Origin Acoustics SUBS10 Instruction Manual

Slim floor-standing subwoofer
Hide thumbs
Table of Contents

Advertisement

Quick Links

SUBS10
SUBS10 SLIM FLOOR-STANDING SUBWOOFER
INSTALLATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUBS10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Origin Acoustics SUBS10

Summary of Contents for Origin Acoustics SUBS10

  • Page 1 SUBS10 SUBS10 SLIM FLOOR-STANDING SUBWOOFER INSTALLATION MANUAL...

  • Page 2: Table Of Contents

    SUBS10 SUBWOOFER INSTALLATION MANUAL Table of Contents 1. Introduction 2. Subwoofer Specifications 3. What’s Included 4. WARNING / IMPORTANT SAFETY INSTRUCTIONS 5. Subwoofer Parts and Controls 6. Subwoofer Parts and Controls Guide 7. Subwoofer Connection Details 8. Using Wireles Transmission 9.

  • Page 3: Introduction

    SUBS10 SUBWOOFER INSTALLATION MANUAL 1. Introduction Thank you for choosing the SUBS10 Slim Subwoofer. At Origin Acoustics, we take pride in providing you with a high quality product. All of Origin Acoustics’ speakers are designed to have excellent sound quality, longevity, and a simple installation process.

  • Page 4: Subwoofer Specifications

    SUBS10 SUBWOOFER INSTALLATION MANUAL 2. Subwoofer Specifications SPECIFICATION SUBS10 Woofers 10'' Woven Fiber Glass Frequency Response 35Hz - 175Hz [+/- 3dB] Power RMS 200 Watts Power Peak 400 Watts Enclosure Aluminum Cabinet DIMENSIONS Width '' W [400mm] Height • Without Feet: 14...

  • Page 5: What's Included

    SUBS10 SUBWOOFER INSTALLATION MANUAL 3. What’s Included 4 x Phillips Screws SUBS10 Subwoofer Start Guide 4 x Drywall Anchors 90 Degree AC Cable 4 x Screw Posts Grille 90 Degree RCA Cable 4 x Rubber Feet 14.57in 370.0mm 2 x Floor Standing Feet...

  • Page 6: Warning / Important Safety Instructions

    SUBS10 SUBWOOFER INSTALLATION MANUAL 4. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to the rain or moisture. To reduce the risk of fire, do not cover the ventilation opening of the appliance...
  • Page 7 SUBS10 SUBWOOFER INSTALLATION MANUAL 9. Do not defeat the safety purpose of polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding plug. The wide blade or the third prong are provided for you safety.

  • Page 8: Subwoofer Parts And Controls

    SUBS10 SUBWOOFER INSTALLATION MANUAL 5. Subwoofer Parts and Controls 1. POWER SWITCH...
  • Page 9 SUBS10 SUBWOOFER INSTALLATION MANUAL 2. AC POWER CONNECTION 5. LFE/NAX & CROSSOVER SWITCH 4. AUTO ON / TRIGGER SWITCH 3. FUSE 9. POWER LIGHT 8. VOLUME KNOB 7. CROSSOVER KNOB 6. POLARITY SWITCH...
  • Page 10 SUBS10 SUBWOOFER INSTALLATION MANUAL 10. POWER SUPPLY 5V 500 mA 11. TRIGGER IN 12. RCA LINE LEVEL OUTPUTS 13. RCA LINE LEVEL INPUTS (LFE /NAX) 14. FEET PLACEMENT INDICATORS (LEFT & RIGHT)

  • Page 11: Subwoofer Parts And Controls Guide

    SUBS10 SUBWOOFER INSTALLATION MANUAL 6. Subwoofer Parts and Controls Guide 1. Power Switch - Switch between On/Off. 2. AC Power Connection - This connection is a standard IEC power jack. Use the supplied 90 Degree AC Power Cord to connect the subwoofer to an available and easily accessible AC outlet.
  • Page 12 SUBS10 SUBWOOFER INSTALLATION MANUAL 8. Volume Knob - This knob adjusts the subwoofer’s volume. Turn it clockwise for full volume. Note that the subwoofer level control in an AV Receiver will also affect how loud the subwoofer plays. With most AV Receivers, setting this knob at about halfway up (the 12 o’clock position) will provide a volume level that allows the...

  • Page 13: Subwoofer Connection Details

    SUBS10 SUBWOOFER INSTALLATION MANUAL ! CAUTION: All connections and switching must be done with the amplifier turned off. Connect the power cord last to ensure that the amplifier is off during all the connections and set up. 7. Subwoofer Connection Details 7a.

