Atdec AWM-BT Installation Manual

AWM Tilt Bracket
COMPONENT CHECKLIST
A
VESA Plate
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! Each Tilt Bracket supports a maximum weight as per above capacity specification.
! Avoid applying downward load to corners of display.
! This product is not suitable for outdoor use.
! Do not use this product for mobile applications.
! The manufacturer accepts no responsibility for incorrect installation.
! This product is compatible with Atdec AWM Series products.
! VESA mounted accessories (such as mini PC brackets and mounts), and offset VESA locations exert additional leverage
that can exceed the capacity of the mount even though the monitor weight may be within the stated range. Please contact
Atdec if you would like further information.
! WARNING! Death or serious injury may occur if a child climbs on or tips product.
C
M4x10mm
Screw
(x4)
E
10mm
Spacer
(4x)
B
Bracket
(x1)
Installation Guide
D
REQUIRED TOOLS
M4x20mm
Screw
• Phillips Head Screwdriver
(x4)
CAPACITY
F Flat Monitor
4mm 4.5 - 25kg (10 - 55lb)
Hex Key
Curved Monitor
(x1)
4.5 - 18kg (10 - 40lb)
Display Size
24" - 55"
300mm (12") max
overall display depth
AWM-BT
AWM-BT Page 1 of 3
