Summary of Contents for Allegion Schlage L-Series

  • Page 1 L-Series Service manual...

  • Page 3: Table Of Contents

    Contents L9050, L9060, L9066 x XL11-897, L9070, L9071 Introduction LV9050, LV9060, LV9070, LV9071 Dot charts LM9350, LM9370, LM9371 Changes and additions 100 LMV9350, LMV9370, LMV9371 Additions L9056 LV9056 Lock assembly drawing index L9076, L9077 LV9076, LV9077 Trim assemblies L9080 L400-Series deadbolt trim LV9080 L9000-Series single dummy trim LM9380...
  • Page 4 147 Assembly of lock case parts 181 LM9300 Series multipoint lock Turn hub spring and transfer lever 182 Lubrication specifications Locking catch/retractor catch and locking link L functions only: fire door fuse, fire door catch 184 Door handing and hub spring Changing the lock hand LV functions only: fire door fuse, fire door catch and hub spring...

  • Page 5: Introduction

    Introduction Introduction This manual contains a complete listing of parts and assemblies for L-Series mortise locks manufactured by Schlage Lock Company. This edition lists components of L-Series locks manufactured after June, 2001. All lock case covers are labeled with the date of manufacture. Example: 8/15/13 = August 15, 2013. Exploded views of each lock function chassis and trim assembly are provided with accompanying charts to identify parts for replacement purposes.

  • Page 6: Dot Charts

    Changes and additions Dot charts • = (1) Part 2 = (2) Parts Example: Description • • • • • 2 2 2 2 • • • 2 2 • • • • 2 • • • 2 2 • • 30-001 Classic Mortise...

  • Page 7: Lock Assembly Drawing Index

    Lock assembly drawing index Lock assembly drawing index The lock assembly drawing index provides representations and descriptions of available functions. Page numbers for full trim and chassis drawings are referenced. Outside Inside Two-point latch Emergency Turn Thumbturn Electrified Coin Turn Cylinder Auxiliary Deadbolt...
  • Page 8 Lock assembly drawing index L9000 FUNCTIONS Trim Lock Lock case ANSI/BHMA A156.13, 2012, Series 1000, Grade 1 assembly assembly part no. Non-keyed locks page no. page no. SCHLAGE ANSI Description Privacy with turns both sides L9040 x XL11-446 L283-132 Latchbolt is retracted by knob/lever from either side unless outside is locked by inside or outside thumbturn.
  • Page 9 Lock assembly drawing index L9000 FUNCTIONS Trim Lock Lock case ANSI/BHMA A156.13, 2012, Series 1000, Grade 1 assembly assembly part no. Non-keyed locks page no. page no. SCHLAGE ANSI Description Privacy with deadbolt and coin turn outside L9444 L283-062 Latchbolt is retracted by knob/lever from either side. Deadbolt is thrown or retracted by inside thumbturn or outside coin turn.
  • Page 10 Lock assembly drawing index L9000 FUNCTIONS Trim Lock Lock case ANSI/BHMA A156.13, 2012, Series 1000, Grade 1 assembly assembly part no. Keyed locks page no. page no. SCHLAGE ANSI Description Apartment entrance lock with Vandlgard LV9060 L283-170 � Latchbolt is retracted by knob/lever from either side unless outside is locked by LOCKED key from inside.
  • Page 11 Lock assembly drawing index L9000 FUNCTIONS Trim Lock Lock case ANSI/BHMA A156.13, 2012, Series 1000, Grade 1 assembly assembly part no. Keyed locks page no. page no. SCHLAGE ANSI Description Classroom security holdback lock with Vandlgard ◊ LV9077 L283-172 ® Latchbolt is retracted by knob/lever from either side unless locked by key from either side.
  • Page 12 Lock assembly drawing index L9000 FUNCTIONS Trim Lock Lock case ANSI/BHMA A156.13, 2012, Series 1000, Grade 1 assembly assembly part no. Keyed locks page no. page no. SCHLAGE ANSI Description Request to exit electrically unlocked (fail secure) L9080EU-RX L283-143 Same as L9080EU function. In addition, a microswitch positioned inside the lock L283-263 case is activated when either inside or outside knob/lever is rotated.
  • Page 13 Lock assembly drawing index L9000 FUNCTIONS Trim Lock Lock case ANSI/BHMA A156.13, 2012, Series 1000, Grade 1 assembly assembly part no. Keyed locks page no. page no. SCHLAGE ANSI Description Corridor lock with deadbolt L9456 L283-138 Latchbolt is retracted by knob/lever from either side. Deadbolt is operated by key LOCKED outside or inside thumbturn.
  • Page 14 Lock assembly drawing index L9000 FUNCTIONS Trim Lock Lock case ANSI/BHMA A156.13, 2012, Series 1000, Grade 1 assembly assembly part no. Keyed locks page no. page no. SCHLAGE ANSI Description L9473 Dormitory/bedroom lock L283-140 Latchbolt is operated by knob/lever from either side. Deadbolt is operated by key LOCKED outside or thumbturn inside.
  • Page 15 Lock assembly drawing index L9000 FUNCTIONS Trim Lock Lock case ANSI/BHMA A156.13, 2012, Series 1000, Grade 1 assembly assembly part no. Keyed locks page no. page no. SCHLAGE ANSI Description Hotel lock with 09-611 "Do not disturb" indicator L9486 L283-141 Latchbolt is operated by key outside or by knob/lever inside.
  • Page 16 Lock assembly drawing index L9000 FUNCTIONS Trim Lock Lock case ANSI/BHMA A156.13, 2012, Series 1000, Grade 1 assembly assembly part no. Keyed L9000-Series deadbolts page no. page no. SCHLAGE ANSI Description Cylinder by thumbturn lock L9460 L283-139 Deadbolt is operated by key outside or thumbturn inside. LOCKED L9462 Double cylinder lock*...
  • Page 17 Lock assembly drawing index L909X Electrified functions Trim Lock Lock case ANSI/BHMA A 156.25, 2014 assembly assembly part no. Non-keyed locks page no. page no. SCHLAGE Description Electrically locking and unlocking outside lever (no cylinder) L9090 EL/EU L283-347 Outside knob/lever continuously locked (EL) or unlocked (EU) by 12 or 24V DC. EL is fail safe (power failure allows outside knob/lever to retract latchbolt).
  • Page 18 Lock assembly drawing index L949X Electrified functions Trim Lock Lock case ANSI/BHMA A 156.25, 2014 assembly assembly part no. Keyed locks with deadbolt page no. page no. SCHLAGE Description Electrically locking and unlocking outside lever (outside cylinder, inside L9492 EL/EU L283-467 thumbturn with deadbolt) Outside knob/lever continuously locked (EL) or unlocked (EU) by 12 or 24V DC.
  • Page 19 Lock assembly drawing index LM9200 Two-point functions Trim Lock Lock case ANSI/BHMA A 156.37, 2014 assembly assembly part no. Non-keyed locks page no. page no. SCHLAGE Description Exit lock two-point latch LM9225 24759599 Inside lever only, no outside trim. Latchbolt(s) always retracted by inside lever. Inside lever is always free for immediate egress.
  • Page 20 Lock assembly drawing index LM9200 Multipoint functions Trim Lock Lock case ANSI/BHMA A 156.37, 2014 assembly assembly part no. Keyed Locks page no. page no. SCHLAGE Description Electrified outside lever lock, two-point latch LM9290 EL/EU 24759656 Electrically locking/unlocking outside lever only. Latchbolt(s) retracted by outside lever when unlocked, or anytime by inside lever.
  • Page 21 Lock assembly drawing index LM9300 Multipoint functions** Trim Lock Lock case ANSI/ICC 500 for tornadoes, ANSI/BHMA A 156.37, 2014 assembly assembly part no. FEMA 320 and FEMA 361 certified for tornadoes page no. page no. Non-keyed locks SCHLAGE Description LM9310 Passage latch with three-point latch L283-314 Latchbolt retracted by knob/lever from either side at all times.
  • Page 22 Lock assembly drawing index LM9300 Multipoint functions** Trim Lock Lock case ANSI/ICC 500 for tornadoes, ANSI/BHMA A 156.37, 2014 assembly assembly part no. FEMA 320 and FEMA 361 certified for tornadoes page no. page no. Keyed Locks SCHLAGE Description LMV9371 Classroom security lock with three-point latch and Vandlgard�...
  • Page 23 Lock assembly drawing index L400 FUNCTIONS Trim Lock Lock case ANSI/BHMA A156.13, 2010, Series 1000, Grade 1 assembly assembly page no. Keyed L400-Series page no. page no. SCHLAGE ANSI Cylinder by thumbturn lock L460 E06071 L283-099 Deadbolt is operated by key outside or thumbturn inside. LOCKED L462 E06061...
  • Page 24 24 • Schlage • L-Series service manual...

  • Page 25: Trim Assemblies

    Trim assemblies L400-Series deadbolt trim L9000-Series single dummy trim L9000-Series double dummy trim Passage latch trim Exit trim Emergency button x turn trim Privacy x turns both sides trim Coin turn outside x turn trim Cylinder x turn trim Double cylinder trim Double cylinder storeroom trim Cylinder outside trim Electrically locked/unlocked both sides trim...

  • Page 26: L400-Series Deadbolt Trim

    Trim assemblies L400-Series deadbolt trim L460, L462, L463, L464, L480, L496 L460P L462P L463P L464P L496 L480 Notes: Standard full face mortise cylinder shown. Available with 180° messaging indicator trim. 26 • Schlage • L-Series service manual...
  • Page 27 Trim assemblies Description • • • 09-509 Inside thumbturn • 09-611 Occupancy Indicator • • • • • • 09-717 L400 Series 1Z\v" armor front x Schlage logo, deadbolt • 09-905 Classroom turn and 1Z\," blocking ring • • • •...

