Code No.
027F0309
Fits to Danfoss EKC controlles
Enclosure rating: IP 67 (∼ NEMA 6)
Assembled view of metal mounting parts from inside electrical box.
Metal mounting parts
Remove plastic tabs in the front panel.
Front view after
plastic tabs removed
© Danfoss A/S (AC-AKC / frz), 11-2007
Instructions
EKC front panel mounting kit
Two screws
Remove 8 tabs to
fit a EKC controller
DKRCI.PI.FO0.A1.02 / 520H2518
Metal mounting parts
Front panel
1
