Examples Of Ordering Codes - DIGITAL-LOGIC SmartCore Express SMA200 Technical User's Manual

DIGITAL-LOGIC AG
Operating Environment
Relative Humidity
Vibration
Shock
Operating Temperature
Maximum Copper Temperature
Storage Temperature
EMI / EMC (IEC1131-2 refer MIL 461/462)
ESD Electro Static Discharge
REF Radiated Electromagnetic Field
EFT Electric Fast Transient (Burst)
SIR Surge Immunity Requirements
High-Frequency Radiation
All information is subject to change without notice.

2.3. Examples of Ordering Codes

Product Name
SMA200-11G-xxGB
incl. 0.5GB RAM
incl. 1.0GB RAM
incl. 2.0GB RAM
SMA200-16G-xxGB
incl. 0.5GB RAM
incl. 1.0GB RAM
incl. 2.0GB RAM
SMA204-16G-xxGB
incl. 0.5GB RAM
incl. 1.0GB RAM
incl. 2.0GB RAM
Options/Accessories
SMX-CON5
SMX-CON8
SMA200DK
These are only examples; for current ordering codes, please see the current price list.
Specification
5-90% non-condensing
5 to 2000 Hz
10 G
Standard: t.b.d. (depends on the CPU and the cooling concept)
Extended Range: t.b.d.
90° C
-55° C to +85°C
Specification
IEC 801-2, EN55101-2, VDE 0843/0847 Part 2
Metallic protection needed
Separate Ground Layer included
15 kV single peak
IEC 801-3, VDE 0843 Part 3, IEC770 6.2.9.
Not tested
IEC 801-4, EN50082-1, VDE 0843 Part 4
250V - 4kV, 50 Ohm, Ts = 5ns
Grade 2: 1KV Supply, 500 I/O, 5Khz
IEC 801-5, IEEE587, VDE 0843 Part 5
Supply:
I/O:
FD, CRT: None
EN55022
Part Number Description
ATOM Z510, 1.1GHz
805800
805801
805802
ATOM Z530, 1.6GHz
805810
805811
805812
ATOM Z530, 1.6GHz, 4GB PATA SSD
805820
805821
805822
807139 5mm COM Express connector
807138 8mm COM Express connector
805850 SMA200 Development Kit
2kV, 6 pulse/minute
500V, 2 pulse/minute
14
SMA200 Manual V1.0
