MOS36SUB
MINIMAL OPENING SUBWOOFER•INSTALLATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOS36SUB and is the answer not in the manual?

Questions and answers

Related Manuals for Origin Acoustics MOS36SUB

Summary of Contents for Origin Acoustics MOS36SUB

  • Page 1 MOS36SUB MINIMAL OPENING SUBWOOFER•INSTALLATION MANUAL...

  • Page 2: Table Of Contents

    MOS36SUB INSTALLATION USER MANUAL Table of Contents 1. Introduction 2. MOS36SUB Specifications 3. What’s Included 4. Required Tools 5. MOS36SUB Trim Ring Kit Overview 6. Typical Parts Order 7. MOS36SUB Trim Ring Kit Specifications 8. MOS36SUB Mounting Steps 9. Troubleshooting 10. Technical Assistance 11.

  • Page 3: Introduction

    MOS36SUB INSTALLATION USER MANUAL 1. Introduction Thank you for choosing the Origin MOS36SUB Minimal Subwoofer, built to enhance the listening experince of our Minimal Opening System™, a revolutionary fully in-ceiling audio system that mimics the appearance of 4'' designer lighting.

  • Page 4: Mos36Sub Specifications

    MOS36SUB INSTALLATION USER MANUAL 2. MOS36SUB Subwoofer Specifications SPECIFICATION MOS36SUB System Type Minimal Opening Subwoofer Driver Components Two 61/2'' Poly Cone Subwoofers Crossover DSP Recommended LPF 160Hz or less 24 dB BW Frequency Response 31Hz - 250Hz [ - 10 dB]...
  • Page 5 MOS36SUB INSTALLATION USER MANUAL *All product specifications are subject to change. Please refer to the dealer portal for the latest information.

  • Page 6: What's Included

    MOS36SUB INSTALLATION USER MANUAL 3. What’s Included MINIMAL OPENING COLLECTION When you have decided on the location for the speaker, trace this template lightly in pencil where the hole should be. Punch out either the Round or MOS36SUB MINIMAL OPENING SUBWOOFER Square Template, according to your preferred trim.

  • Page 7: Mos36Sub Trim Ring Kit Overview

    MOS36SUB INSTALLATION USER MANUAL 5. MOS36SUB Trim Ring Kit Overview A. SPACERS B. TRIM RINGS B. TRIM RINGS GRILLES C. SQUARE TRIM ADAPTER RING 6. Typical Parts Order MOS36SUB SQUARE ROUND TRIM-RING SPACERS [A] TRIM RINGS [B] SQUARE TRIM ADAPTER RING [C] ®...

  • Page 8: Mos36Sub Trim Ring Kit Specifications

    MOS36SUB INSTALLATION USER MANUAL MOS36K INSTALLATION USER MANUAL MOS36K INSTALLATION USER MANUAL in ] in ] 7. MOS36SUB Trim Ring Kit Specifications 7. MOS36K Trim Ring Kit 7. MOS36K Trim Ring Kit 6.35 mm 6.35 mm The Trim Ring Kit includes the following pieces:...
  • Page 9 MOS36SUB INSTALLATION USER MANUAL MOS36K INSTALLATION USER MANUAL in ] 15/16 100 mm in ] 15/16 100 mm B. Trim Ring Options: Round Trim Rings B. Trim Ring Options: Round Trim Rings in ] 130 mm in ] 130 mm...
  • Page 10 MOS36SUB INSTALLATION USER MANUAL MOS36K INSTALLATION USER MANUAL E. MOS36SUB Round Trim SetUp 8a. MOS36K Round Trim SetUp A. SPACERS A. SPACERS There are 3 included spacer pieces: There are 3 included spacer pieces: A1. Spacer: in. (3.18 mm) Depth A1.
  • Page 11 MOS36SUB INSTALLATION USER MANUAL MOS36K INSTALLATION USER MANUAL F. MOS36SUB Square Trim SetUp 8a. MOS36K Round Trim SetUp MOS36K INSTALLATION USER MANUAL 8b. MOS36K Square Trim SetUp: A. SPACERS A. SPACERS There are 3 included spacer pieces: There are 3 included spacer pieces: A1.