  • Page 14: Using Wireles Transmission

    Connect the appropriate conductor to each screw terminal, observing correct polarity. 8. Using Wireless Transmission Please using Origin Acoustics WSK200 (Seperate Purchase) to connect the SUBS10 Subwoofer to a line-level source. Either LFE or Line Level can be selected, but only one is sufficient.
  • Page 15 SUBS10 SUBWOOFER INSTALLATION MANUAL 8a. Wireless Subwoofer Kit: WSK200 Receiver Transmitter Operating Voltage: DC 5V / 0.5A Operating Voltage: DC 5V / 0.5A RF Frequency Band: 5135 MHz - 5820 MHz RF Frequency Band: 5135 MHz - 5820 MHz Modulation: GFSK...
  • Page 16 SUBS10 SUBWOOFER INSTALLATION MANUAL General Placement and Setup Tips • Place the subwoofer, powered speakers or amplifier at its intended location. • Try to maintain line-of-sight (no walls or solid barriers) between the transmitter and receiver for best results. • Receiver should be within 65 feet of transmitter for best results.
  • Page 17 SUBS10 SUBWOOFER INSTALLATION MANUAL 8b. Connecting the Wireless Transmitter to an AV Processor 1. Connect the 3.5 mm to dual RCA adapter cable to the subwoofer pre-out or LFE channel of the AV processor and to the input on the wireless transmitter. Use only one RCA cable channel (e.g.Red).
  • Page 18 SUBS10 SUBWOOFER INSTALLATION MANUAL 8e. Pairing the Transmitter and Receiver 1. The transmitter and receiver are synched at the time of manufacture and will pair automatically when connected and powered on. 2. Successful pairing will be indicated by a steady blue light on the transmitter and receiver.

  • Page 19: Subwoofer Mounting Options

    SUBS10 SUBWOOFER INSTALLATION MANUAL 9. Subwoofer Mounting Options In Preparation Unbox the Subwoofer and set box and packing material aside. Turn off the entire audio system before making any connections. If it will be mounted, take care to ensure the Subwoofer is mounted securely into its mount.
  • Page 20 W I T H O U T p r e - i n s t a l l e d s c r e w SUBS10 SUBWOOFER INSTALLATION MANUAL 9b. Floor Standing: with Woofer Facing Room 1.
  • Page 21 SUBS10 SUBWOOFER INSTALLATION MANUAL s c r e w h o l e s W I T H O U T p r e - i n s t a l l e d s c r e w p o s t s : f r o n t s i d e Floor Standing with Woofer Facing Room 9c.
  • Page 22 SUBS10 SUBWOOFER INSTALLATION MANUAL 9d. Wall Mounted: with Woofer Facing Wall 1. The wall mounted option, where the woofer is facing the wall, requires the included Wall Mount, 4 x Phillips Screws, 4 x Drywall Anchors, and uses the 4 x Pre-installed Screw Posts on the Woofer Side of the unit.
  • Page 23 SUBS10 SUBWOOFER INSTALLATION MANUAL extras extras screw holes WITHOUT pre-installed screw posts : front side rack mounting: rack mounting: Wall Mount Hook Wall Mount Hook overhead view overhead view extras woofer facing room woofer facing room with grille with grille...
  • Page 24 SUBS10 SUBWOOFER INSTALLATION MANUAL woofer facing room [Top View Cut Out ] with grille Wall Wall Mount Hook Wall [Top View Cut Out ] Wall woofer facing wall Wall Mounted Subwoofer New Screw Post [Woofer Facing Room] Wall Mount Hook...
  • Page 25 SUBS10 SUBWOOFER INSTALLATION MANUAL N O T E S...

  • Page 26: Technical Assistance

    If you are considering returning the product, it’s required that you contact Origin Acoustics prior to any return attempts. This way we can determine if the issue can be resolved without returning the product, or if needed we can provide instructions and support for the return process.

  • Page 27: Warranty Coverage - 2 Year Limited Warranty

    SUBS10 SUBWOOFER INSTALLATION MANUAL 11. Warranty Coverage - 2 Year Limited Warranty Origin Acoustics warrants to the original retail purchaser only that for a period of Two (2) years from the original date of purchase. This Origin Acoustics product will be free from defects in materials and workmanship, provided the speaker was purchased from an Origin Acoustics authorized dealer.

  • Page 28: Return Process

    Before making any return attempts, it is required that you first contact Origin Acoustics. Return product to Origin Acoustics or your dealer, either in person or by mail. It’s preferable if the product is returned in the original packaging. If this isn’t possible, the customer is responsible for insuring the shipment for the full value of the product.

  • Page 29: Troubleshooting

    SUBS10 SUBWOOFER INSTALLATION MANUAL 13. Troubleshooting If possible, it’s often good to try to isolate the problem first. For example, if you’re playing a DVD on a television and there’s no sound, try connecting an MP3 player to the system to see if that works. If it does work, then the problem is with the television, DVD player, or the cables connecting them.
  • Page 30 Rev B 09-19-2022 6975 S Decatur BLVD, Las Vegas, NV 89118 • www.originacoustics.com • 844-674-4461 ©2022 Origin Acoustics. All copyrighted, trademarked and patented elements mentioned herein are the sole property of Origin Acoustics.
