the picture show. 1) Find the right direction of metal slider W. Metal slider W has two ends, one is open , another is close .Make sure the close end to the part 19 while install ! 2) Align the U hole in metal part W to the hole in part 20 and 21, screw in and tighten the screw E by screwdriver X...
- Page 18 Use the adjustable nail to keep the cabinet level in case the cabinet is wabbling. Now your cabinet is ready to use. 18/20...
- Page 19 Install the anti-collapse device. 1. Mark the position on the wall, this should be same as the position of R where are on the back of panel 1; Drilled and insert the expandable screw T by hammer; 2.Assemble the part R on the wall. Align the hole in the part R to the expandable screw T, screw in and tighten by screwdriver;...
- Page 20 We strive to offer high-quality products, and we also try our best to satisfy each and every customer that orders from us with product or service as needed. We provide 30 days warranty starting from the time you receive the item. Each customer must provide a record of their order such as the order number, or item receipt for any items that are out of the warranty period you may also still receive replacement...