  • Page 12: Mos36Sub Mounting Steps

    (Drywall screws not included). At least 3'' apart These temporary holders will help you hold up the MOS36SUB and make the speaker mount flush to the future drywall. Using a level, check that your temporary holders are evenly level, adjusting as needed.
  • Page 13 MOS36SUB INSTALLATION USER MANUAL B. Adjust the rails, as neccessary, to fit ceiling joists. Place MOS36SUB in desired final location. Ensure the rail ends are turned outwards. Then, using a Phillips screwdriver, loosen the screws on each side of the system rails, and extend them so they reach the ceiling joists.
  • Page 14 MOS36SUB INSTALLATION USER MANUAL C. Securely fix the rail brackets to the joists. Use a drill and the included screws. Ensure each the screws on each side of the rails are evenly inserted, for a level positioning. 5 ” 5 ”...
  • Page 15 MOS36SUB INSTALLATION USER MANUAL E. Ensure the face of the speaker is plumb with the joists. F. Speake wire connection: To connect the speaker wire, strip approximately 3/16’’ (5mm) of the insulation off each wire, and to avoid stray strands, twist them at the end. To connect the ceiling speaker wire to the Terminal Connector on the Subwoofer module, push down on each connector, and insert each wire into the opening with the correct polarity.
  • Page 16 MOS36SUB INSTALLATION USER MANUAL G. Cut-Out Steps: Use the cut-out template to mark the cut-out for the Trim Ring on the drywall/ surface material. Trace along the inside of the Cut-Out Template, then use a keyhole or drywall saw to cut out the hole.
  • Page 17 MOS36SUB INSTALLATION USER MANUAL H. Installing Flanged or Flush Trims: The Flanged and Flush trims can be added to the cut out, without drywalling over. If the Port Tube cover does not reach the edge of the drywall, or if using sheetrock that is thicker than ½’’...
  • Page 18 MOS36SUB INSTALLATION USER MANUAL • Installing Flanged Trim SPACERS SPACERS FLANGED ROUND TRIM FLANGED ROUND TRIM FLANGED SQUARE TRIM FLANGED SQUARE TRIM Then, install the desired trim ring over the spacers and secure the trim ring into all spacers & subwoofer enclosure, using the 3 included Trim Ring Screws.
  • Page 19 MOS36SUB INSTALLATION USER MANUAL • Installing Flush Trim SPACERS SPACERS FLUSH ROUND TRIM FLUSH ROUND TRIM FLUSH SQUARE TRIM FLUSH SQUARE TRIM Then, install the desired trim ring over the spacers and secure the trim ring into all spacers & subwoofer enclosure, using the 3 included Trim Ring Screws.
  • Page 20 MOS36SUB INSTALLATION USER MANUAL I. Installing Invisible Trims SPACERS SPACERS INVISIBLE ROUND TRIM INVISIBLE ROUND TRIM INVISIBLE SQUARE TRIM INVISIBLE SQUARE TRIM MRM ADAPTER RING MRM ADAPTER RING Then, install the desired trim ring over the spacers and secure the trim ring into...
  • Page 21 It is best to test the unit, before plaster work is performed. Securely connect the INVISIBLE ROUND TRIM with ROUND PLACEHOLDER SPONGE wires from the MOS36SUB to the amp, for a sound test. Next, before installing the drywall over the Invisible Trim, place the correct Placeholder Sponge inside, to protect the cut-out hole &...
  • Page 22 MOS36SUB INSTALLATION USER MANUAL J. Adding the Grille: To complete the installation, use the pieces of included adhesive tack, to secure the press grille in place. The grille can be spray painted to better match the ceiling color and environment, prior to being attached.
  • Page 23 MOS36SUB INSTALLATION USER MANUAL SQUARE TRIM FLANGED SQUARE TRIM FLANGED ROUND TRIM SQUARE GRILLE GRILLE ADHESIVE FLANGED SQUARE TRIM...

  • Page 24: Troubleshooting

    MOS36SUB INSTALLATION USER MANUAL 9. Troubleshooting If possible, it’s often good to try to isolate the problem first. For example, if you’re playing a DVD on a television and there’s no sound, try connecting an MP3 player to the system to see if that works. If it does work, then the problem is with the television, DVD player, or the cables connecting them.

  • Page 25: Technical Assistance

    If you are considering returning the product, it’s required that you contact Origin Acoustics prior to any return attempts. This way we can determine if the issue can be resolved without returning the product, or if needed we can provide instructions and support for the return process.

  • Page 26: Warranty Coverage - 5 Year Limited Warranty

    11. Warranty Coverage - 5 Year Limited Warranty Origin Acoustics warrants to the original retail purchaser only that for a period of Five (5) years from the original date of purchase. This Origin Acoustics product will be free from defects in materials and workmanship, provided the speaker was purchased from an Origin Acoustics authorized dealer.

  • Page 27: Return Process

    Before making any return attempts, it is required that you first contact Origin Acoustics. Return product to Origin Acoustics or your dealer, either in person or by mail. It’s preferable if the product is returned in the original packaging. If this isn’t possible, the customer is responsible for insuring the shipment for the full value of the product.
  • Page 28 01-30-23 6975 S Decatur BLVD, Las Vegas, NV 89118 • www.originacoustics.com • 844-674-4461 ©2023 Origin Acoustics. All copyrighted, trademarked and patented elements mentioned herein are the sole property of Origin Acoustics.
