DIGITAL-LOGIC SmartCore Express SMA200 Technical User's Manual page 13

DIGITAL-LOGIC AG
Intel US15W
PCIe BUS
EIDE BUS
SATA BUS
USB V2.0
APIC
SMB
FWH
LPC
Sound
IRQ Controller
Timers
Power Management
Reset & Power Management
Controller
Power Modes
ACPI
BUS
LPC
PCIexpress
Power Supply
DC Input
Inrush Current
Standby Power
Onboard Voltages
Power Consumption
Physical Characteristics
Dimensions
Weight
PCB Thickness
PCB Layer
Specification
2x x1 Lane
1x Ultra P-ATA 100
-
8 channel USB
INTEL I/O APIC
V2.0 SMBus controller
FirmWare Hub for BIOS devices
Serialized BUS (no ISA) used for external SuperI/O
AC97 2.3 HDA Interface with 192kHz sampling rate and 8 channels
8259 compatible
8254 compatible
Integrated
Specification
Atmel
S5, S3
V3.0
Specification
8bit 33MHz
2x x1 lane
Specification
5.0V, max. 200mV ripple
5.0V up to 2Amp for 100µs
0.1W
VCC Core, 1.05V, 1.8V, 0.9V, CoreVCC, 1.5V
4W
Use inductors in series to reduce the maximum inrush current!
Specification
Length: 65 mm +/- 0.1mm
Depth: 58 mm +/- 0.1mm
Height: 11 mm +/- 0.2mm (with 5mm bus connectors)
14 mm +/- 0.2mm (with 8mm bus connectors)
The connector height is selected by the connector on the carrier board.
70 gr / 8 ounces
1.6 mm / 0.0625 inches nominal
Multilayer
13
SMA200 Manual V1.0
