Summary of Contents for Allegion Milre MI-260S
- Page 1 MI-260S USER MANUAL Notice Please read this manual before installation and operation.
- Page 2 Product features Insatiability UP through Left / Right-handed automatic identification system function. With no separate disassembling work, both left and right-handed installments is convenient. Safety up for separable safe knob structure. Separable knob structure provided perfect security function when external trespassing occur using wire string.
- Page 3 Safety precautions Do not disassemble or alter the lock Assembling or disassembling the door lock may damage the product. Damages to the product caused by unauthorized persons may result in damages to your property. Please contact our customer service. If the product generates harmful gases and smoke Please remove the batteries immediately from the product, if you do not take this step immediately, the product may suffer server damage.
-
Page 4: Table Of Contents
Contents Before using Product features and components Name and function of each part How to replace batteries How to apply external power in the emergency Basic function How to use touch-pad and random security coding function How to register / change secret code How to register / delete card keys How to open from outdoor(by secret code, card , mute function How to lock the door from outdoor... -
Page 5: Product Features And Components
Ⅰ. Before using Product features and components ① ② ③ Installation ④ template Manual ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ Name Product specification Remark ① Front Ass`y 75mm(W) x 165mm(H) x 20mm(D) Working temperature : -15~55℃ ② Sensor operating temperature (high temperature): 60℃±10℃ Back Ass`y 73mm(W) x 165mm(H) x 41mm(D) ③... -
Page 6: Name And Function Of Each Part
Ⅰ. Before using Name and function of each part [Front Ass`y] [Back Ass`y] Name Description Lock /Unlock lamp 명칭 Indicate lock / unlock status 설명 Battery replacement When the battery is low, red lamp is flickering. indicator Please change batteries to new one. Touch type numeric pad Input secret code or touch card to open the door Card key touch plate... -
Page 7: How To Replace Batteries
Ⅰ. Before using How to replace battery lamp in RED 4 batteries If battery is flickering with sound, replace all to new one. (1.5V,"AA" size, LR6 alkaline) If battery lamp is flickering with sound Replace batteries in same position as like above picture. Note one year based on 10 times of uses a day. -
Page 8: How To Use Touch-Pad And Random Security Coding Function
Ⅱ. Basic function How to use touch-pad and random security coding function Random security coding function Press any number randomly without limitation and then enter your secret code at final. With this function, you can open the door without revealing your secret code to others. Touch the front pad Numeric buttons are displayed... -
Page 9: How To Register / Change Secret Code
Ⅱ. Basic function How to register / change secret code code ※ Please register/change with the door open. To register one secret code Open battery cover Press new secret code Press [ ] Press [ ] Complete and press [REG] (ie,123456) registration button shortly. -
Page 10: How To Register / Delete Card Keys
Ⅱ. Basic function How to register / delete card keys 1. How to register card key (Max 35 EA of card key can be registered.) Open battery cover and Touch the card key Complete registration press [REG] button shortly. one by one. by [ ] 2. -
Page 11: How To Open From Outdoor
Ⅱ. Basic function How to open from outdoor (by secret code, card , mute function) 1. Open the door using secret code 2. Open the door using card key Touch the front pad Enter secret code Press [ ] and door Touch the registered (ie, 123456) in unlocked... -
Page 12: How To Lock The Door From Outdoor
Ⅱ. Basic function How to lock the door from outdoor 1. Lock the door at auto - locking mode 2. Lock the door at manual - locking mode ※ Magnet must be installed to operate normally. At manual - locking mode, door is not locked automatically even though the door is closed. -
Page 13: How To Open Or Close With Thumb-Turn From Indoor(Manually)
Ⅱ. Basic function How to open or close with thumb-turn from indoor(manually) Turn to clockwise, Turn to counterclockwise, it will be unlocked it will be locked How to open or close with[Open/Close] button from indoor ※ When setting the [Open/Close] button auto stop function, the door sense magnet must be installed for normal operation. -
Page 14: How To Set / Cancel Auto Stop Function By [Open/Close] Button
Ⅱ. Basic function How to set / cancel auto stop function by [Open/Close] button When the door is open, [Open/Close] button moves to extend the dead bolt and damage the glass door. This feature prevents it from happening. Touch the front pad Press [ ] button Input secret code... -
Page 15: How To Set Outing Mode
Ⅱ. Basic function How to set outing mode 2. How to set outing mode (inside) 1. How to set outing mode (outside) Manual locking mode Touch the front pad, Press [#] button Remove the Thumb-turn Press [ ] button lighting pad for (separable) with 2 seconds. -
Page 16: How To Set / Stop Wanning Sound For Thumb-Turn
Ⅱ. Basic function How to set / stop wanning sound for thumb-turn(separable) Press [ ] button Touch the front pad Input secret code Touch the card key (ie, 123456) 1: [Set] Warning sound Press [ ] button 0: [Cancel] warning sound Alarm for 2 minutes after the Thumb-turn (separable) falls when door is closed... -
Page 17: Auto Lock
Ⅱ. Basic function Auto lock * Automatically locks when a magnet is detected in the sensor unit after setting the auto lock mode. Note · The sensor is not detected in the manual locked mode. · In the manual lock mode, you can lock it externally by pressing [0]. ·... -
Page 18: How To Set Double Locking Function
Ⅲ. Applications How to set double locking function Double lock mode, function of door is suspended and can not open the door from outside. ※ Please set this function after the door is closed. 1. Use double lock mode [Open/Close], [Double lock] button press 5 sec Beep ~↑... -
Page 19: How To Control Volume Level
Ⅲ. Applications How to control volume level Sound volume can be controlled by 8 levels. Touch the front pad Press [ Touch the car key Input secret code (ie, 123456) Press [ 2 : Volume down 3 : volume up... -
Page 20: Against Mischief Or Hacking
Ⅲ. Applications Against mischief or hacking If wrong secret code or unregistered card key is applied over 5 times, alarm system in activated with warning sound and all the function of door lock is suspended for a minute. How to release the suspended lock function Applying wrong... - Page 22 MEMO...
- Page 23 MEMO...
- Page 24 Rev 0.1 MILRE STSTEK CO., LTD http://www.milre.com...
