DIGITAL-LOGIC AG
2. O
VERVIEW
2.1. Standard Features
The smartCoreExpress is an electrical and mechanical definition for a COM or Computer on Module
(miniaturized PC system), based on Intel's ATOM chip unit incorporating the major elements of a PC
compatible computer.
Powerful though low consumption ATOM CPU
Soldered DDR2 RAM 512k up to 2GByte
Single 220pin connectors (Tyco) for the smartCoreExpress BUS
5x x1 PCI-Express lanes
8x USB V2.0
1x PATA or (4x SATA plus 1x GE-LAN)
1x SDVO interface
1x LVDS 24bit interface
1x AC97 HAD interface
1x LPC BUS
1x SPI BUS
1x SM BUS
1x Generic Serial BUS (ex. CAN)
4x GPIO (programmable global in/out)
Maximum Thermal Design Power up to 40W
Reserved pins for: 1x Ethernet interface 1GE
Single 5Volt supply
Legacy signals for SuperIO
11
SMA200 Manual V1.0
