VACON® NX Door Keypad Mounting Kit
Installation Guide
6. Attach the grounding cable. See
7.
In FR8, make a sufficiently wide opening for the grounding cable by cutting the grid of the cable cover as wide as necessa-
ry. Attach the cable cover.See
8.
VACON® NX Door Keypad Mounting Kit is now ready to use.
1
Illustration 2: Connection of VACON cable and the grounding cable, FR4-FR7
1 VACON cable
2 Grounding cable
2 | Danfoss A/S © 2023.01
Illustration 2 and Illustration 3
Illustration 4 below.
2
below.
AN440742738345en-000201 / DPD01616
