  • Page 1 HULALA TVYJ0746 ITEM NO. NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/25...
  • Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soap with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
  • Page 3 2PERSONEN 03/25...

  • Page 4: Parts List

    PARTS LIST 04/25...
  • Page 5 PARTS LIST 05/25...

  • Page 6: Hardware List

    HARDWARE LIST Ø4*22 ∅ 5*3*12 Ø1/4 ∅ 4*39mm Ø4*25m* ∅ 4*20mm Ø1/4 6mm*45 TOOL LIST HARDWARE SPARE LIST Ø4*25m* Ø4*25m* Ø1/4 06/25...
  • Page 7 07/25...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP-1 1.picture shows.Use bolt #2 to attach rebound device #9 to side panel F&E， tighten bolts with screwdriver #17. ∅ 5*3*12 08/25...
  • Page 9 ASSEMBLY INSTRUCTIONS STEP-2 1.Insert gasket #15 and #14 in sequence into screw #7, install leg Q on of bottom panel B, ensure the corresponding holes are aligned and fix with screw #7, then tighten the screw with an Allen key #16. 2.Rotate the middle leg R clockwise and fix it on the bottom panel B.
  • Page 10 ASSEMBLY INSTRUCTIONS STEP-3 Insert side panel (I) into panel (E&F),make sure all holes aligned and then tighten it with allen key #16 as picture show. E&F 10/25...
  • Page 11 ASSEMBLY INSTRUCTIONS STEP-4 1.Insert side panel (E&F) into bottom panel (B),make sure all holes aligned and then tighten it with allen key #16 as picture show. 11/25...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP-5 1.Insert side panel (C&D) into bottom panel (B),make sure all holes aligned and then tighten it with allen key #16 as picture show. 12/25...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP-6 1.Insert top panel (A) into the corresponding hole of preassembled step 5 ， make sure all holes aligned and use allen key #16 to tighten it as picture show. C&E 13/25...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP-7 Open the back panel (G),insert back panel (G) into the groove of preassembled step 6,make sure all holes aligned and use screw #6 to attach them，tighten screw #6 with screwdriver #6x28 #6x28 14/25...
  • Page 15 ASSEMBLY INSTRUCTIONS STEP-8 Attention: After installation, adjust the adjustable leveler to keep the cabinet balanced . 15/25...
  • Page 16 ASSEMBLY INSTRUCTIONS STEP-9 Insert shelf holder #8 into the corresponding hole of panel (C)&(D)&(E)&(F) and then attach panel (H) to it. Shelf holder can be adjusted up or down Ø1/4 16/25...
  • Page 17 ASSEMBLY INSTRUCTIONS STEP-10 1.Connect part (N&M) to part O using screw #1 and tighten it with screwdriver #17. Slide in the part (P ) into the groove in part (N&M). make sure they are also in groove in part (O). &...
  • Page 18 ASSEMBLY INSTRUCTIONS STEP-11 and tighten it 1.Connect the (L) connection (N&M) using screw #1 , with screwdriver #17. & 18/25...
  • Page 19 ASSEMBLY INSTRUCTIONS STEP-12 Use bolt #3 to attach handle #10 to panel (L)，tighten bolts #3 with screwdriver 19/25...
  • Page 20 ASSEMBLY INSTRUCTIONS STEP-13 Attention ： When installing the drawer , slide the steel ball slide rail of side panel to the most front as picture show . Female slider Male slider Schematic diagram of slide rail disassembly 20/25...
  • Page 21 ASSEMBLY INSTRUCTIONS STEP-14 1.First , align the salient point of the lower end door spindle (J)&(K) with the corresponding hole of bottom panel(B),and then press the upper end salient point of door spindle (J)&(K) with hand ， finally push it forward to the corresponding hole of top panel (A).
  • Page 22 ASSEMBLY INSTRUCTIONS STEP-15 to attach part #13 to back panel (G),tighten screw #5 with Use screw screwdriver #17 . 22/25...
  • Page 23 ASSEMBLY INSTRUCTIONS #11 x4 STEP-16 Install the anti-collapse device. 2.Mark the position on the wall, that corresponds to the location of part#13 on the back of panel (G); Drill and insert the expandable screw by hammer. Assemble the part #13 to the wall. Align the hole in the part #13 with the expandable screw #11 , use screw #4 to attach it and tighten by screwdriver#17.
  • Page 24 ASSEMBLY INSTRUCTIONS #12 x2 STEP-17 Let the plastic belt #12 pass through the both part #13 and pull tightly. #12x2 #12x2 24/25...

  • Page 25: Warranty

    WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
