- Page 1 ITEM NO. DKHN0066-1 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference.
-
Page 2: Warranty
WARRANTY We strive to offer high-quality products, and we also try our best to satisfy each and every customer that orders from us with product or service as needed. We provide 30 days warranty starting from the time you receive the item. Each customer must provide a record of their order such as the order number, or item receipt for any items that are out of the warranty period you may also still receive replacement parts by purchasing them... - Page 3 MAINTAINANCE AND WARNING Keep furniture away from heat. Do not clean furniture with harsh cleansers or pol ish. Do not use detergents, Solvents, abrasives, spray packs or leather cleaner. Use non-color mild soap with warm water clean spills(Mix 1:10 soap to water) Do not place furniture under direct sunlight, material will possibly fade over time.
- Page 4 PARTS LIST Front bottom Check all parts according to parts and hardware list make sure all parts present before assembly as some small parts may come loose during transit. Place all parts on clean padded surface and line up according to sequence of assembly.
-
Page 5: Extra Parts
HARDWARE LIST ∅15*12 1/4*38 M6x15 M6x35 6pcs 3pcs 3pcs 12pcs 46pcs 16" ∅4*40 ∅3.5*14 ∅8*30 ∅7*36 M6*25 12pcs 3pcs 8pcs 46pcs 24pcs 6pcs 6pcs SPARE EXTRA PARTS ∅15*12 ∅3.5*14 ∅8*30 ∅7*36 M6x15 M6x35 3pcs ∅4*40 M6*25 Be sure to check all packing material carefully for small parts, which may have come loose inside the carton during shipment. - Page 6 ASSEMBLY INSTRUCTIONS open and place all parts on a clean, no-marring surface. STEP 1: Ax12 Use bolt A and allen Key B to connect stretchers 3 and 4 with side frames 1&2. Make sure all parts sets leveled then fasten all bolts to secure.
- Page 7 ASSEMBLY INSTRUCTIONS STEP 2: Ix24 Use wood screw I and philips head screw driver to attach drawer slides K to end panel and partition 11&12&6&7.
- Page 8 ASSEMBLY INSTRUCTIONS STEP 3: Jx12 Turn the center partition 6&7 upside down,use philips head screw driver to fasten bolt F on inserts of back panel 8, bottom panel 9&10, then insert the bolts G on back panel 8 through end holes of center partition 6&7, put on cam unit F and fasten to secure.
- Page 9 ASSEMBLY INSTRUCTIONS STEP 4: Fx10 Gx10 Use philips head screw driver to fasten bolt G on inserts of end panel 11 & 12, back panel 8, then insert the bolts G on end panel 11 & 12 through end holes of bottom panel 9 & 10, put on cam unit F and fasten to secure.
- Page 10 ASSEMBLY INSTRUCTIONS STEP 5: Fx16 Gx16 Use philips head screw driver to fasten bolt G on inserts of table top 13, Insert all dowels H to holes on back side of table top 13 then insert the bolts G on table top 13 through end holes of end/back/bottom panels assembly (6&7&8&9&10&11&12), put on cam unit F and fasten to secure.
- Page 11 ASSEMBLY INSTRUCTIONS STEP 6: Use philips head screw driver and bolt C to attach the metal frame assembly to bottom of upper unit, make sure all edges align then fasten to secure.
- Page 13 ASSEMBLY INSTRUCTIONS STEP 8: Pull out the drawer slides and carefully align the pin on drawer slides with the hole on drawer box then fix the clip to secure the drawer. Whenever drawer adjustment of drawers needed, please spin the pin on drawer slides to set it level.
- Page 14 ASSEMBLY INSTRUCTIONS STEP 9: Switch the button with hand to slightly adjust the height of drawer sides in order to sent the drawer leveled. Insert the plastic clip M through the slide to the hole on drawer sides.
- Page 15 ASSEMBLY INSTRUCTIONS Assembly completed.
