6. C
SMART ORE
The connector type is equal to the COMexpress connector. This is a 220pin, surface-mounted connector
with 0.5mm pitch.
Parameter
Material
Electrical
Mechanical
The manufacturer of the connector is:
Source on smartCore
Carrier Board Connector
TYCO / AMP
smartCoreExpress Module Connector
TYCO / AMP
The stack height may be defined on the carrier board as either 5 or 8mm using the two different connector
types available.
-E C
XPRESS
Condition
Contact
Housing
Current
Voltage
Termination Resistance
Insulation Resistance
Mating Cycles
Connector Mating Force
Connector Un-mating Force
Pitch
Number of pins
Temperature rating
Part Name
H = 8mm
H = 5mm
Mating connector
40
S
ONNECTOR
Specification
Copper alloy
Thermoplast molded compound LCP
0.5 Amp
50 VAC
55mΩ max. ∆R = 20mΩ max.
500MΩ
30
0.9N per contact
0.1N per contact
0.5mm
220
-40° C to 85° C
Part Number
Alternative 8-6318491-6
Standard 3-1827253-6
8-1318490-6
