AWM Tilt Bracket
COMPONENT CHECKLIST
A
VESA Plate
(x2)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! Each Bracket supports a maximum weight as per above weight range specification.
! This product supports VESA mounting hole configurations: 75x75mm and 100x100mm.
! The manufacturer accepts no responsibility for incorrect installation.
! VESA mounted accessories (such as mini PC brackets and mounts), and offset VESA locations exert additional leverage that can
exceed the capacity of the mount even though the monitor weight may be within the stated range. Please contact Atdec if you would
like further information.
Mount Screw
Mount Screw
B
Bracket
(x2)
Installation Guide
C
M4x10
REQUIRED TOOLS
(x4)
• Phillips Head Screwdriver
D
CAPACITY
M4x20
(x4)
Flat Monitor
0 - 25kg (0 - 55lb)
Curved Monitor
E
0 - 18kg (0 - 39lb)
10mm
Screen Size
Spacer
17" - 55"
(4x)
300mm (12") max overall
display depth
AWM-BT
AWM-BT Page 1 of 2