  • Page 28: L9000-Series Single Dummy Trim

    Wood/metal door x rose/escutcheon x knob L583-286 Dummy mounting bar L583-321 Inside knob mounting plate L583-322 Outside lever spacer Notes: Reinforcement required for metal door applications. See template at www.allegion.com/us. L0170 not available with L escutcheon. 28 • Schlage • L-Series service manual...

  • Page 29: L9000-Series Double Dummy Trim

    L583-321 Inside knob mounting plate 09-650 Outside N escutcheon and bushing x 93 lever, blank L583-322 Outside lever spacers (qty – 2) Note: Reinforcement required for metal door applications. See template at www.allegion.com/us. Schlage • L-Series service manual • 29...

  • Page 30: Passage Latch Trim

    Trim assemblies Passage latch trim L9010, LM9310 Levers Knobs Note: LM9310 lock function has latch and auxiliary latch. Lock case and armor front shown with latch only. 30 • Schlage • L-Series service manual...
  • Page 31 Trim assemblies Description • • 09-401 Outside knob and lever • • 09-402 Inside knob and lever • • 09-403 Inside rose • • 09-404 Outside rose and bushing Outside rose and knob/lever: • • 09-506 All designs except AST, AVA, MER •...

  • Page 32: Exit Trim

    Trim assemblies Exit trim LM9325 Levers Knobs 32 • Schlage • L-Series service manual...
  • Page 33 Trim assemblies Description 09-402 Inside knob and lever 09-403 Inside rose 09-663 1Z\v" armor front x Schlage logo –latch and auxiliary latch C203-736 Case mounting screw pack K110-020 Armor screw pack L283-031 Inside lever mounting plate L283-040 Lever spring cage L283-060 Spindle and spring L283-314...

  • Page 34: Emergency Button X Turn Trim

    Trim assemblies Emergency button x turn trim L9040, LV9040, L9440, LV9440 Levers Notes: L9440 and LV9440 lock functions have latch and deadbolt. Lock case and armor front shown with latch only. Available with 180° messaging indicator trim. Available with lever trim only. 34 •...
  • Page 35 Trim assemblies Description • • • • 09-401 Outside lever • • • • 09-402 Inside lever • • • • 09-403 Inside rose • • • • 09-404 Outside rose and bushing Outside rose lever: • • • • 09-506 All designs except AST, AVA, MER •...

  • Page 36: Privacy X Turns Both Sides Trim

    Trim assemblies Privacy x turns both sides trim L9040 x XL11-446, LV9040 x XL11-446 Levers 2 CC Notes: Available with 180° messaging indicator trim. Available with lever trim only. 36 • Schlage • L-Series service manual...
  • Page 37 Trim assemblies Description • • 09-401 Outside lever • • 09-402 Inside lever • • 09-403 Inside rose • • 09-404 Outside rose and bushing Outside rose and lever: • • 09-506 All designs except AST, AVA, MER • • 09-655 AST, AVA, MER •...

  • Page 38: Coin Turn Outside X Turn Trim

    Trim assemblies Coin turn outside x turn trim L9044, LV9044, L9444, LV9444 Levers Notes: L9444 and LV9444 lock functions have latch and deadbolt. Lock case and armor front shown with latch only. Available with 180° messaging indicator trim. Available with lever x rose trim only. 38 •...
  • Page 39 Trim assemblies Description • • • • 09-401 Outside lever • • • • 09-402 Inside lever • • • • 09-403 Inside rose • • • • 09-404 Outside rose and bushing Outside rose and knob/lever: • • • •...

  • Page 40: Cylinder X Turn Trim

    Trim assemblies Cylinder x turn trim L9050, LV9050, LM9350, LMV9350, L9056, LV9056, L9453, LV9453, L9456, LV9456, L9473 Levers Knobs Notes: L9456, LV9456, and L9473 lock functions have a latch and deadbolt. Lock case and armor front shown with latch and auxiliary latch. L/LV9453 lock functions have a latch, auxiliary latch, and deadbolt.
  • Page 41 Trim assemblies Description • • • • • • • • • • • 09-401 Outside knob and lever • • • • • • • • • • • 09-402 Inside knob and lever • • • • • •...

  • Page 42: Double Cylinder Trim

    Trim assemblies Double cylinder trim L9060, LV9060, L9071, LV9071, LM9371, LMV9371, L9077, LV9077, L9082, LV9082, L9457, LV9457, L9458, LV9458, L9462 x XL11-886, L9466 Levers 2 CC Knobs Notes: L9457, LV9457, and L9466 lock functions have a latch and deadbolt. Lock case and armor front shown with latch and auxiliary latch. L9458 and LV9458 lock functions have a latch, auxiliary latch and deadbolt.
  • Page 43 Trim assemblies Description • • • • • • • • • • • • • • • • 09-401 Outside knob and lever • • • • • • • • • • • • • • • • 09-402 Inside knob and lever •...

  • Page 44: Double Cylinder Storeroom Trim

    Trim assemblies Double cylinder storeroom trim L9066 x XL11-897 Levers 2 CC Knobs Note: Standard full face mortise cylinders shown. 44 • Schlage • L-Series service manual...
  • Page 45 Trim assemblies Description 09-401 Outside knob and lever 09-402 Inside knob and lever 09-403 Inside rose 09-404 Outside rose and bushing 09-506 Outside rose and knob/lever, all designs except AST, AVA, MER 09-553 Outside escutcheon x knob/lever (except 93 lever), L and N x full face cylinder 09-635 Inside escutcheon for knob/lever, L and N x full face cylinder 09-639...

  • Page 46: Cylinder Outside Trim

    Trim assemblies Cylinder outside trim L9070, LV9070, LM9370, LMV9370, L9076, LV9076, L9080, LV9080, LM9380, LMV9380, L9080EL/EU*, LV9080EL/EU*, L9080EL/EU-RX*, L9464 x XL11-886, L9465 Levers Knobs Notes: L9465 lock function has a latch and deadbolt. Lock case and armor front shown with latch and auxiliary latch. L9464 x XL11-886 lock function has deadbolt only.
  • Page 47 Trim assemblies Description • • • • • • • • • • • • • • • • • • 09-401 Outside knob and lever • • • • • • • • • • • • • • •...

  • Page 48: Electrically Locked/Unlocked Both Sides Trim

    Trim assemblies Electrically locked/unlocked both sides trim L9082EL/EU* Levers DD Q Knobs Notes: Standard full face mortise cylinder shown. L9082EL/EU is discontinued. For equivalent current product, see page 50. 48 • Schlage • L-Series service manual...
  • Page 49 Trim assemblies Description • • 09-401 Outside knob and lever • • 09-402 Inside knob and lever • • 09-403 Inside rose • • 09-404 Outside rose and bushing Outside rose and knob/lever: • • 09-506 All designs except AST, AVA, MER •...

  • Page 50: Electrically Locked/Unlocked Outside Trim

    Trim assemblies Electrically locked/unlocked outside trim L9090EL/EU Levers Knobs 50 • Schlage • L-Series service manual...
  • Page 51 Trim assemblies Description • • 09-401 Outside knob and lever • • 09-402 Inside knob and lever • • 09-403 Inside rose • • 09-404 Outside rose and bushing Outside rose and knob/lever: • • 09-506 All designs except AST, AVA, MER •...

  • Page 52: Electrically Locked/Unlocked Both Sides Trim

    Trim assemblies Electrically locked/unlocked both sides trim L9091EL/EU Levers Knobs 52 • Schlage • L-Series service manual...
  • Page 53 Trim assemblies Description • • 09-401 Outside knob and lever • • 09-402 Inside knob and lever • • 09-403 Inside rose • • 09-404 Outside rose and bushing Outside rose and knob/lever: • • 09-506 All designs except AST, AVA, MER •...
  • Page 54 Trim assemblies Electrically locked/unlocked outside trim, single cylinder L9092EL/EU, L9492 EL/EU Levers Knobs Notes: L9492 lock function has a latch, auxiliary latch, deadbolt and inside thumb turn. Lock case and armor front shown with latch and auxiliary latch. Standard full face mortise cylinder shown. 54 •...
  • Page 55 Trim assemblies Description • • • • 09-401 Outside knob and lever • • • • 09-402 Inside knob and lever • • • • 09-403 Inside rose • • • • 09-404 Outside rose and bushing Outside rose and knob/lever: •...

  • Page 56: Electrically Locked/Unlocked Both Sides Trim, Single Cylinder

    Trim assemblies Electrically locked/unlocked both sides trim, single cylinder L9093EL/EU, L9493 EL/EU Levers Knobs Notes: L9493 lock function has a latch, auxiliary latch, deadbolt and inside thumb turn. Lock case and armor front shown with latch and auxiliary latch. Standard full face mortise cylinder shown. 56 •...
  • Page 57 Trim assemblies Description • • • • 09-401 Outside knob and lever • • • • 09-402 Inside knob and lever • • • • 09-403 Inside rose • • • • 09-404 Outside rose and bushing Outside rose and knob/lever: •...

  • Page 58: Electrically Locked/Unlocked Outside Trim, Double Cylinder

    Trim assemblies Electrically locked/unlocked outside trim, double cylinder L9094EL/EU, L9494EL/EU Levers DD Q Knobs Notes: L9494 lock function has a latch, auxiliary latch, deadbolt and inside thumb turn. Lock case and armor front shown with latch and auxiliary latch. Standard full face mortise cylinder shown. 58 •...
  • Page 59 Trim assemblies Description • • • • 09-401 Outside knob and lever • • • • 09-402 Inside knob and lever • • • • 09-403 Inside rose • • • • 09-404 Outside rose and bushing Outside rose and knob/lever: •...

