3. D
IMENSIONS

3.1. Block Diagram

Intel Atom
Processor
CPU
(power supply)
Temp.
Sensor
Power
Management
Microcontroller
& D
IAGRAMS
1 GB DDR2
RAM
System Controller Hub
FSB
Module Connector (220 pin)
US15W
15
SMA200 Manual V1.0
Firmware Hub
(BIOS)
Option
SSD 4GB
