Oak Hill
Side Chair
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Seat
1 pc.
Hardware List
Hex Wrench
1 pc.
Tools required for assembly : Phillips screwdriver
B.
Side Frame
1 pc.
D.
Front Frame
1 pc.
Small
Hex Wrench
Head Cap Bolt
1 pc.
8 pcs. (+1 extra)
C.
Side Frame
1 pc.
E.
Back Frame
1 pc
Spring Washer
Flat Washer
8 pcs. (+1 extra )
8 pcs. (+1 extra )
Wood Screw
4 pcs.(+1 extra)