  • Page 60: Electrically Locked/Unlocked Both Sides Trim, Double Cylinder

    Trim assemblies Electrically locked/unlocked both sides trim, double cylinder L9095EL/EU, L9495EL/EU Levers DD Q Knobs Notes: L9495 lock function has a latch, auxiliary latch, deadbolt and inside thumb turn. Lock case and armor front shown with latch and auxiliary latch. Standard full face mortise cylinder shown.
  • Page 61 Trim assemblies Description • • • • 09-401 Outside knob and lever • • • • 09-402 Inside knob and lever • • • • 09-403 Inside rose • • • • 09-404 Outside rose and bushing Outside rose and knob/lever: •...

  • Page 62: Active Double Dummy Trim

    Trim assemblies Active double dummy trim L9110 x XL11-741 Levers Knobs 62 • Schlage • L-Series service manual...
  • Page 63 Trim assemblies Description 09-401 Outside knob and lever 09-402 Inside knob and lever 09-403 Inside rose 09-404 Outside rose and bushing Outside rose and knob/lever: 09-506 All designs except AST, AVA, MER 09-655 AST, AVA, MER 09-550 Outside escutcheon x knob/lever (except 93 lever) L and N x blank 09-632 Inside escutcheon for knob/lever, L and N x blank 09-636...

  • Page 64: Single Dummy With Case Trim

    Trim assemblies Single dummy with case trim L9175, L9177 (discontinued) Levers For discontinued function L9177 order L9175 and armor strike separately and specify hand of inactive door. Mount in place of blank armor. Knobs For discontinued function L9177 order L9175 and armor strike separately and specify hand of inactive door.
  • Page 65 Trim assemblies Description • • 09-402 Inside knob and lever • • 09-403 Inside rose • • 09-632 Inside escutcheon for knob/lever, L and N x blank • • 09-661 1Z\v" armor front x Schlage logo, blank • • C203-736 Case mounting screw pack Escutcheon thru-bolts/screws: L583-133...

  • Page 66: Double Dummy With Case Trim

    Trim assemblies Double dummy with case trim L9176, L9178 (discontinued) Levers For discontinued function L9178 order L9176 and armor strike separately and specify hand of inactive door. Mount in place of blank armor. Knobs For discontinued function L9178 order L9176 and armor strike separately and specify hand of inactive door.
  • Page 67 Trim assemblies Description • • 09-401 Outside knob and lever • • 09-402 Inside knob and lever • • 09-403 Inside rose • • 09-404 Outside rose and bushing • • 09-506 Outside rose and knob/lever: All designs except AST, AVA, MER •...

  • Page 68: Deadbolt Trim

    Trim assemblies Deadbolt trim L9460, L9462, L9463, L9464 L9460P L9462P L9463P L9464P Notes: Standard full face mortise cylinder shown. Available with 180° indicator trim. 68 • Schlage • L-Series service manual...
  • Page 69 Trim assemblies Description • 09-509 Thumbturn • • • • 09-665 1Z\v" armor front x Schlage logo, deadbolt • 09-905 Classroom turn and 1Z\," blocking ring • • • 30-001 Full face cylinder with compression ring and spring , clover leaf cam •...

  • Page 70: Deadbolt With Fixed Double Dummy Trim

    Trim assemblies Deadbolt with fixed double dummy trim L9460 x XL11-635 Levers Knobs Notes: Standard full face mortise cylinder shown. Available with 180° indicator trim. 70 • Schlage • L-Series service manual...
  • Page 71 Trim assemblies Description 09-401 Outside knob and lever 09-402 Inside knob and lever 09-403 Inside rose 09-404 Outside rose and bushing Outside rose and knob/lever: 09-506 All designs except AST, AVA, MER 09-655 AST, AVA, MER 09-509 Thumbturn 09-553 Outside escutcheon x knob/lever (except 93 lever), L and N x full face cylinder 09-633 Inside escutcheon for knob/lever: L and N x thumbturn 09-639...

  • Page 72: Fixed Outside X Turn Trim

    Trim assemblies Fixed outside x turn trim L9412-XL11-907, L9460 x XL11-886, L9480, LV9480, L9485, LV9485 Levers Knobs Notes: L9460 x XL11-886 lock function has a deadbolt only. Lock case and armor front shown with latch, auxiliary latch, and deadbolt. Standard full face mortise cylinder shown. L9460 x XL11-886 and L/LV9485 available with 180°...
  • Page 73 Trim assemblies Description • • • • • • 09-401 Outside knob and lever • • • • • • 09-402 Inside knob and lever • • • • • 09-403 Inside rose • • • • • 09-404 Outside rose and bushing Outside rose and knob/lever: •...

  • Page 74: Institution Deadbolt Trim

    Trim assemblies Institution deadbolt trim L9482 x XL11-543, LV9482 x XL11-543 Levers DD Q Knobs Note: Standard full face mortise cylinder shown. 74 • Schlage • L-Series service manual...
  • Page 75 Trim assemblies Description • • 09-401 Outside knob and lever • • 09-402 Inside knob and lever • • 09-403 Inside rose • • 09-404 Outside rose and bushing Outside rose and knob/lever: • • 09-506 All designs except AST, AVA, MER •...

  • Page 76: Prison Lock Trim

    Trim assemblies Prison lock trim L9485 x XL11-557 Notes: Standard full face mortise cylinder shown. Available with knob x rose trim only. Furnished with tamper-resistant Torx screws. ® 76 • Schlage • L-Series service manual...
  • Page 77 Trim assemblies Description 09-401 Outside knob and lever 09-402 Inside knob and lever 09-403 Inside rose 09-404 Outside rose and bushing 09-506 Outside rose and knob/lever: All designs except AST, AVA, MER 09-666 1Z\v" armor front x Schlage logo, latch, auxiliary latch and deadbolt 30-002 Full face cylinder with compression ring and spring , clover leaf cam, hotel (handed) 30-022...

  • Page 78: Hotel With Indicator Trim

    Trim assemblies Hotel with indicator trim L9486, LV9486, L9486 x L583-375, LV9486 x L583-375, L9496, LV9496 Levers Knobs Notes: L9496 and LV9496 lock functions have a latch and deadbolt. Lock case and armor front shown with latch, auxiliary latch, and deadbolt. Standard full face mortise cylinder shown.
  • Page 79 Trim assemblies Description • • • • 09-401 Outside knob and lever • • • • 09-402 Inside knob and lever • • • • 09-403 Inside rose • • • • 09-404 Outside rose and bushing Outside rose and knob/lever: •...

  • Page 80: Passage And Electrically Locked/Unlocked, Two-Point Latch Trim

    Trim assemblies Passage and electrically locked/unlocked, two-point latch trim LM9210, LM9290 EL/EU, LM9291 EL/EU 2 CC Notes: Bottom latch and cable are optional (lock may be ordered less bottom latch (LBL)). LM9290 EL/EU and LM9291 EL/EU lock functions have wiring for electric motor. Lock case shown without electrified option. LM9291 EL/EU lock function has double dummy spindle and spring (item AA on parts chart, page 81).
  • Page 81 Trim assemblies Description • • • 09-401 Outside lever • • • 09-402 Inside lever • • • 09-403 Inside rose • • • 09-404 Outside rose and bushing Outside rose and lever: • • • 09-506 All designs except AST, AVA, MER •...

  • Page 82: Outside Lever Only, Two-Point Latch Trim

    Trim assemblies Outside lever only, two-point latch trim LM9225 2 CC Note: Bottom latch and cable are optional (lock may be ordered less bottom latch (LBL)). 82 • Schlage • L-Series service manual...
  • Page 83 Trim assemblies Description 09-402 Inside lever 09-403 Inside rose 24771248 1Z\v" armor front x Schlage logo C203-736 Case mounting screw pack K110-020 Armor screw pack L283-031 Inside lever mounting plate L283-040 Lever spring cage L283-060 Spindle and spring 24759599 Assembled lock case, passage/exit for two point latch L583-066 Mounting trim screws, wood/metal door x rose/escutcheon x lever (except single dummy) (qty 2) 24871584...

  • Page 84: Cylinder X Turn, Two-Point Latch Trim

    Trim assemblies Cylinder x turn, two-point latch trim LM9250, LM9256 2 CC Note: Bottom latch and cable are optional (lock may be ordered less bottom latch (LBL)). 84 • Schlage • L-Series service manual...
  • Page 85 Trim assemblies Description • • 09-401 Outside lever • • 09-402 Inside lever • • 09-403 Inside rose • • 09-404 Outside rose and bushing Outside rose and lever: • • 09-506 All designs except AST, AVA, MER • • 09-655 AST, AVA, MER •...

  • Page 86: Outside Cylinder And Electrically Locked/Unlocked Outside Cylinder, Two-Point Latch Trim

    Trim assemblies Outside cylinder and electrically locked/unlocked outside cylinder, two-point latch trim LM9270, LM9280, LM9292 EL/EU, LM9293 EL/EU 2 CC Notes: Bottom latch and cable are optional (lock may be ordered less bottom latch (LBL)). LM9292 EL/EU and LM9293 EL/EU lock functions have wiring for electric motor. Lock case shown without electrified option. LM9293 EL/EU lock function has double dummy spindle and spring (item AA on parts chart, page 87).
  • Page 87 Trim assemblies Description • • • • 09-401 Outside lever • • • • 09-402 Inside lever • • • • 09-403 Inside rose • • • • 09-404 Outside rose and bushing Outside rose and lever: • • • •...

