Project Timber Corner Shed Building Instructions page 2

*All Garden Buildings must be
built on level, flat base to be
erected correctly.
1. Fix the Corner Post
to Side Gable Panel
4
S50
Screws
1780mm
Screw Here
2. Fix the Floor Panels
together
7
S50
Screws
*Important* PILOT DRILL HOLES
BEFORE FIXING
2. Fix Floor together
Wall Panel Position
Corner post
Side
Side
Floor
Assembly
3. Fix the 2 Side Gable Panels
together and screw to the
floor assembly
4FT
3. Fix the two Side Gables
Panel in this position
S50
Screws
8
S50
Screws
3FT
4. Fix the additional
Side panels
Side Side
12
Front
Screws
S50
