TKH security FD2005v2M Quick Start Manual

FD2005v2M
5MP Vandal Fixed Dome Camera
Quick Start Guide

Unpack

Mounting Plate
CAT-6 RJ45 conduit
& Pin pusher
Camera Unit
Conduit Security Torx
Subject to modification. Actual product and accessories may differ in appearance.

Connector Definition

No. Connector Definition
1 Alarm I/O Alarm I/O connection
2 Audio I/O Line In and Line Out connection
For network and PoE connections. Please
3 RJ-45 Port contact TKH Security for a compatible PoE
injector.
4 Power(DC 12V) Power Connection
To restore camera to factory defaults, power
5 Reset Button
up with Reset button pressed for at least 10s.
Insert the SD card into the card slot to store
6 Micro-SD Card Slot videos and snapshots. Do not remove the SD
card when the camera is powered on.
Table 1 Connector definition
© TKH Security B.V. 2023 | Version 3 (20230209) | FD2005v2M-QS-EN
Find additional manuals, the
datasheet, the EU Declaration of
Conformity, and the latest firmware
for this product at:
tkhsecurity.com
Caution installation shall be performed by qualified
personnel only. Installation shall be in accordance with
local procedures. The camera contains batteries.
Battery replacement shall not be applied in view of the
risk of explosion. Dispose of used batteries according to
Duster
the instructions.
For "PoE" input connection, use only with UL listed
I.T.E. with "PoE" output. Description for the "PoE" is
intended to be connected to not exposed (outside plant)
Screws(4x) &
networks or equivalent statement in installation
Plastic Screw
instructions.
Anchors (4x)
Quick Start Guide

Installation Notices

Camera Cabling

Figure 2 Cabling

Connectors

1
2
3
4
Figure 1 Camera Connectors
To restore camera to factory defaults, power up with
Reset button pressed for at least 10s

Waterproof Notice

Please make sure the
rubber is properly aligned
during installation.
Figure 3 Rubber
5
6
