1
2
WIRING LINKING BEACON & SOUNDER
FACTORY FITTED
A
Single Stage Configuration
Line Monitoring
Stage 1: Apply Power to Stage 1 +ve & Stage 1 -ve
B
C
D
Stage 1 +ve IN
Stage 1 +ve OUT
E
Stage 1 -ve IN
Stage 1 -ve OUT
F
DRAWING TO BS8888:2000
DRAWN
GEOMETRIC TOLERANCES TO ISO1101:1983
LINEAR DIMENSIONAL TOLS
R.S.RAIT
ANGULAR DIMENSIONAL TOLS
CHECKED
G
R.N.POTTS
STANDARDS
APPROVED
M RANGE
R.N.POTTS
3
4
OPTIONAL LINE MONITORING RESISTOR, CUSTOMER SUPPLIED,
RECOMMENDED MINIMUM VALUES:
14V MAX SYSTEM = 120Ω MIN, 2W MIN OR 1KΩ MIN, 0.5W MIN
28V MAX SYSTEM = 470Ω MIN, 2W MIN OR 2.4KΩ MIN, 0.5W MIN
Linked Sounder & Beacon Activation (Default)
Config.: 1a
S3
S2
-
-
+
+
+
-
+
+
-
-
SURFACE FINISH
WEIGHT (Kg)
DATE
05/03/2021
MATERIAL
DATE
05/03/2021
ALTERNATIVE MATERIAL
DATE
05/03/2021
5
6
SWITCHES FOR STAGE OPERATION
CUSTOMER SUPPLIED
Two/Three Stage Voltage Free Activation Configuration
Line Monitoring
Stage 1: Apply Power to Stage 1 +ve & Stage 1 -ve
Stage 2: Apply Power to Stage 1 +ve & Stage 1 -ve & connect Stage 2 to -ve/Common
Stage 3: Apply Power to Stage 1 +ve & Stage 1 -ve & connect Stage 3 to -ve/Common
Stage 1 +ve IN
Stage 1 +ve OUT
Stage 1 -ve OUT
Stage 1 -ve IN/COMMON
Stage 2 -ve
Stage 3 -ve
THIS DRAWING AND ANY INFORMATION OR DESCRIPTIVE
MATTER THEREIN IS COMMUNICATED IN CONFIDENCE AND
IS THE COPYRIGHT PROPERTY OF EUROPEAN SAFETY
SYSTEMS LTD. NEITHER THE WHOLE OR ANY EXTRACT MAY
BE DISCLOSED, LOANED, COPIED OR USED FOR
MANUFACTURING OR TENDERING PURPOSES WITHOUT THEIR
WRITTEN CONSENT.
EUROPEAN SAFETY SYSTEMS LTD.
AS PER LATEST DATE OF ISSUE SHOWN ABOVE
C
7
8
9
ISSUE
MOD No.
INTRODUCTION
A
RSR - 05/03/2021
S3
S2
-
-
+
+
+
-
+
+
-
-
S2
S3
ALL DIMENSIONS IN MM
2S
IF IN DOUBT, ASK -
DO NOT SCALE
warning signals
MC1LD2 DC COMBINED SOUNDER
TITLE
EUROPEAN SAFETY SYSTEMS LTD
XENON BEACON WIRING DIAGRAMS
IMPRESS HOUSE
MANSELL ROAD
ACTON
LONDON W3 7QH
DRAWING NUMBER
SCALE
SHEET
WWW.E2S.COM
NTS 1
2
OF
10
REASON - INITIAL - DATE
A
Config.: 1b
B
C
D
E
F
A3
G
D207-06-511
