88 5180 12
Art & Crafts
Center Console
x
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Top
1 pc.
F.
Front Stretcher
1 pc.
G.
Back Stretcher
2 pcs.
Shelf
2 pcs.
Hardware List
Key Wrench
Head Cap Bolt
1 pc.
(long)
8 pcs.(+1 extra)
Small
Cross Dowel
Hex Wrench
8 pcs. (+1 extra)
1 pc.
Tools required for assembly : Phillips screwdriver
K.
Shelf
1 pc.
L.
M1.
Leg
2 pcs.
Head Cap Bolt
4 pcs. (+1 extra)
Adjustable Pin
12 pcs. (+2 extra)
Casual Attire For Today's Home
B.
C.
Side Panel
Side Panel
1 pc.
1 pc.
I.
H.
Back Panel
Rail
2 pcs.
2 pcs.
N.
M2.
Base
Leg
1 pc.
1 pc.
Cam Lock
14 pcs.(+1 extra)
Cam Lock Screw
14 pcs.(+1 extra)
D.
Middle Panel
Middle Panel
1 pc.
J.
Back Panel
1 pc.
O.
Door
1 pc.
Wood Screw
12 pcs.(+1 extra)
Door
Machine Screw
Pull Handle
4 pcs.
2 pcs.
E.
1 pc.
P.
Door
1 pc.
