- Page 1 ITEM NO. TVSBSD0389 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 1/16...
- Page 2 MAINTAINANCE AND WARNING Keep furniture away from heat. Do not clean furniture with harsh cleansers or polish. Do not use detergents, Solvents, abrasives, spray packs or leather cleaner. Use non-color mild soap with warm water clean spills(Mix 1:10 soap to water) Do not place furniture under direct sunlight, material will possibly fade over time.
- Page 3 PARTS LIST 2 x1 1 x1 3 x1 4 x1 5 x1 6 x1 7 x1 8 x2 9 x1 10 x1 12 x1 11 x1 16 x1 13 x1 15 x1 14 x1 18 x1 19 x1 17 x2 3/16...
-
Page 4: Explosive View
Explosive View 4/16... - Page 5 HARDWARE LIST 15mm M6*35mm M7*50mm 8*30mm 4*35mm 3.5*14mm M6*50mm M4*18mm SPARE Be sure to check all packing material carefully for small parts, which may have come loose inside the carton during shipment. 5/16...
- Page 6 ASSEMBLY INSTRUCTIONS Preparing part 1. align the hole in the part 1, insert the wooden dowel D by hand, screw and tighten the A by screwdriver. Preparing part 5 and 6. align the hole in the part 5 and 6, insert thewooden dowel D by hand, screw and tighten the A by screwdriver.
- Page 7 Connect the part 7 with part 5 and 6. align the hole in the part 7, insert the bolt A and wooden dowel D in part 5 and 6 into part 7. tighten with the nut B. cover the screw hole after installation is finished.
- Page 8 slide in the part 8 into the groove in part 3, 5 ,and 4,6. make sure they are also in groove in part 1. Slide in the part 10 into the groove 5,6 and 7. Connect the part 2 with the finished part. Insert the wooden dowel D into the part 3,4,5,6 as the picture show.
- Page 9 Preparing the leg frame. Align the hole in the part 18 and the hole in the part 17, screw and tighten the screw M by Allenkey P. then screw in the hardware O in the part 17 as the picture show. connect the leg frame to the cabinet.
- Page 10 insert the hardware F into the part 8, 9,10 as the picture show, screw in the E and fully tighten. Installing the hardware Q on the part 1 both sides as the picture show. Preparing the drawers. Align the holes in the part 12, screw bolt A into the part 12 by screwdriver.
- Page 11 Connect the part 13 and 14 to the part 15. screw in and tighten the screw G by screwdriver. Then , slide in the part 16 into the groove in part 13, 14 and 15. next, connect the part 12 to the drawer frame and tighten the nut B and cover the hole by N 11/16...
- Page 12 slide in the drawer into cabinet as the picture show. You can adjust the distance between drawer and the cabinet by adjust the metal slider to fit drawer if you need to do this. 12/16...
- Page 13 Finishing the anti-collapse device. Move the cabinet against the wall to mark the same height with Q, then drill the marked position , insert the screw I. next fix the Q on the wall. Last, plasict belt H go through the two Q and tighten to secure.
- Page 14 Preparing the doors. 1, Attach the part J on the part 11 and 19. align the holes on the J to the holes in the part 11 and 19, screw in and tighten the screw E by screwdriver. 2, Attach the door on the cabinet. Align the hole in the part J on the part 11 and 19 to the holes in the part 3 and 4, screw in and tighten screw E by screwdriver as the picture show.
- Page 15 Now your cabinet is ready to use. Assembly completed 15/16...
-
Page 16: Warranty
WARRANTY We strive to offer high-quality products, and we also try our best to satisfy each and every customer that orders from us with product or service as needed. We provide 30 days warranty starting from the time you receive the item. Each customer must provide a record of their order such as the order number, or item receipt for any items that are out of the warranty period you may also still receive replacement...
