- Page 1 SUB Series Bassic Collection Installation Manual SUB12, SUB10, SUB8, SUBV10...
-
Page 2: Table Of Contents
Table of Contents Introduction Specifications What’s Included Features Before You Begin Important Safety Instructions Power Connection Audio Connection: LFE, Line Output, Speaker Wire Alternative High-Level Wire Options Powering on Your Subwoofer Subwoofer Controls: Level, Crossover, Phase Switch Subwoofer Placement: Main Channel & Wall or Corner Cleaning &... -
Page 3: Introduction
Introduction Thank you for purchasing the Bassic SUB Subwoofer. At Origin Acoustics, we take pride in providing you with a high quality product. All of Origin Acoustics’ speakers are designed to have excellent sound quality, longevity, and a simple installation process. -
Page 4: Specifications
Specifications Model SUB12 SUB10 Part Number SBXSUB1200800 SBXSUB100600 Woofer Cone Aluminum Aluminum Woofer 12” (305mm) 10” (254mm) Diameter Amplifer Pow- Class D 250 Watts Class D 150 Watts er (RMS) Frequency 17 Hz ± 3dB 26 Hz ± 3dB Response Power 25 - 140 Watts 25 - 125 Watts... - Page 5 Specifications Model SUB8 SUBV10 Part Number SBXSUB80400 SBXSUBV100600 Woofer Cone Aluminum Aluminum Woofer 8” (203mm) 10” (254mm) Diameter Amplifer Pow- Class D 100 Watts Class D 150 Watts er (RMS) Frequency 32 Hz ± 3dB 32 Hz ± 3dB Response Power 25 - 110 Watts 25 - 110 Watts...
-
Page 6: What's Included
What’s Included Subwoofer Grille AC Cord Features • Front Panel Volume, Crossover Frequency & Phase Controls • Aluminum Cone & Rubber Surround • Slot-Loaded, Front Firing Ports (Sealed on 8”) • Magnetically Secured Grille • Voltage Switch • High & low Level Inputs •... -
Page 7: Before You Begin
Before You Begin • Verify the power switch is in the OFF position before making any connections; when making connections, make them securely. Failure to do so may result in noise, poor performance, or damage to connected equipment. • Bundling power cords with subwoofer or speaker cables may produce un- wanted hum in your system. - Page 8 • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.
-
Page 9: Power Connection
• Due to the weight of our SUB10 and SUB12 subwoofers, we recommend hav- ing two people perform any unboxing, moving, or positioning of the unit to avoid injury or damage to your floor or the subwoofer. • Do not connect the power cord to your subwoofer until all other connections are made. -
Page 10: Audio Connection: Lfe, Line Output, Speaker Wire
Before plugging in your power cord, verify the voltage switch is set at 115V for US operation, or 230V for most other countries. Plug the female-terminated end of the power cord into the Power Cord Connector marked “AC INPUT,” located on the subwoofer’s rear panel. Then, plug the male end into a grounded wall socket. - Page 11 or other component lacking a subwoofer or LFE output, you can use the Left and Right Variable Line Outputs, if available. (Note: Using a Fixed line output is not recommended, since your subwoofer will stay at a “fixed” volume level regardless of your system’s main volume setting).
-
Page 12: Alternative High-Level Wire Options
Alternate High-Level Wiring Options If your front speakers have already been installed into the wall and/or your receiv- er or amplifying component has two pairs of main, front-channel speaker termi- nals, wire one pair of terminals to the subwoofer and the other pair to your main speakers;... -
Page 13: Subwoofer Controls: Level, Crossover, Phase Switch
Subwoofer Level Control Underneath your subwoofer’s cloth grille are two round knobs and one toggle switch. The first knob, labeled “LEVEL”, adjusts the subwoofer’s volume. If the com- ponent sending signal to your subwoofer has its own bass management features, this knob can be set somewhere in the middle of its range so that the subwoofer’s output level is controlled by your surround receiver, amplifier, or processor. - Page 14 subwoofer by ear, listening for the smoothest bass that is devoid of any significant peaks or valleys in its overall response—i.e., without too much or too little bass at certain frequencies. Note: This control is bypassed when using the LFE input on your subwoofer. Subwoofer Phase Switch The switch in between the knobs, labeled PHASE, adjusts the phase of the sub- woofer’s output waveform in relation to your main speakers.
-
Page 15: Subwoofer Placement: Main Channel & Wall Or Corner
0 (up) position. Subwoofer Placement Though your Origin Acoustics subwoofer will provide high-quality, high-impact bass from a wide variety of locations, its placement in the room can greatly af- fect its performance. -
Page 16: Cleaning & Care
Proximity Placement to a Wall or Corner If space allows, try experimenting with boundary loading your subwoofer: It can significantly increase bass impact, lower cone excursion, and power demands. Placing it near a wall increases bass output; placing it in a corner maximizes out- put;... -
Page 17: Troubleshooting
Troubleshooting If possible, it’s often good to try to isolate the problem first. For example, if you’re playing a DVD on a television and there’s no sound, try connecting an MP3 player to the system to see if that works. If it does work, then the problem is with the tele- vision, DVD player, or the cables connecting them. -
Page 18: Technical Assistance
If you are considering returning the product, it’s required that you contact Origin Acoustics prior to any return at- tempts. This way we can determine if the issue can be resolved without returning the product, or if needed we can provide instructions and support for the return process. -
Page 19: Warranty
Limited Lifetime Warranty Origin Acoustics warrants to the original retail purchaser only that this Origin Acoustics product will be free from defects in materials and workmanship, pro- vided the speaker was purchased from an Origin Acoustics authorized dealer. If the product is determined to be defective, it will be repaired or replaced at Ori- gin Acoustics’... -
Page 20: Return Process
Before making any return attempts, it is required that you first contact Origin Acoustics. Return product to Origin Acoustics or your dealer, either in person or by mail. It’s preferable if the product is returned in the original packaging. If this isn’t possible, the customer is responsible for insuring the shipment for the full value of the product. - Page 22 • 844-674-4461 ©2017 Origin Acoustics...
