Fuji Electric FVR-E11S-7EN Instruction Manual

Low noise high performance inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Single-phase 200V input
Three-phase 400V input
Thank you for purchasing our FVR-E11S series inverter.
• This product is designed to drive a three-phase induction motor. Read through this
instruction manual and be familiar with the handling method for correct use.
• Improper handling blocks correct operation or causes a short life or failure.
• Have this manual delivered to the final user of the product. Keep this manual in a
safe place until the inverter is discarded.
• For the usage of optional equipment, refer to the manuals for optional equipment.
Fuji Electric Co., Ltd.
Fuji Electric FA Europe GmbH, Germany, Tel +49-69-669029-0,
Fax +49-69-669029-58, info_inverter@fujielectric.de
INSTRUCTION MANUAL
Low noise high performance inverter
Caution
r
FVR-E11S-7EN
FVR-E11S-4EN
INR-SI47-0627a-E
