Summary of Contents for Origin Acoustics MOS36SUB
- Page 1 MOS36SUB MINIMAL OPENING SUBWOOFER•INSTALLATION MANUAL...
-
Page 2: Table Of Contents
1. Introduction 5. MOS36SUB Trim-Ring Kit Overview 6. Typical Parts Order Thank you for choosing the Origin MOS36SUB Minimal Subwoofer, built to enhance the 7. MOS36SUB Finish Trim Kit listening experince of our Minimal Opening System™, a revolutionary fully in-ceiling audio 8. -
Page 3: Mos36Sub Specifications
MOS36SUB INSTALLATION USER MANUAL MOS36SUB INSTALLATION USER MANUAL 2. MOS36SUB Subwoofer Specifications SPECIFICATION MOS36SUB System Type Minimal Opening Subwoofer Driver Components Two 61/2'' Poly Cone Subwoofers Crossover DSP Recommended LPF 160Hz or less 24 dB BW Frequency Response 31Hz - 250Hz [ - 10 dB]... -
Page 4: What's Included
MOS36SUB INSTALLATION USER MANUAL MOS36SUB INSTALLATION USER MANUAL 3. What’s Included 5. MOS36SUB Trim Ring Kit Overview A. SPACERS B. TRIM RINGS B. TRIM RINGS GRILLES Start Guide MOS36SUB TRIM RING KIT Grille Pick Grille Adhesives C. SQUARE TRIM ADAPTER RING 6. - Page 5 MOS36SUB INSTALLATION USER MANUAL MOS36SUB INSTALLATION USER MANUAL 3.94in 100.00 100.00mm 100.00 3.82in 97.00mm .25in 7. MOS36SUB Trim Ring Kit 6.35mm B. Trim Ring Options: Round Trim Rings The Trim Ring Kit includes the following pieces: 5.12in 130.00 130.00mm 130.00 3.94in 3.74in...
- Page 6 MOS36SUB INSTALLATION USER MANUAL MOS36SUB INSTALLATION USER MANUAL E. Round Trim Kit Set Up F. Square Trim Kit Set Up A. SPACERS x 3 There are 3 included spacer pieces: A1. 1/2 in. (12.70 mm) B. SQUARE TRIM RINGS A2. 1/4 in. (6.35 mm) A3.
-
Page 7: Mos36Sub Mounting Steps
These temporary holders will help you hold up the MOS36SUB and make the speaker mount flush to the future drywall. Using a level, check that your temporary... - Page 8 MOS36SUB INSTALLATION USER MANUAL MOS36SUB INSTALLATION USER MANUAL 3. Securely fix the rail brackets to the joists. 5. Ensure the face of the speaker is plumb with the joists. Use a drill and the included screws. Ensure each the screws on each side of the rails are evenly inserted, for a level positioning.
- Page 9 MOS36SUB INSTALLATION USER MANUAL MOS36SUB INSTALLATION USER MANUAL 7. Drywalling Steps: Place the Placeholder Sponge inside the Port Tube Opening, before installing the drywall, to protect the cut-out hole & port from any debris during the drywalling Use the cut-out template to mark the cut-out for the Trim Ring on the drywall/ process.
- Page 10 MOS36SUB INSTALLATION USER MANUAL MOS36SUB INSTALLATION USER MANUAL Apply drywall/ surface material, plaster & paint, using mesh tape to cover any installation seams. Apply joint compound and level out compound to conceal SQUARE TRIM KIT seams. Make sure to mud up to the rim of the trim ring spacer. Then remove placeholder sponge.
- Page 11 MOS36SUB INSTALLATION USER MANUAL MOS36SUB INSTALLATION USER MANUAL SQUARE TRIM KIT 9. Lastly, to complete the installation, use the pieces of included adhesive tack, to secure the press grille in place. The grille can be spray painted to better match the ceiling color and environment, prior to being attached.
-
Page 12: Return Process
9. Warranty Coverage - 5 Year Limited Warranty Not Covered by Warranty Origin Acoustics warrants to the original retail purchaser only that for a period of • Accidental damage Five (5) years from the original date of purchase. This Origin Acoustics product •... -
Page 13: Troubleshooting
If you are considering settings on both the amplifier and the television/computer/CD returning the product, it’s required that you contact Origin Acoustics prior to any player/etc. return attempts. This way we can determine if the issue can be resolved without... - Page 14 Rev A • 11-23-22 6975 S Decatur BLVD, Las Vegas, NV 89118 • www.originacoustics.com • 844-674-4461 ©2022 Origin Acoustics. All copyrighted, trademarked and patented elements mentioned herein are the sole property of Origin Acoustics.
