TMS-4 SPECIFICATIONS
TMS-4 receiver
Size (without connector)
Operating Voltage
Ambient Operating Current
Receiver frequency
Ingress Protection
Operating Temperature
Configuration
CAN Connection
TMS-4 Internal Sensors (HT-011600)
Battery Model
Battery lifespan
Standby Current
Pressure Measurement Range
Temperature Measurement Range
Ingress Protection
TMS-4 External Sensors (HT-011601)
Battery Model
Battery Lifespan
Standby Current
Pressure Measurement Range
Temperature Measurement Range
Ingress Protection
103.80 x 80.70 x 36.80mm
12V to 32V DC
50mA
433.92MHz + / - 50KHz
IP67
-40°C to +85°C (-40°F to 185°F)
via Haltech NSP or ESP Software
6-position TE MCON Connector
CR2023, 380mAh (Not Replaceable)
Up to 3 years
<0.7uA
0-800kpa (0-116psi)
-40°C to +125°C (-40°F to 257°F)
IP67
CR1632, 140mAh (Replaceable)
1-2 years
<0.7uA
0-800kpa (0-116psi)
-40°C to +125°C (-40°F to 257°F)
IP69
