88 5531 31
The Bedford
Dining Table
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Top
1 pc.
C.
Leaf
1 pc.
E.
Table Slide
1 pc.
Hardware List
Key Wrench
1 pc.
Tools required for assembly : Phillips screwdriver
F.
Table Slide
1 pc.
Spring Washer
Flat Washer
20 pcs. (+1 extra )
20 pcs. (+1 extra )
Casual Attire For Today's Home
Bolt (long)
8 pcs. (+1 extra )
B.
Top
1 pc.
D.
Leg
4 pcs.
Bolt (short)
12 pcs. (+1 extra )
Advertisement
Related Manuals for EefaCo.Store 88 5531 31
Summary of Contents for EefaCo.Store 88 5531 31
- Page 1 88 5531 31 The Bedford Dining Table IMPORTANT NOTE Carefully remove all the parts from the carton and put them individually on a soft cloth to prevent scratches or other damages occuring to the wood parts. We have taken great care in the design of this...
- Page 2 Assembly Instructions 2/3 IMPORTANT * Do not tighten up all the screws until each part is properly assembled. * You should keep Key Wrench in the safe place as you may need to tighten up the Bolts in the future. (Figure 1) STEP 1 Attach Top (A) with (B), by aligning dowels...
- Page 3 Assembly Instructions 3/3 Adding the Leaf STEP 3 Disengage the locks by turning their handles counter-clockwise ¼ turn (see Figure 3). Pull out both sides of the table, then place Leaf (C) in the unit as shown, aligning the dowels with the holes. Push the table together firmly, then engage the locks by turning their handles clockwise ¼...