  • Page 88: Double Cylinder And Electrically Locked/Unlocked Outside Cylinder, Two-Point Latch Trim

    Trim assemblies Double cylinder and electrically locked/unlocked outside cylinder, two-point latch trim LM9271, LM9294 EL/EU, LM9295 EL/EU DD Q 2 CC Notes: Bottom latch and cable are optional (lock may be ordered less bottom latch (LBL)). LM9294 EL/EU and LM9295 EL/EU lock functions have wiring for electric motor. Lock case shown without electrified option. LM9295 EL/EU lock function has double dummy spindle and spring (item AA on parts chart, page 89).
  • Page 89 Trim assemblies Description • • • 09-401 Outside lever • • • 09-402 Inside lever • • • 09-403 Inside rose • • • 09-404 Outside rose and bushing Outside rose and lever: • • • 09-506 All designs except AST, AVA, MER •...
  • Page 90 90 • Schlage • L-Series service manual...

  • Page 91: Lock Case Assemblies

    Lock case assemblies L460, L462, L463, L464, L480, L496 LM9256 L9010 LM9250, LM9270, LM9271, LM9280 LM9310, LM9325 LM9290 EL/EU, LM9292 EL/EU, LM9294 EL/EU L9040, L9040 x XL11-446, L9044 LM9291 EL/EU, LM9293 EL/EU, LM9295 EL/EU LV9040, LV9040 x XL11-446, LV9044 Lock case assembly compatibility L9050, L9060, L9066 x XL11-897, L9070, L9071 LV9050, LV9060, LV9070, LV9071 LM9350, LM9370, LM9371...

  • Page 92: L460, L462, L463, L464, L480, L496

    Lock case assemblies L460, L462, L463, L464, L480, L496 Assembled Lock Case L283-099 Number Description Part Number Deadbolt L283-003 Cylinder Plate & Screw L283-055 L400 Lock Case L283-128 Turn Hub L583-029 Turn Hub Spring L583-035 L583-426 " Faceplate Tab Case Cover Screws L583-454 Cylinder Retainer Screw L583-481...

  • Page 93: L9010

    Lock case assemblies L9010 Assembled Lock Case L283-131 Part Number Description Number Latchbolt L283-008 L9000 Lock Case L283-112 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link L583-024 Retractor Crank L583-025 Hub Spring L583-026 Fire Door Fuse L583-027...

  • Page 94: Lm9310, Lm9325

    Lock case assemblies LM9310, LM9325 Assembled Lock Case L283-314 Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-336 Retractor Hub L583-748 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link L583-024 Retractor Crank L583-025 Hub Spring L583-026 Fire Door Fuse L583-027...

  • Page 95: L9040, L9040 X Xl11-446, L9044

    Lock case assemblies L9040, L9040 x XL11-446, L9044 Assembled Lock Case L283-132 Part Number Description Number Latchbolt L283-008 L9000 Lock Case L283-112 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link L583-024 Retractor Crank L583-025 Hub Spring...

  • Page 96: Lv9040, Lv9040 X Xl11-446, Lv9044

    Lock case assemblies LV9040, LV9040 x XL11-446, LV9044 Assembled Lock Case L283-171 Part Number Description Number Latchbolt L283-008 L9000 Lock Case L283-112 Retractor Link L583-024 Hub Spring L583-026 Fire Door Fuse L583-027 Fire Door Catch L583-028 Turn Hub L583-029 Turn Hub Spring L583-035 Auxiliary Bar Guide L583-038...

  • Page 97: L9050, L9060, L9066 X Xl11-897, L9070, L9071

    Lock case assemblies L9050, L9060, L9066 x XL11-897, L9070, L9071 Assembled Lock Case L283-133 Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022...

  • Page 98: Lv9050, Lv9060, Lv9070, Lv9071

    Lock case assemblies LV9050, LV9060, LV9070, LV9071 Assembled Lock Case L283-170 Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Link L583-024 Hub Spring L583-026 Fire Door Fuse L583-027 Fire Door Catch L583-028 Turn Hub L583-029...

  • Page 99: Lm9350, Lm9370, Lm9371

    Lock case assemblies LM9350, LM9370, LM9371 Assembled Lock Case L283-316 Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-336 Cylinder Plate & Screw L283-055 Retractor Hub L583-748 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link L583-024 Retractor Crank L583-025...

  • Page 100: Lmv9350, Lmv9370, Lmv9371

    Lock case assemblies LMV9350, LMV9370, LMV9371 Assembled Lock Case L283-317 Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-336 Cylinder Plate & Screw L283-055 Retractor Link L583-024 Hub Spring L583-026 Fire Door Fuse L583-027 Fire Door Catch L583-028 Turn Hub L583-029 Turn Hub Spring L583-035...
  • Page 101 Lock case assemblies L9056 Assembled Lock Case L283-126 Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link L583-024...

  • Page 102: Lv9056

    Lock case assemblies LV9056 Assembled Lock Case L283-180 Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Link L583-024 Hub Spring L583-026 Fire Door Fuse L583-027 Fire Door Catch L583-028 Turn Hub L583-029 Turn Hub Spring...

  • Page 103: L9076, L9077

    Lock case assemblies L9076, L9077 Assembled Lock Case L283-039 Part Number Description Number Auxiliary Latchbolt L283-006 Locking Link L283-010 Latchbolt L283-049 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023...

  • Page 104: Lv9076, Lv9077

    Lock case assemblies LV9076, LV9077 Assembled Lock Case L283-172 Part Number Description Number Auxiliary Latchbolt L283-006 Locking Link L283-010 Latchbolt L283-049 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Link L583-024 Hub Spring L583-026 Fire Door Fuse L583-027 Fire Door Catch L583-028 Turn Hub...

  • Page 105: L9080

    Lock case assemblies L9080 Assembled Lock Case L283-134 Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Standoff Post L583-004 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023...

  • Page 106: Lv9080

    Lock case assemblies LV9080 Assembled Lock Case L283-173 Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Standoff Post L583-004 Retractor Link L583-024 Hub Spring L583-026 Fire Door Fuse L583-027 Fire Door Catch L583-028 Stop Spring L583-044...

  • Page 107: Lm9380

    Lock case assemblies LM9380 Assembled Lock Case L283-316 Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-336 Cylinder Plate & Screw L283-055 Retractor Hub L583-748 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link L583-024 Retractor Crank L583-025 Hub Spring...

  • Page 108: Lmv9380

    Lock case assemblies LMV9380 Assembled Lock Case L283-317 Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-336 Cylinder Plate & Screw L283-055 Retractor Link L583-024 Hub Spring L583-026 Fire Door Fuse L583-027 Fire Door Catch L583-028 Turn Hub L583-029 Turn Hub Spring L583-035 Stop Spring L583-044...

  • Page 109: L9080El, L9080El-Rx

    Lock case assemblies L9080EL, L9080EL-RX Discontinued effective December 2014 Assembled Lock Case L283-142 Part Number Description Number Lock O-Ring 36-080 Lock Bushing K510-842 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Solenoid & Driver L283-053 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Standoff Post L583-004...

  • Page 110: Lv9080El

    Lock case assemblies LV9080EL Discontinued effective December 2014 Assembled Lock Case L283-174 Part Number Description Number EL Lock O-Ring 36-080 EL Lock Bushing K510-842 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Solenoid & Driver L283-053 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Standoff Post L583-004...

  • Page 111: L9080Eu, L9080Eu-Rx

    Lock case assemblies L9080EU, L9080EU-RX Discontinued effective December 2014 Assembled Lock Case L283-143 Part Number Description Number O-Ring 36-080 Bushing K510-842 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Solenoid & Driver L283-053 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Standoff Post L583-004 Retractor Hub L583-019...

  • Page 112: Lv9080Eu

    Lock case assemblies LV9080EU Discontinued effective December 2014 Assembled Lock Case L283-175 Part Number Description Number O-Ring 36-080 Bushing K510-842 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Solenoid & Driver L283-053 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Standoff Post L583-004 Retractor Link L583-024...
  • Page 113 Lock case assemblies L9082 Assembled Lock Case L283-146 Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Standoff Post L583-004 Stop Spring L583-044 Transfer Lever L583-051 Spindle Anchor L583-057 Auxiliary Stop L583-196 L583-426 "...

  • Page 114: Lv9082

    Lock case assemblies LV9082 Assembled Lock Case L283-182 Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Standoff Post L583-004 Stop Spring L583-044 Transfer Lever L583-051 Auxiliary Stop L583-196 L583-426 " Faceplate Tab Case Cover Screws L583-454 Cylinder Retainer Screw...

  • Page 115: L9082El

    Lock case assemblies L9082EL Discontinued effective December 2014 Assembled Lock Case L283-085 Part Number Description Number O-Ring 36-080 Bushing K510-842 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Solenoid & Driver L283-053 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Standoff Post L583-004 (couple before Retractor Hub...

  • Page 116: L9082Eu

    Lock case assemblies L9082EU Discontinued effective December 2014 Assembled Lock Case L283-086 Part Number Description Number O-Ring 36-080 Bushing K510-842 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Solenoid & Driver L283-053 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Standoff Post L583-004 Retractor Hub L583-019...

  • Page 117: L9090El/Eu, L9092El/Eu, L9094El/Eu

    Lock case assemblies L9090EL/EU, L9092EL/EU, L9094EL/EU Assembled Lock Case Numbers: L283-347 = EL/EU; L283-392 = EL/EU wtih RX; L283-393 = EL/EU with LX; L283-394 = EL/EU with LX and RX Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L909X Lock Case L283-673...

  • Page 118: L9091El/Eu, L9093El/Eu, L9095 El/Eu

    Lock case assemblies L9091EL/EU, L9093EL/EU, L9095 EL/EU Assembled Lock Case Numbers: L283-395 = EL/EU; L283-396 = EL/EU wtih RX; L283-397 = EL/EU with LX; L283-398 = EL/EU with LX and RX Part Number Description Number Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate &...

