Table 3
SFPs and XFPs (cont'd.)
SFP model
1000BaseCWDM-ZX
SFP
1000Base-T SFP
1000Base-SX DDI SFP
1000Base-LX DDI SFP
1000BASE-BX
bidirectional SFP
1000BASE-BX
bidirectional SFP
100Base-FX SFP
XFP Model
10GBase-LR/LW XFP
10GBASE-ER/EW
10GBase-SR XFP
10GBase-ZR/ZW XFP
10GBase-LRM XFP
See Nortel Ethernet Routing Switch 5000 Series Installation — SFPs
and XFPs - NN47200-302 for a list of supported SFPs and your latest
product-specific release notes. Information contained in the Release Notes
takes precedence over any information contained in this document.

Preparing for power requirements of the switch

Navigation
•
"Nortel Ethernet Routing Switch 5510-24T and 5510-48T" (page 43)
•
"Nortel Ethernet Routing Switch 5520-24T-PWR and 5520-48T-PWR"
(page 43)
•
"Nortel Ethernet Routing Switch 5530-24TFD" (page 44)
•
"Nortel Ethernet Power Supply 10" (page 44)
