The Lafayette
Pier Unit
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
B.
Side Panel
1 pc
.
Hardware List
Hex Wrench
1 pc.
Head Cap Bolt
8 pcs. (+1extra)
For assembly see instructions in carton 88 5537 132
Tools required for assembly : Phillips screwdriver
C.
Side Panel
1 pc.
Cam Lock Screw
Wood Screw
18 pcs.(+1 extra)
for Back Panel
9 pcs.(+1 extra)
Cam Lock
18 pcs.(+1 extra)
Casual Attire For Today's Home
Steel Plate
for Pull Handle
Attachment
1 pc.
Wood Screw
for Hinge
Adjustable Pin
4 pcs.(+1 extra)
16 pcs.(+1 extra)
D.
Back Panel
1 pc.
Machine Screw
1 pc.
Nail
Pull Handle
1 pc.(+1 extra)
1 pc.