  • Page 119: L9492El/Eu, L9494 El/Eu

    Lock case assemblies L9492EL/EU, L9494 EL/EU Assembled Lock Case L283-467 Part Number Description Number Deadbolt Assembly L283-676 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L909X Lock Case L283-673 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate...

  • Page 120: L9493 El/Eu, L9495 El/Eu

    Lock case assemblies L9493 EL/EU, L9495 EL/EU Assembled Lock Case L283-468 Part Number Description Number Deadbolt Assembly L283-676 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L909X Lock Case L283-673 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022...

  • Page 121: L9110 X Xl11-741

    Lock case assemblies L9110 x XL11-741 Assembled Lock Case XL11-741 Part Number Description Number L9000 Lock Case L283-112 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link L583-024 Retractor Crank L583-025 Hub Spring L583-026 Fire Door Fuse L583-027...

  • Page 122: L9175

    Lock case assemblies L9175 Assembled Lock Case L283-144 Part Number Description Number Spindle Anchor Single L583-468 L9000 Lock Case L283-112 L583-426 " Faceplate Tab Case Cover Screws L583-454 Lock Case Cover L583-496 122 • Schlage • L-Series service manual...

  • Page 123: L9176

    Lock case assemblies L9176 Assembled Lock Case L283-145 Part Number Description Number L9000 Lock Case L283-112 Spindle Anchor L583-057 L583-426 " Faceplate Tab Case Cover Screws L583-454 Lock Case Cover L583-496 Schlage • L-Series service manual • 123...

  • Page 124: L9440, L9444

    Lock case assemblies L9440, L9444 Assembled Lock Case L283-062 Part Number Description Number Deadbolt L283-003 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link L583-024...

  • Page 125: Lv9440, Lv9444

    Lock case assemblies LV9440, LV9444 Assembled Lock Case L283-181 Part Number Description Number Deadbolt L283-003 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Link L583-024 (couple before Hub Spring L583-026 assembly)** Fire Door Fuse L583-027 Fire Door Catch L583-028 Turn Hub L583-029...

  • Page 126: L9453

    Lock case assemblies L9453 Assembled Lock Case L283-137 Part Number Description Number Entrance Deadbolt L283-004 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023...

  • Page 127: Lv9453

    Lock case assemblies LV9453 Assembled Lock Case L283-176 Part Number Description Number Entrance Deadbolt L283-004 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Link L583-024 Hub Spring L583-026 Fire Door Fuse L583-027 Fire Door Catch L583-028 Entrance Hub L583-030...

  • Page 128: L9456, L9457, L9496

    Lock case assemblies L9456, L9457, L9496 Assembled Lock Case L283-138 Part Number Description Number Deadbolt L283-003 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link L583-024...

  • Page 129: Lv9456, Lv9457, Lv9496

    Lock case assemblies LV9456, LV9457, LV9496 Assembled Lock Case L283-177 Part Number Description Number Deadbolt L283-003 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Link L583-024 Hub Spring L583-026 Fire Door Fuse L583-027 Fire Door Catch L583-028 Turn Hub L583-029...

  • Page 130: L9458

    Lock case assemblies L9458 Assembled Lock Case L283-310 Part Number Description Number Deadbolt L283-003 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link...

  • Page 131: Lv9458

    Lock case assemblies LV9458 Assembled Lock Case L283-311 Part Number Description Number Deadbolt L283-003 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Link L583-024 Hub Spring L583-026 (couple before assembly)** Fire Door Fuse L583-027 Fire Door Catch L583-028...

  • Page 132: L9460, L9462, L9463, L9464

    Lock case assemblies L9460, L9462, L9463, L9464 Assembled Lock Case L283-139 Part Number Description Number Deadbolt L283-003 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Latchbolt Guide L583-015 Turn Hub L583-029 Turn Hub Spring L583-035 Auxiliary Bar Guide L583-038 L583-426 "...

  • Page 133: L9460 X Xl11-635

    Lock case assemblies L9460 x XL11-635 Assembled Lock Case XL11-661 Part Number Description Number Deadbolt L283-003 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Latchbolt Guide L583-015 Turn Hub L583-029 Turn Hub Spring L583-035 Auxiliary Bar Guide L583-038 Spindle Anchor L583-057 L583-426 "...

  • Page 134: L9460 X Xl11-886, L9462 X Xl11-886, L9464 X Xl11-886

    Lock case assemblies L9460 x XL11-886, L9462 x XL11-886, L9464 x XL11-886 Assembled Lock Case XL11-886 Part Number Description Number Deadbolt L283-003 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Latchbolt Guide L583-015 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker...

  • Page 135: L9465, L9466, L9473

    Lock case assemblies L9465, L9466, L9473 Assembled Lock Case L283-140 Part Number Description Number Latchbolt L283-008 Cylinder Plate & Screw L283-055 Deadbolt L583-075 L9000 Lock Case L283-112 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link L583-024...

  • Page 136: L9480, L9485, L9486, L9486 X L583-375, L9412 X Xl11-907

    Lock case assemblies L9480, L9485, L9486, L9486 x L583-375, L9412 x XL11-907 Assembled Lock Case L283-141 (specify L9486 x L583-375 or L9412 x XL11-907 as applicable) Part Number Description Number Deadbolt L283-003 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112...

  • Page 137: Lv9480, Lv9485, Lv9486, Lv9486 X L583-375

    Lock case assemblies LV9480, LV9485, LV9486, LV9486 x L583-375 Assembled Lock Case L283-178 Part Number Description Number Deadbolt L283-003 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Link L583-024 Hub Spring L583-026 Fire Door Fuse L583-027 Fire Door Catch L583-028...

  • Page 138: L9482 X Xl11-543

    Lock case assemblies L9482 x XL11-543 Assembled Lock Case L283-146 x XL11-543 Part Number Description Number Deadbolt L283-003 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Turn Hub L583-029 Turn Hub Spring L583-035 Stop Spring L583-044 Transfer Lever L583-051...

  • Page 139: Lv9482 X Xl11-543

    Lock case assemblies LV9482 x XL11-543 Assembled Lock Case L283-183 Part Number Description Number Deadbolt L283-003 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Turn Hub L583-029 Turn Hub Spring L583-035 Stop Spring L583-044 Transfer Lever L583-051 Auxiliary Stop...

  • Page 140: L9485 X Xl11-557

    Lock case assemblies L9485 x XL11-557 Assembled Lock Case XL11-557 Part Number Description Number Deadbolt L283-003 Auxiliary Latchbolt L283-006 Latchbolt L283-008 Cylinder Plate & Screw L283-055 L9000 Lock Case L283-112 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023...

  • Page 141: Lm9210, Lm9225

    Lock case assemblies LM9210, LM9225 Assembled Lock Case 24759599 Part Number Description Number LM9200 Lock Case 24653917 Latchbolt Guide L583-015 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link L583-024 Retractor Crank L583-025 Hub Spring 24624892...

  • Page 142: Lm9256

    Lock case assemblies LM9256 Assembled Lock Case 24616914 Part Number Description Number Cylinder Plate & Screw L283-055 LM9200 Lock Case 24653917 Latchbolt Guide L583-015 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link L583-024 Retractor Crank L583-025...

  • Page 143: Lm9250, Lm9270, Lm9271, Lm9280

    Lock case assemblies LM9250, LM9270, LM9271, LM9280 Assembled Lock Case 24759623 Part Number Description Number Cylinder Plate & Screw L283-055 LM9200 Lock Case 24653917 Latchbolt Guide L583-015 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023 Retractor Link L583-024...

  • Page 144: Lm9290 El/Eu, Lm9292 El/Eu, Lm9294 El/Eu

    Lock case assemblies LM9290 EL/EU, LM9292 EL/EU, LM9294 EL/EU Assembled Lock Case 24759656 Part Number Description Number Cylinder Plate & Screw L283-055 LM9200 Lock Case 24653917 Latchbolt Guide L583-015 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Blocking Plate L583-023...

  • Page 145: Lm9291 El/Eu, Lm9293 El/Eu, Lm9295 El/Eu

    Lock case assemblies LM9291 EL/EU, LM9293 EL/EU, LM9295 EL/EU Assembled Lock Case 24759664 Part Number Description Number Cylinder Plate & Screw L283-055 LM9200 Lock Case 24653917 Latchbolt Guide L583-015 Retractor Hub L583-019 Hub Spacer L583-020 Retractor Lever L583-021 Retractor Rocker L583-022 Retractor Link L583-024...

  • Page 146: Lock Case Assembly Compatibility

    Lock case assemblies Lock case assembly compatibility Use this table to determine compatibility between parts for lock manufactured in 1994. L283-005 • • Cylinder Anchor Assembly L583-046 • • Lock Handing Screw L583-046 • • • Faceplate Tab Screw L583-006 L583-007 •...

  • Page 147: Assembly Of Lock Case Parts

    Assembly of lock case parts Assembly of lock case parts Turn hub spring and transfer lever Transfer Lever Auxiliary Bar Turn Hub Spring Guide Locking catch /retractor catch and locking link Locking Link Locking Catch Schlage • L-Series service manual • 147...

  • Page 148: Lv Functions Only: Fire Door Fuse, Fire Door Catch

    Assembly of lock case parts L functions only: fire door fuse, fire door catch and hub spring short end of hub spring Fire Door Fuse LV functions only: fire door fuse, fire door catch and hub spring 148 • Schlage • L-Series service manual...

  • Page 149: Trim Options

    Trim options Trim options Cast or forged levers, standard lever designs Standard levers are available in forged brass or bronze, and cast stainless steel. Levers are shown with rose trim A or B. Also available with L or N escutcheon. See escutcheon options on pages 155-157. "...

