  • Page 1 XE360 Series ™ User guide...
  • Page 2 2 • Schlage • OEM 200 Developer guide...
  • Page 3: Table Of Contents

    Contents FCC Statements IC Statements Contact information Warnings and cautions Introduction Lock diagrams Power Commissioning Lock modes Register a commerical construction credential 10 Diagnostics and Troubleshooting Factory default reset (FDR) DPS (door position switch) REX (request for exit) 12 Troubleshooting Factory default reset...
  • Page 4: Fcc Statements

    Contents | FCC Statements FCC Statements FCC Compliance Statements • This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 5: Ic Statements

    Contents | IC Statements IC Statements IC Compliance Statements • This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: This device may not cause interference. This device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 6: Contact Information

    Contents | Contact information Contact information Should a system design engineer or developer need assistance, they should contact technical support at: Phone: 1-877-671-7011 www.allegion.com/us MIFARE® and DESFire™ are registered trademarks of NXP B.V. Warnings and cautions WARNING Warnings indicate potentially hazardous conditions, which if not avoided or corrected, may cause death or serious injury.
  • Page 7: Introduction

    Introduction Lock diagrams XE360-EW Interior Exterior Battery compartment Button Communication area Exit device (not included) Lever XE360-M and XE360-T Interior Exterior Communication Button or area thumbturn (thumbturn shown) Lever Battery compartment 7 • Schlage • XE360 Locks user guide...
  • Page 8: Power

    Power XE360-EW Actual size XE360-M/XE360-T Screw retained in cover. Insert batteries as shown. Replace batteries as necessary after the low battery warning, or on a set schedule to ensure continuous operation. Use standard alkaline batteries. Lithium batteries are not recommended as there is little warning before the battery voltage is Î...
  • Page 9: Commissioning

    Commissioning Commissioning is the process of adding the lock into the access control system. Once commissioned, the lock(s) can be controlled using Allegion Engage™. Power the lock. The initiation sequence will begin. Wait for a steady blue light and one (1) beep.
  • Page 10: Diagnostics And Troubleshooting

    Diagnostics and Troubleshooting Troubleshooting Problem Solution Manual commissioning failed. When commissioning fails, the lock will revert to FDR mode. Press and release the mode switch again to restart the process. • Confirm that bluetooth is enabled on the mobile device. •...
  • Page 11: Factory Default Reset (Fdr)

    Diagnostics and Troubleshooting | Factory default reset (FDR) Lock indicators Function Actions Lights Beeps Contruction mode Mode initiated green Construction mode activated green fast Timeout long — Test mode Mode activated yellow yellow steady Manual commissioning mode Advertising blue MAPP connected blue long —...
  • Page 12: Troubleshooting

    Troubleshooting Troubleshooting Problem Solution Manual commissioning failed. When commissioning fails, the lock will revert to FDR mode. Press and release the mode switch again to restart the process. • Confirm that bluetooth is enabled on the mobile device. • Confirm that the mobile device is not currently connected to another device.
  • Page 14 About Allegion Allegion (NYSE: ALLE) is a global pioneer in seamless access, with leading brands like CISA , Interflex , LCN , Schlage , SimonsVoss and Von Duprin ® ® ® ® ® ® Focusing on security around the door and adjacent areas, Allegion secures people and assets with a range of solutions for homes, businesses, schools and institutions.
