Homestead
Entertainment Stand
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Top
1 pc.
E.
Base
1 pc.
F.
Plinth
1 pc.
J.
Door
1 pc.
Hardware List
Cam Lock Screw
Cam Lock
19 pcs.(+1 extra)
19 pcs.(+1 extra)
Tools required for assembly : Phillips screwdriver
B.
Side Panel
1 pc
.
G.
Leg
4 pcs.
K.
L.
Door
Shelf
1 pc.
1 pc.
Magnet
Wood Screw
2 pcs.
for Magnet
4 pcs.(+1 extra)
Casual Attire For Today's Home
C.
Side Panel
1 pc.
Middle Panel
1 pc
H.
Back Panel
2 pcs.
M.
Shelf
2 pcs.
Adjustable Pin
Machine Screw
12 pcs.(+1 extra)
2 pcs.(+1 extra)
D1.
D2.
Middle Panel
.
1 pc
.
I.
Back Panel
1 pc.
Pull Handle
2 pcs.
Advertisement
Table of Contents
Related Manuals for EefaCo.Store Home Styles 88 5527 09
Summary of Contents for EefaCo.Store Home Styles 88 5527 09
- Page 1 88 5527 09 Homestead Entertainment Stand IMPORTANT NOTE Carefully remove all the parts from the carton and put them individually on a soft cloth to prevent scratches or other damages occuring to the wood parts. We have taken great care in the design of this product and request that you carefully and strictly follow our assembly instructions to ensure a Casual Attire For Today's Home...
- Page 2 Assembly Instructions 2/4 IMPORTANT Do not tighten up all the screws until each part is properly assembled. Magnet Wood Screw STEP 1 Attach 2X Magnets to front rail of Top (A) with Wood Screws. Insert Cam Lock Screws into the pre-drilled holes of Top (A), Side Panel (B) and (C), Base (E), Plinth (F).
- Page 3 Assembly Instructions 3/4 Cam Lock Figure 1 Cam Lock Screw STEP 2 Attach Middle Panel (D1) and (D2) onto Base (E) with Cam Locks (see Figure 1). Cam Lock STEP 3 Attach Plinth (F) to the unit with Cam Locks. Attach Side Panel (B) and (C) to the unit with Cam Locks.
- Page 4 Assembly Instructions 4/4 Cam Lock Figure 2 Figure 3 STEP 4 Slide Back Panels (H) and (I) into place. Place Top (A) onto the unit, using Cam Locks. Attach Doors (J) and (K) by sliding the door lift hinges into the side panels lift hinges (See figure 2) Assemble Pull Handles to Doors (J) and (K) with Machine Screws.