  • Page 150: Decorative Trim

    Decorative trim Decorative trim Decorative levers Asti lever (AST) Merano lever (MER) Accent lever (ACC) Latitude (LAT) Longitude (LON) Decorative roses " diameter " diameter " diameter >\zn Avanti rose (AVA) Merano rose (MER) " diameter " diameter 150 • Schlage • L-Series service manual...

  • Page 151: Collection Levers

    M collection levers M collection levers Standard levers are available in solid brass and solid stainless steel. Levers are shown with rose trim A or B. Also available with L or N escutcheon. See escutcheon options on pages 155-157. 2.4” 2”...

  • Page 152: Danmark Stainless Steel Levers

    Danmark stainless steel levers Danmark stainless steel levers For reference only. Danmark lever styles are discontinued. 630 Satin stainless steel finish Danmark stainless steel rose " diameter 152 • Schlage • L-Series service manual...

  • Page 153: Wrought Knob Designs

    Wrought knob designs Wrought knob designs Knobs shown with rose trim A or B. Also available with L or N escutcheons. See escutcheon options on pages 155-157. 41 (PLY) 42 (ORB) 2¹⁄₄" 2¹⁄₈" 2³⁄₄" 2³⁄₄" Inside knob assembly Outside knob assembly 09-402 09-401 Note:...

  • Page 154: Rose Trim A Or B

    Rose trim A or B Rose trim A or B Inside rose Blank outside rose 09-403 09-508 Rose design A– 2Z\," dia. x ZC\cx" Rose design A– 2Z\," dia. x ZC\cx" Rose design B– 2>\zn" dia. x ZC\cx" Rose design B– 2>\zn" dia. x ZC\cx" Rose design C–...
  • Page 155 L escutcheon trim L escutcheon trim Outside escutcheon dimensions Knob/lever design: 7 " x 1 " x " cold forged brass, bronze, or stainless steel base material. Bushing is attached at ZB\zn M\zn factory. 41, 42 01, 02, 03, 05, 06, 07, 12, 17, 18, ACC, LAT, LON, ACC, AST, MER, OME, STA, M51, M52, M53, OME, STA M54, M55, M56, M57, M61, M62, M63, M81,...
  • Page 156 L escutcheon trim Inside Escutcheons 09-632 Blank x knob/Lever 09-633 Thumbturn x knob/Lever 09-634 Thumbturn x blank Specify door thickness: 1C\," or 1C\v" Available Specify door thickness: 1C\," or 1C\v" with EZ Turn (ADA). See "Additional trim Available with EZ Turn (ADA). See "Additional options"...
  • Page 157 N escutcheon trim N escutcheon trim Outside escutcheon dimensions Knob/lever design: 7M\," x 2Z\x" x M\zn" heavy wrought reinforced brass, bronze, or stainless steel base material. Bushing is attached at factory. 41, 42 01, 02, 03, 05, 06, 07, 12, 17, 18, ACC, OME, STA AST, MER, M51, M52, M53, M54, M55, M56, M57, M61, M62, M63, M81, M82, M83, M84, 1¹⁄₂”...

  • Page 158: Indicator Trim Options

    Indicator trim options Indicator trim options Indicator trim is available for sectional and N escutcheon trim, for inside and outside trim where trim consists of a cylinder, thumb turn, coin turn or emergency turn. Specify part number for desired indicator message and placement (inside or outside). Indicator Message Options Sectional trim N Escutcheon trim...

  • Page 159: Additional Trim Options

    Additional trim options Additional trim options "EZ" thumbturn (ADA) for rose trim "EZ" thumbturn (ADA) x knob/lever with "EZ" thumbturn (ADA) x blank with L or N escutcheon L escutcheon 09-509 per L583-363 09-633 per L583-363 09-634 per L583-363 Not available for L463 or L9463 functions. Not available for L9463 functions.

  • Page 160: Trim Assembly Parts

    Additional trim options Tactile warning (knurling) Applied to outside knob/lever only unless otherwise specified. Milling pattern for backside of 01, 06, 07, 17, Knurling pattern for 02 lever. Knurling pattern for 03 lever. and 18 levers. Milling pattern for backside of 05 lever. Milling pattern for underside of 12 lever.
  • Page 161 Additional trim options Standard screw packs Part number Specify Description Contents finish C203-736 Lock case mounting screws (2) C603-256, #12-24 WMS PFH C203-736 • Strike screws (2) C603-256, #12-24 WMS PFH K110-020 • Armor mounting screws (2) K510-210, #8-32 x Z\v" PFHMS K110-947 •...
  • Page 162 Additional trim options Mounting plate for trim one side only L283-150 Mounting plate and posts for rose trim on one side of door. For lever use with spring cage L283-031, for knob use with mounting plate L583-321. DOOR DETAIL For location of cylinder and/or thumbturn holes, as well as all other dimensions, see appropriate lock function template.

  • Page 163: Armor Fronts

    Armor fronts Armor fronts 1Z\v" 1Z\zn" Description and functions 1Z\v" 1Z\zn" Description and functions Square corner Square corner* Square corner Square corner* Non UL 09-667 Blank Non UL 09-179 Deadbolt 09-661 09-168 L9110 09-671 09-665 L9175 L9460 L9176 L9462 L9463 L9464 Non UL 09-216...

  • Page 164: Strikes

    Strikes Strikes Square corner 10-072 Square corner 10-072 Square corner 10-073 Square corner 10-075 Standard M\,'', 1'', 1Z\x'', 1C\v'' No Lip No Lip 1C\zn" Lip or 2'' Lip Size: Size: Size: Size: 4M\," x 1Z\v" 4M\,'' x 1Z\v'' 4M\," x 1Z\v" 4M\,"...

  • Page 165: Cylinders

    Cylinders Cylinders How to measure cylinder lengths Cylinder length Dimension LENGTH LENGTH 1Z\,’’ 1Z\v’’ 1C\,’’ 1Z\x’’ 1B\,’’ Full face and interchangeable core Concealed 1C\v’’ L-Series, LV-Series cylinder and length requirements Function Trim Cylinder Door Thickness 1C\,’’ 1C\v’’ 2” 2Z\v” Dimension L9050, L9056, L9070, L9076, L9080, L9453, L9456, L9460 per Rose 30-001...

  • Page 166: Full Face Cylinders

    Cylinders Full face cylinders Cylinder with compression ring Screws Cylinder front Cylinder back Cylinder only and spring Back housing screw Cylinder plug assembly Face plate and front cover L-Series, LV-Series (except L9060/LV9060 outside and LM9280, LM9380/LMV9380) Description Cylinder Mechanism Complete Cylinder Traditional Cams Modular Cams Cylinder only:...

  • Page 167: Concealed Cylinders

    Cylinders Concealed cylinders Screw Cylinder front Cylinder back Cylinder only Shell Cylinder Cylinder plug plug assembly L-Series, LV-Series (except L9060/LV9060 outside) Description Cylinder mechanism Complete cylinder Cams Cylinder only: Conventional 30-004 L583-254 L583-153 L escutcheon Conventional Everest� and Primus� Primus� controlled access 20-789 Primus XP controlled access 20-789-XP...

  • Page 168: Full Size Interchangeable Core Cylinders

    Cylinders Full size interchangeable core cylinders Screw Cylinder with compression ring Cylinder with Cylinder front Cylinder back 1¹⁄₂" Cylinder only and spring blocking ring 1¹⁄₂" 1¹⁄₂" 1¹⁄₂" Shell Cylinder plug assembly L /LV/LM/LMV-Series (except L9060 /LV9060 outside and LM9280, LM9380/LMV9380) Description Cylinder mechanism Complete cylinder...
  • Page 169 Cylinders Assembled full size interchangeable cores 23-030 23-031 Part number Description 23-030 Conventional core 23-031 Conventional core less logo 20-740 Primus� core 20-740-XP Primus XP core 20-741 Primus core less logo 20-741-XP Primus XP core less logo 30-120* Hotel function conventional core for L9485 and L9486 30-121* Hotel function conventional core, less logo, for L9485 and L9486 Full size core parts...

  • Page 170: Small Format Interchangeable Core Cylinders

    Cylinders Small format interchangeable core cylinders Screw Cylinder with compression ring Cylinder with Cylinder front Cylinder back 1³⁄₈" Cylinder only and spring blocking ring 1³⁄₈" 1³⁄₈" 1³⁄₈" Driver Shell Cylinder plug assembly L /LV/LM/LMV-Series (except L9060 /LV9060 outside and LM9280, LM9380/LMV9380) Description Cylinder mechanism Complete cylinder...
  • Page 171 Cylinders Everest� and Everest 29 patented keyway cores Part number Description 80-036, 80-037 80-037 Everest combinated core, includes master keying Everest 80-036 uncombinated core (does not include keys, pins or springs) Notes: 1) Finishes: 606, 613, and 626. 2) Everest® B-family keyways are restricted. 3) Key symbol must be specified for combinated cores.

  • Page 172: Blocking And Compression Rings

    Blocking and compression rings Blocking and compression rings 36-079 Blocking ring 36-082 Blocking ring 36-083 compression ring and L583-195 Cylinder spring cylinder spring 1¹⁄₂" diameter 1C\,” diameter 1Z\x” diameter Specify dimension Specify dimension Specify dimension DO NOT use with 36-083 Use with 36-083 Dimensions for blocking rings Blocking ring length...

