WARRANTY
We strive to offer high-quality products, and we also try our
best to satisfy each and every customer that orders from us with
product or service as needed. We provide 30 days warranty
starting from the time you receive the item. Each customer must
provide a record of their order such as the order number, or
item receipt for any items that are out of the warranty period
you may also still receive replacement parts by purchasing them
with our company if they are available.
Are you having difficulty
with assembly? Missing parts?
Please send email with your order No to
customerservice@hulalahome.com
For return, please check the return policy with
the retailer or market place you bought from.
Appreciate your purchasing from us.
Pop up your life by our furniture piece!
ITEM NO. TVSHM0540
NOTE:
This brochure contains IMPORTANT safty info. Please read
and keep for future reference.
Advertisement
Related Manuals for HULALA HOME TVSHM0540
Summary of Contents for HULALA HOME TVSHM0540
- Page 1 Missing parts? Please send email with your order No to customerservice@hulalahome.com For return, please check the return policy with ITEM NO. TVSHM0540 the retailer or market place you bought from. Appreciate your purchasing from us. NOTE: Pop up your life by our furniture piece! This brochure contains IMPORTANT safty info.
- Page 2 PARTS MAINTAINANCE LIST AND WARNING A:Top B:Bottom Keep furniture away from heat. Do not clean furniture with harsh cleansers or polish. Do not use detergents, Solvents, abrasives, spray packs or leather cleaner. Use non-color mild soap with warm water clean spills(Mix 1:10 soap to water) C:Adjustable leg D:Left Side...
- Page 3 PARTS PARTS LIST LIST R: Side Drawer Back I:Left Dust Panel J:Right Dust Panel Q: Middle Drawer Bottom 2pcs K:Back Panel S: Middle Drawer Back T: Side Adjustable Shelf L:Middle Drawer Front 2pcs M: Side Drawer Front N: Drawer Left Side U: Middle Adjustable Shelf V: Left Door 2pcs...
- Page 4 HARDWARE HARDWARE LIST LIST 1111 x1 x1∅ 8#x1-1/2” L616 Cam bol Wood dowel Cam bolt Cam lock ∅ 8x30mm Plastic circle SPARE Screw Magnetic door ∅ 3x15mm Cover catch Wood dowel Cam bolt Cam lock ∅ 8x30mm Screw Screw ∅ 3x15mm Bracket ∅...
- Page 5 ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS Attach left panel(D) and left partitioner (F) to dust panel(I) Attach magnetic door catch(4) to dust panel(I/J) with screw(5), with cam bolt(1) and wood dowel(3) and cam lock(2). Tight and tight them with screwdriver. cam lock with screwdriver. Then cover it with cover(6)
- Page 6 ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS Attach right side panel(E) and right partitioner (G) to dust Attach preassemble unit at step 2 and step 3 to upper front panel(J) with cam bolt(1) and wood dowel(3) and cam lock(2). rail(H)with cam bolt(1) and wood dowel(3) and cam lock(2). Tight cam lock with screwdriver.
- Page 7 ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS Attach adjustable leg(C) to bottom (B) with hand. Attach preassemble unit at step 4 to preassemble unit(5) with cam bolt(1) and wood dowel(3) and cam lock(2). Tight cam lock with screwdriver, then cover it with cover(6)
- Page 8 ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS x 22 Attach back panel (K) to preassemble unit at step 7 with Attach top(A) to preassemble unit at step6 unit with cam screw(5), and attach bracket(8) to preassemble unit at step 7 bolt(1) and wood dowel(3) and cam lock(2). Tight cam lock with screw(7), tight screw with screwdriver.
- Page 9 ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS Attach middle drawer front(L) to preassemble unit at step 9 Attach drawer right side(O) and drawer left side(N) to middle with screw(9), tight it with screwdriver. Then attach handle(10) drawer back(S) with screw(9), tight it with screwdriver, slide to drawer front with bolt(11), tight bolt with screwdriver.
- Page 10 ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS Attach side drawer front(M) to preassemble unit at step 11 Attach drawer right side(O) and drawer left side(N) to side with screw(9), tight it with screwdriver. Then attach handle(10) drawer back(R) with screw(9), tight it with screwdriver, slide to drawer front with bolt(11), tight bolt with screwdriver.
- Page 11 ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS Slider arm Slider bracket Attach drawer to preassemble unit at step 8.
- Page 12 ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS x 12 shelf pin can be adjusted up or down Attach let door(V) and right door(W) to preassemble unit Insert shelf holder(12) to preassemble unit at step 14 , and at step 15. and attach handle(10) to door with bolt(11), attach adjustable shelf (T/U) to it.
- Page 13 ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS 3/16" Drill hole on the wall , and insert anchor(13) , then attach bracket(8) to it with screw(14), tight screw with screwdriver. Attach let door(V) and right door(W) to preassemble unit at step 16. and attach handle(10) to door with bolt(11), tight bolt with screwdriver.
- Page 14 ASSEMBLY INSTRUCTIONS Attach the unit to the wall with tie(15) Furniture Furniture Anti-tipping hardware must be used for this product to avoid tipping and injury. If the unit is not stable , Wall Wall please adjust the adjustable level.
