- Page 1 HULALA ITEM NO.TVSD0826 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/25...
- Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
-
Page 3: Explosive View
EXPLOSIVE VIEW 2PERSON 03/25... -
Page 4: Parts List
PARTS LIST 04/25... -
Page 5: Hardware List
HARDWARE LIST Ø Ø M7*50mm M6*50mm 6*35mm Ø15*11mm 8*30mm M6*40mm M4*35mm M3.5*14mm TOOL LIST HARDWARE SPARE LIST Ø M6*50mm M6*40mm 6*35mm M4*35mm M3.5*14mm M7*50mm 05/25... - Page 6 ASSEMBLY INSTRUCTIONS STEP-1 Use screw #17 to attach part #14 to the corresponding hole of top panel(A),tighten screw #4 with screwdriver #20.And then slide the rebounder #14 into the rebounder base as picture show. The rear protrusion of therebound member should facein the direction of the backpanel.
- Page 7 ASSEMBLY INSTRUCTIONS STEP-2 Screw bolt #1 into top panel (A) ,tighten bolt #1 with screwdriver #20.Insert wooden dowel #2 into side panel (E)&(F),and then screw bolt #1 into the corresponding hole of side panel (E)&(F),tighten bolt #1 with screwdriver #20. E&F Ø...
- Page 8 ASSEMBLY INSTRUCTIONS STEP-3 Insert panel (G) into the corresponding hole of side panel (E),and then insert cam bolt #3 into the corresponding hole of panel (G)，tighten cam bolt #3 with screwdriver #20.Insert panel (F) into the corresponding hole of preassemble panel (G),and then insert cam bolt #3 into the corresponding hole of panel (G)，tighten finally stick paster #4 to it for look nice cam bolt #3 with screwdriver #20,...
- Page 9 ASSEMBLY INSTRUCTIONS STEP-4 Stick paster #18 to the corresponding hole of panel(I) . Insert rubber ring into the corresponding hole of panel (I) and then carefully align and slide panel (I) into the groove along rear edge of pre-assembled step 3. &...
- Page 10 ASSEMBLY INSTRUCTIONS STEP-5 Insert wooden dowel #2 into the corresponding hole of panel (E)&(F),and then insert panel (A) into the preassemble unit at step 4 ,and then insert cam bolt #3 ,tighten cam bolt #3 with screwdriver #20,finally stick paster #4 to it for look nice. &...
- Page 11 ASSEMBLY INSTRUCTIONS & & & Ø Ø15*11mm 8*30mm 11/25...
- Page 12 ASSEMBLY INSTRUCTIONS STEP-7 Insert rubber ring #18 into the corresponding hole of panel (I) and then carefully align and slide panel (I)&(H) into the groove along rear edge of pre-assemble unit at step 6. 12/25...
- Page 13 ASSEMBLY INSTRUCTIONS STEP-8 Insert wooden dowel #2 into the corresponding hole of panel (C)&(E)&(F)&(D). Insert panel (B) into the preassemble unit at step 7，make sure all holes aligned ， then use bolt #5 to attach them，tighten bolt #5 with allen key #19. Ø...
- Page 14 ASSEMBLY INSTRUCTIONS STEP-9 Use bolt #7 to attach part (N) to part (M), make sure all holes aligned and tighten all bolts with allen key #19 . M6*40mm 14/25...
- Page 15 ASSEMBLY INSTRUCTIONS STEP-10 (N)&(M) to bottom panel (B) Use bolt #6 to attach preassemble leg allen key #19.And screw the middle leg(O) into tighten bolt #6 with the bottom panel (B). M6*50mm 15/25...
- Page 16 ASSEMBLY INSTRUCTIONS STEP-11 Attention: Before the next step, adjust the feet of the locker to keep it level. Attention: Before the next step, adjust the feet of the locker to keep it level. 16/25...
- Page 17 ASSEMBLY INSTRUCTIONS STEP-12 Use screw #17 to attach plastic shelf #9 to panel(A)&(B)&(C)&(D)&(E) &(F)&(G),tighten screw #17 with screwdriver #20 M3.5*14mm 17/25...
- Page 18 ASSEMBLY INSTRUCTIONS STEP-13 Insert shelf holder #8 into the corresponding hole of panel(C)&(D)&(E)&(F),and then attach adjustable shelf (J) to it. Shelf holder can be adjusted up or down & & & 18/25...
- Page 19 ASSEMBLY INSTRUCTIONS STEP-14 (K)&(L),tighten screw 1.Use screw #17 to attach hinge #12 to door #17with screwdriver #20. 2.Attach the gasket#15 to the door using screws#17,tighten screw #17with screwdriver #20. M3.5*14mm 19/25...
- Page 20 ASSEMBLY INSTRUCTIONS STEP-15 Use screw #17 to attach preassemble hinge #12 to panel (C)&(D) tighten screw #17 with screwdriver #20. M3.5*14mm 20/25...
- Page 21 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS HINGE ADJUST Concealed hinges are three-way adjustable: Horizontal by screw adjustment! Concealed hinges are three-way adjustable: In-and-out by loosening the hinge arm mounting screw or via cam adjustment! Concealed hinges are three-way adjustable: Vertical via slots in the mounting plate or via cam adjustment! Hinge adjustment method...
- Page 22 ASSEMBLY INSTRUCTIONS M3.5*14mm STEP-16: Use screw #17 to plastic bracket #10 to panel (A),tighten screw #17 with screwdriver #20. 22/25...
- Page 23 ASSEMBLY INSTRUCTIONS M4*35mm STEP-17: 1. Mark the position on the wall, that corresponds to the location of bracket on the top panel (A); Drill and insert the expandable screw by hammer. 2. Assemble the bracket to the wall. Align the hole in the bracket with the expandable screw , use screw...
- Page 24 ASSEMBLY INSTRUCTIONS STEP-18 3. Let the plastic belt pass through bracket and pull tightly. If you encounter difficulties during the installation process, please watch the installation video! ×2 24/25...
-
Page 25: Warranty
WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
