Fuji Electric FRENIC 5000G11S/P11S Instruction Manual

High-performance, low-noise inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

High-Performance, Low-Noise Inverter
General-Purpose Industrial Machines
230V Series
0.25HP/FRNF25G11S-2UX
to 125HP/FRN125G11S-2UX
460V Series
0.50HP/FRNF50G11S-4UX
to 600HP/FRN600G11S-4UX
Fuji Electric FA Components & Systems Co., Ltd.
Fuji Electric Corp of America
Instruction Manual
FRENIC 5000G11S/P11S
Fans and Pumps
230V Series
7.5HP/FRN007P11S-2UX
to 150HP/FRN150P11S-2UX
460V Series
7.5HP/FRN007P11S-4UX
to 800HP/FRN800P11S-4UX
CAUTION
！
Read all operating instructions before
installing, connecting (wiring),
operating, servicing, or inspecting the
inverter.
Ensure that this instruction manual is
made available to the final user of the
inverter.
Store this manual in a safe,
convenient location.
The product is subject to change
without prior notice.
INR-SI47-1206-E