  • Page 173: Special Trim Options

    Special trim options Special trim options Solid latchbolt Armor front (deadbolt) L9000 lead lining L400 lead lining XL11-422 XL11-743 XL11-515 XL12-216 .125 ± .015 .125 ± .015 For use with electric strikes. The Armor front with deadbolt hole Lead plate installed on case cover. Buyer should verify that the anti-friction tongue is replaced for use with dummy functions or preparation meets local installation requirements or regulations.
  • Page 174 Special trim options Anti-ligature knob trim Anti-ligature lever trim Anti-ligature thumbturn XL11-000 XL12-482 09-029 Specify SK1 trim per XL11-000 Specify SL1 trim per XL12-482 Anti-ligature conversion kits Knob Lever Kit contents Knob or lever functions 09-155 09-138 (2) anti-ligature knob or lever assembly L9010, L9176, L9070, L9076, L9080, L9080EL, L9080EU, (2) anti-ligature blocking ring L9465, L9060, L9071, L9077, L9082, L9082EL, L9082EU, L9482,...
  • Page 175 Schlage • L-Series service manual • 175...

  • Page 176: Installation Tools And Kits

    Installation tools and kits Installation tools and kits 40-054 Maintenance kit Part No. Desc. L583-481-603 Screw, Retainer L583-492-604 Plate, Screw L583-490-604 Retainer L583-485-604 Screw, Catch L583-047-MW Spring, Catch L583-038-604 Guide, Aux. Bar L283-006-455 Latch, Aux. L583-026-MW Spring, Hub L583-027-PLA Fuse, Fire Door L583-028-604 Catch, Fire Door L583-024-604...
  • Page 177 Installation tools and kits Part number Description 40-158 Mortise pocket filler (edge) 40-160 Mortise lock jig Includes 1 each: Case, jig, long boring shaft, M\," wood cutter bit, 1" wood cutter bit, 1Z\v" wood cutter bit, instruction booklet 40-227 L-Series installation templates 40-286 Universal clamp Part Number...

  • Page 178: Electrified Locks

    Electrified locks Electrified locks L-Series and LM-Series EL, electrically locked (fail safe) Outside knob/lever or both outside and inside knobs/levers (depending on function) will lock when power is applied. In the event of power failure, the opening will be unlocked. L-Series and LM-Series EU, electrically unlocked (fail secure) Outside knob/lever or both outside and inside knobs/levers (depending on function) will unlock when power is applied.
  • Page 179 Electrified locks Electrified LM-Series functions No cylinder: LM9290 – outside lever electrically locked/unlocked; LM9291 – both levers electrically locked/unlocked Outside cylinder: LM9292 – outside lever electrically locked/unlocked; LM9293 – both levers electrically locked/unlocked Outside and inside cylinders: LM9294 – outside lever electrically locked/unlocked; LM9295 – both levers electrically locked/unlocked Request to exit (RX) For L909x and L949x Series electrified locks: A microswitch inside the lock case to detect rotation of the inside knob/lever.

  • Page 180: Lm9200 Series Two Point Lock

    LM9200 Series two point lock LM9200 Series two point lock The Schlage LM9200 Series is a one or two point latch solution for pairs of doors where both leaves are active. The LM9200 utilizes concealed vertical cables for simple installation and maintenance. The LM9200 is compatible with sectional trim as well as escutcheon trim, and offers 13 functions (mechanical and electrical).

  • Page 181: Lm9300 Series Multipoint Lock

    LM9300 Series multipoint lock LM9300 Series multipoint lock The LM9300 three-point locking chassis is a component in the Schlage Multipoint Lock product. The Multipoint Lock is an integrated assembly which includes the LM9300 three point locking chassis, a specialized Steelcraft door with a concealed vertical rod assembly, and a specialized Steelcraft frame.

  • Page 182: Lubrication Specifications

    Lubrication specifications Lubrication specifications L9000, LM9300 Series Lock Function Lock case lubrication areas Subassembly and component L9010, LM9310, LM9325, Lock case and case cover: Latchbolt: Components shown L9080, LV9080, L9082, Apply 150 mg minimum at each below must be barrel Apply 50 mg LV9082 applicable area.
  • Page 183 Lubrication specifications LM9200 Series Lock case lubrication areas Subassembly and component Lock case and case cover: Apply lubrication at shaded areas. Top link: Tilting link: Apply lubricant at shaded areas Apply lubricant at shaded areas indicated. indicated. Bottom link: Link subassembly: Apply lubricant at Apply lubricant at shaded areas indicated.

  • Page 184: Door Handing

    Door handing Door handing The hand of a door refers to the position of the lock relative to the side and direction of the door hinge. Le Hand Right Hand INSIDE There are four possible ‘handings’ based on whether the hinge is on the right or left side of the door and whether it OUTSIDE swings to the inside or outside (see diagram).

  • Page 185: Ordering Procedures

    Ordering procedures Ordering procedures To order Schlage products, descriptive data should be in the same sequence as shown: Line Product Outside Inside Hand Latch Strike Additional Details Item Line Item: Line item number 11. DR THK: Door thickness: Enter door thickness if non- standard.

  • Page 186: Finishes

    Finishes Finishes Schlage Lock products are available in a range of durable, Cleaning and care varies by finish. Clear-coated or oil top quality finishes. Most are available with a clear coating rubbed finishes can be cleaned periodically with a mild that protects against damaging environmental factors, non-abrasive soap and buffed lightly with a clean cloth.

  • Page 187: Limited Warranty

    Limited warranty Limited warranty Commercial application Specific product warranty restrictions/additional warranties 3-Year Limited Warranty Portable security products warranty: A limited lifetime warranty is provided to the Original User, subject to the Schlage Lock Company (the "Company") extends a three- restrictions of this limited warranty, except that the year limited warranty from the orginal date of purchase to Company's sole obligation under this warranty is to replace the Original User of the products manufactured by the...

  • Page 188: L9000-Series Installation Instructions

    L9000-Series installation instructions L9000-Series installation instructions Lever and Rose A Lockcase and mounting screws B Spindle and spring C Outside lever and rose D Mounting posts E Spring cage or spacer F Occupancy indicator G Inside mounting plate & screws H Inside lever J Inside thumbturn K Cylinder, compression ring and...
  • Page 189 L9000-Series installation instructions All functions For Functions: 9486 9496 Use correct driver bar For Functions: 9040 9440 For Functions: 9050 9056 Use blocking ring with double 9060 cylinder 9070 9071 9076 9077 9080 9082 9453 9456 9457 9465 9466 9473 For Functions: 9480 9044...
  • Page 190 L9000-Series installation instructions All functions For Functions: 9040 9050 9056 9440 Thumbturn 9453 vertical 9456 9473 9480 9485 9486 Arrow in direction of lever down rotation I N S I D E All functions Extend deadbolt For Functions: 9060 9071 Use blocking ring 9077 with double cylinder...
  • Page 191 L9000-Series installation instructions All functions Door Handing IMPORTANT: Move handing screw to inside of door for L locks and outside of door for LV locks. Tighten cylinder mounting screw if necessary Tighten mounting Pull screws All functions 180˚ Handing screw Schlage •...
  • Page 192 L9000-Series installation instructions Lever and Escutcheon A Lockcase and mounting screws B Spindle and spring D Mounting posts E Spring cage or spacer G Inside mounting plate and screws H Inside lever K Cylinder and spring N Emergency button and turn Q Armor front and screws R Outside lever and escutcheon T Inside escutcheon and screws...
  • Page 193 L9000-Series installation instructions For Functions: IMPORTANT: For concealed cylinder option, install cylinder(s) Note: Discontinued BEFORE installing escutcheon(s). 9486 L escutcheon 9496 indicator design shown. Available Optional only by RFQ. Use correct driver bar For Functions: For Functions: 9010 9050 9485 9176 9056 9486...
  • Page 194 L9000-Series installation instructions For Functions: For Functions: 9010 9080 9050 9071 9082 9465 9485 9060 9082 9056 9076 9453 9466 9486 9070 9457 9060 9077 9456 9473 9496 9071 9465 9070 9080 9457 9480 9076 9466 9077 I D E For Functions: For Functions: 9060...
  • Page 195 L9000-Series installation instructions All functions Door Handing IMPORTANT: Move handing screw to inside of door for L locks and outside of door for LV locks. Tighten cylinder mounting screw if necessary Tighten mounting Pull screws All functions 180˚ Handing screw Schlage •...
  • Page 196 L9000-Series installation instructions Knob and Rose A Lockcase and mounting screws B Spindle and spring D Mounting posts F Occupancy indicator J Inside thumbturn K Cylinder, compression ring and spring L Inside rose M Outside knob and rose N Emergency turn and button P Coin turn Q Armor front and screws V Knob mounting plate...
  • Page 197 L9000-Series installation instructions For Functions: For Functions: 9050 9040 9056 9440 9060 Use blocking ring 9070 with double cylinder 9071 9076 9077 9080 9082 9453 9456 9457 9465 9466 9473 I D E 9480 9485 For Functions: 9486 9044 9496 9444 All functions For Functions:...
  • Page 198 L9000-Series installation instructions All functions For Functions: 9060 9071 Use blocking 9077 ring with double 9082 cylinder 9457 9466 Optional Cylinder Turn For Functions: 9040 9044 9050 9056 All functions 9440 Thumbturn vertical 9444 9453 9456 9473 9480 Tighten cylinder 9485 mounting screw if necessary...
  • Page 199 L9000-Series installation instructions All functions Door Handing IMPORTANT: Move handing screw to inside of door. Pull 180˚ Handing screw Schlage • L-Series service manual • 199...
  • Page 200 L9000-Series installation instructions Knob and Escutcheon A Lockcase and mounting screws B Spindle and spring D Mounting posts K Cylinder and spring N Emergency button and turn Q Armor front and screws S Outside knob and escutcheon T Inside escutcheon and screws V Knob mounting plate W Inside knob IMPORTANT: Before installation of any L/LV Series...
  • Page 201 L9000-Series installation instructions For Functions: For Functions: 9010 9050 9110 9056 9176 9060 9070 9071 9076 9077 9080 9082 9453 9456 9457 9465 9466 9473 9480 9485 For Functions: 9486 9040 9496 9440 All functions I N S I D E Note: For Functions: Discontinued...
  • Page 202 L9000-Series installation instructions For Functions: For Functions: 9050 9071 9082 9465 9485 9010 9071 9080 9175 9465 9056 9076 9453 9466 9486 9060 9076 9082 9176 9466 9060 9077 9456 9473 9496 9070 9077 9110 9457 9070 9080 9457 9480 I D E Shown with escutcheon for cylinder For Functions:...
  • Page 203 L9000-Series installation instructions All functions Door Handing IMPORTANT: Move handing screw to inside of door. Tighten cylinder mounting screw if necessary Tighten mounting Pull screws All functions 180˚ Handing screw Schlage • L-Series service manual • 203...

