- Page 1 ITEM NO. TVSBSD0454 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 1/20...
- Page 2 MAINTAINANCE AND WARNING Keep furniture away from heat. Do not clean furniture with harsh cleansers or polish. Do not use detergents, Solvents, abrasives, spray packs or leather cleaner. Use non-color mild soap with warm water clean spills(Mix 1:10 soap to water) Do not place furniture under direct sunlight, material will possibly fade over time.
- Page 3 PARTS LIST...
-
Page 4: Explosive View
Explosive View... - Page 5 HARDWARE LIST SPARE Be sure to check all packing material carefully for small parts, which may have come loose inside the carton during shipment.
- Page 6 ASSEMBLY IN STRUCTIONS Preparation for middle leg and doors 1) Assemble the middle leg. Align the hole in part 16 and the screw hole in part 15, screw in and tighten the screw K by allenkey P. 2) Attach the part U to the part 11. Align the hole in part U to the part 11, then screw in and tighten the screw E by screwdriver X.
- Page 7 Attach the part 3 and 4 to the part 1. 1）Insert the nut B into the hole in part 3 and 4 as the picture show. 2）Align the hole in part 3 and 4, insert the wooden dowel D and cam bolt A in part 1 into the part 3 and 4, then tighten the nut B by screwdriver X.
- Page 8 Connect the part 5 and 6 to the part 8. 1) Insert the nut B into the hole in part 8 as the picture show. 2) Align the hole in the part 8, insert the wooden dowel D and cam bolt A in part 5 and 6 into the part 8, then tighten the nut B by screwdriver X.
- Page 9 Attach part 9 and 10 to finished part in step 6. 1) Insert the part W into the part 9 and 10 bu hand. 2) Slide the part 9 and 10 into the groove in part 1, 3,4,5 and 6. 9 20...
- Page 10 Attach the part 2 to the finished part in step 7. 1) Align the hole in part 2, insert the wooden dowel B in the part 3,4,5 and 6 into the part 2 2) Align the hole in part 2 to the hole in part 3,4,5 and 6, Screw in and tighten the screw C by Allenkey P as the picture show.
- Page 11 J*12 Attach the leg frame. Align the hole in part 12 and 13 to the hole in part 2, screw in and tighten the screw J by allenkey P. DO NOT FULLY TIGHTEN! Attach the middle leg to the leg frame. Align the hole in part 16 to the hole in part 12, screw in and tighten the screw I by allenkey P.
- Page 12 Assemble the part V to the leg frame. 1) Insert the edge of part V into the space in part 12 and 13 2) Align the hole in part V to the hole in part 12 and 13, screw in and tighten the screw E by screwdriver X.
- Page 13 Assemble the legs. 1）Align the hole in part 14 to the hole in part V, screw in and tighten the screw L by allenkey P. 2）After check the all screw in right position, fully tighten the screws I, J E in sequence. 13 20...
- Page 14 Assemble the part F and part hook of anti-collapse R as the picture show. 1）Insert the part F into the space between the part 1,2, 3, 4,5,6, screw in screw E and tighten by screwdriver X. 2）Align the hole in part R to the part 1, screw in and tighten the screw E by screwdriver X. 14 20...
- Page 15 Insert the part Q into the hole in part 3, 4,5,6 by hand as the picture show. Align the hole in part U ,screw in and tighten the screw E by screwdriver X 15/20...
- Page 16 Install the part N on the part 3 and 4 as the picture show. Align the hole in part N to the hole in part 3 and 4, screw in and tighten the screw E by screwdriver X. 16/20...
- Page 17 Insert the part 7 into the position above the part Q. 17/20...
- Page 18 Use the adjustable nail to keep the cabinet level in case the cabinet is wabbling. Now your cabinet is ready to use. 18/20...
- Page 19 Install the anti-collapse device. 1. Mark the position on the wall, this should be same as the position of R where are on the back of panel 1; Drilled and insert the expandable screw T by hammer; 2.Assemble the part R on the wall. Align the hole in the part R to the expandable screw T, screw in and tighten by screwdriver;...
- Page 20 We strive to offer high-quality products, and we also try our best to satisfy each and every customer that orders from us with product or service as needed. We provide 30 days warranty starting from the time you receive the item. Each customer must provide a record of their order such as the order number, or item receipt for any items that are out of the warranty period you may also still receive replacement...
