DIGITAL-LOGIC SmartCore Express SMA200 Technical User's Manual page 38

DIGITAL-LOGIC AG
5.4.14. PM
Signal BUS
WAKE# CMOS
WD_OUT CMOS
SUS_S3# CMOS
SUS_S4&5# CMOS
GPIO[3..0] CMOS
RST_IN# CMOS
RST_OUT# CMOS
Power-Good CMOS
PS_ON CMOS
PWRBTN# CMOS
BIOS_Disable# CMOS
A20M# CMOS
Speaker CMOS
If the signals are not used:
Leave the signal open.
Remarks:
EMV/EMI filters:
Are not needed.
Type Description
3.3V To wakeup the system,
In this input must be pulled
to GND.
3.3V Indicates a watchdog
Out timeout event with a high
level. Cleared with a
reset and at power-on.
3.3V Low = system is in
Out suspend state S3/S4/S5
(ACPI).
3.3V Low = system is in
Out suspend state S4/S5
(ACPI).
3.3V General purpose I/O pin.
I/O
3.3V To reset the system, this
In input must be pulled to
GND.
3.3V Goes low during the reset
Out phase and stays at high
in the running phase.
3.3V High = feedback from the
In external power supplies,
that the voltages are in
the valid ranges.
3.3V High = power supply on
Out the baseboard is
switched on.
3.3V To activate this signal,
In the PWR_BTN# must be
pulled to GND.
3.3V Low = onmodule BIOs is
In disabled, an external
BIOS may be connected
over LPC.
3.3V Connect to the SuperIO's
In KBC to switch between
real and protected mode.
3.3V Speaker
Out
On Module Ext. Ter-
Termination mination
Needed
PU 1k0k
3.3V
-
-
-
-
PU 10k to
3.3V
-
PU 10k to
3.3V
-
PU 1k to
3.3V
PU 1k to
3.3V
PU 100k to
5.0V
38
SMA200 Manual V1.0
Max.
Length Ohm
in mm
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
Matched
Length in
mm
-
-
-
-
-
-
-
-
-
-
-