  • Page 204: L400-Series Installation Instructions

    L400-Series installation instructions L400-Series installation instructions Small Case Mortise Locks A Lockcase and mounting screws B Occupancy indicator C Cylinder compression ring and spring D Inside thumbturn E Blocking ring F Armor front and screws For Functions: All functions L460 L462 L463 L464...
  • Page 205 L400-Series installation instructions Small Case Mortise Locks A Lockcase and mounting screws B Occupancy indicator C Cylinder compression ring and spring D Inside thumbturn E Blocking ring F Armor front and screws For Functions: All functions L460 L462 L463 L464 L496 Use blocking ring with double...

  • Page 206: L9000-Series 180 Degree Indicator Installation Instructions - Escutcheon Trim

    L9000-Series 180 degree indicator installation instructions – escutcheon trim L9000-Series 180 degree indicator installation L9000 Lock with Indicator instructions – escutcheon trim L9000 Series Lock with Indicator Escutcheon Trim Installation Instructions Indicator trim is available for either the inside or outside of the door on allowable functions. Non-indicator trim is furnished on the opposite side of the door.
  • Page 207 L9000-Series 180 degree indicator installation instructions – escutcheon trim Connect the cam to the indicator slide. The cam must Install springs and spindles engage either the left or right side of the indicator slide Exterior according to door handing. All functions • Unlock the door.
  • Page 208 L9000-Series 180 degree indicator installation instructions – escutcheon trim Functions Install outside spring cage or spacer. L/LV9044 L/LV9444 All functions L The spring cage arrow must point in direction of lever down rotation. Install spacer for L/LV9485 Install outside mounting posts. Exterior Functions L/LV9050...
  • Page 209 L9000-Series 180 degree indicator installation instructions – escutcheon trim Install outside cylinder (if applicable) Install inside spring cage and mounting plate Insert key halfway into the cylinder. Interior Install the cylinder with cylinder spring as shown. Functions L/LV9050 L9465 L/LV9056 L9466 L/LV9060 L9473...
  • Page 210 L9000-Series 180 degree indicator installation instructions – escutcheon trim Connect the cam to the indicator slide. The cam must Install inside trim engage either the left or right side of the indicator slide DO NOT OVERTIGHTEN THE MOUNTING SCREWS according to door handing. • Unlock the door.
  • Page 211 L9000-Series 180 degree indicator installation instructions – escutcheon trim Tighten bushing with spanner wrench 13a Tighten cylinder mounting screw (if applicable). All functions 13b Tighten top and bottom chassis mounting screws. Chassis mounting Cylinder screws mounting screw Install inside cylinder (if applicable) Install armor front 12a Insert key halfway into the cylinder.
  • Page 212 L9000-Series 180 degree indicator installation instructions – escutcheon trim INDICATOR LOCK RETROFIT INSTRUCTIONS Inside Indicator Trim Outside Indicator Trim Inside trim options: Cylinder or thumb turn Outside trim options: Emergency turn, coin turn or cylinder Cylinder Emergency turn Coin turn Thumb turn Cylinder Remove armor front...
  • Page 213 Remove the inside escutcheon. the indicator trim. Complete installation of indicator trim Go to STEP 4 ON PAGE 2 and follow the instructions to complete the installation of the indicator trim. Customer Service 1-877-671-7011 www.allegion.com/us Schlage • L-Series service manual • 213...

  • Page 214: L9000-Series 180 Degree Indicator Installation Instructions - Sectional Trim

    L9000-Series 180 degree indicator installation instructions – sectional trim L9000-Series 180 degree indicator installation L9000 Lock with Indicator instructions – sectional trim L9000 Series Lock with Indicator Sectional Trim Installation Instructions Indicator trim is available for either the inside or outside of the door on allowable functions. Tools Non-indicator trim is furnished on the opposite side of the door.
  • Page 215 L9000-Series 180 degree indicator installation instructions – sectional trim Install outside mounting posts. Install lock chassis Note: Pilot holes for INDICATOR ONLY LV functions FULLY TIGHTEN MOUNTING POSTS ON SCREWS. Install outside lever All functions DO NOT FULLY TIGHTEN CHASSIS MOUNTING SCREWS. Install springs and spindles Exterior Install inside spring cage and mounting plate...
  • Page 216 L9000-Series 180 degree indicator installation instructions – sectional trim NON-INDICATOR TRIM ONLY Install inside lever and rose Install outside turn or cylinder All functions For INDICATOR outside trim, SKIP TO STEP 11 COIN TURN: 10a Insert coin turn into the door. Functions L/LV9044 L/LV9444...
  • Page 217 L9000-Series 180 degree indicator installation instructions – sectional trim 11d Connect the cam to the indicator slide. The cam must INDICATOR TRIM ONLY engage either the left or right side of the indicator slide Install outside INDICATOR with turn or cylinder according to door handing.
  • Page 218 L9000-Series 180 degree indicator installation instructions – sectional trim NON-INDICATOR TRIM ONLY CYLINDER: Install inside thumb turn or cylinder 11e Insert key halfway into the cylinder. For INDICATOR inside trim, SKIP TO STEP 13 11f Install the indicator faceplate and cylinder with cylinder spring as shown.
  • Page 219 L9000-Series 180 degree indicator installation instructions – sectional trim 13c Connect the cam to the indicator slide. The cam must INDICATOR TRIM ONLY engage either the left or right side of the indicator slide Install inside INDICATOR with thumbturn or cylinder according to door handing.
  • Page 220 L9000-Series 180 degree indicator installation instructions – sectional trim CYLINDER: 14a Tighten cylinder mounting screw, if applicable. 13d Insert key halfway into the cylinder. 14b Tighten top and bottom chassis mounting screws. 13e Install the indicator faceplate and cylinder with cylinder spring as shown.
  • Page 221 Make sure the door is prepared with any necessary holes for the indicator trim. Complete installation of indicator trim Go to STEP 11 ON PAGE 4 and follow the instructions to complete the installation of the indicator trim. Customer Service 1-877-671-7011 www.allegion.com/us Schlage • L-Series service manual • 221...

  • Page 222: L400-Series 180 Degree Indicator Installation Instructions

    L400-Series 180 degree indicator installation instructions L400-Series 180 degree indicator installation L400 Lock with Indicator instructions L400 Series Lock with Indicator Sectional Trim Installation Instructions Indicator trim is available for either the inside or outside of the door on allowable functions. Non-indicator trim is furnished on the opposite side of the door.
  • Page 223 L400-Series 180 degree indicator installation instructions NON-INDICATOR ONLY - Install outside cylinder INDICATOR ONLY – Install outside cylinder Install the indicator mounting plate. FOR INDICATOR, SKIP TO STEP 4. Secure the mounting plate with four (4) screws. L460 Note: Cylinder applications require only two (2) screws. L462 L464 Indicator...
  • Page 224 L400-Series 180 degree indicator installation instructions Connect the cam to the indicator slide. The cam must Rotate cylinder clockwise. engage either the left or right side of the indicator slide according to door handing. • Unlock the door. • Move the indicator slide against the top rim of the mounting plate (unlocked position).
  • Page 225 L400-Series 180 degree indicator installation instructions Connect the cam to the indicator slide. The cam must — OR — engage either the left or right side of the indicator slide THUMB TURN: according to door handing. • Unlock the door. Rotate 180°...
  • Page 226 L400-Series 180 degree indicator installation instructions Install armor front THUMB TURN: Install the indicator slide and indicator faceplate. Secure the indicator faceplate with two set screws. All functions For retrofit instructions, see page 6. Tighten cylinder mounting screw. Tighten top and bottom chassis mounting screws. Chassis Cylinder mounting...
  • Page 227 Complete installation of indicator trim Go to STEP 4 ON PAGE 2 and follow the instructions to complete the installation of the indicator trim. Customer Service © Allegion 2015 1-877-671-7011 www.allegion.com/us P516-911 Rev. 03/15-b Schlage • L-Series service manual • 227...

  • Page 228: L9000-Series Electrified Installation Instructions

    L9000-Series electrified installation instructions L9000-Series electrified installation instructions L-Series Electrified Locks L909X-Series Electrified Mortise Lock, WARNING LM929X-Series Electrified Two-Point Lock WARNINGS Warnings indicate potentially hazardous conditions, which if not Wiring Instructions and Specifications avoided or corrected, may cause death or serious injury. L-Series Electrified Lock All installations should be in accordance with local electrical codes and national electrical code, NFPA 70.
  • Page 229 (10-072 shown) Allegion Connect The L909X-Series and LM929X-Series electrified mortise locks are furnished with Allegion Connect, a factory-installed Molex® connector system that provides simplified installation and maintenance. The system utilizes quick-connect harnesses and hinges. As an alternative installation method, the Molex connector may be cut off and the lock installed with traditional wire splicing methods.
  • Page 230 230 • Schlage • L-Series service manual...
  • Page 232 About Allegion Allegion (NYSE: ALLE) creates peace of mind by pioneering safety and security. As a $2 billion provider of security solutions for homes and businesses, Allegion employs more than 7,800 people and sells products in more than 120 countries across the world.
