Summary of Contents for Haltech TMS-4
- Page 1 TMS-4 QUICK START GUIDE...
- Page 2 • Plug’n’Play with Haltech ECUs using NSP or monitor tyre pressures through your Haltech ECU. ESP software packages The TMS-4 system is available in two kit forms, with • Receiver operating temperature: different tyre pressure sensors. These can be mounted -40°C to 85°C (-40°F to 185°F)
- Page 3 What’s in the box? What’s in the box? TMS-4 Internal Sensor Kit (HT-011600) TMS-4 External Sensor Kit (HT-011601) • Haltech TMS-4 receiver • Haltech TMS-4 receiver • TE MCON to DTM-4 CAN cable • TE MCON to DTM-4 CAN cable •...
-
Page 4: Receiver Installation
For best results installation location should be high in the vehicle. Connection The TMS-4 receiver connects via the supplied TE MCON to DTM-4 CAN Cable. Upon powering up an audible beep will be heard from the receiver to indicate it is on. - Page 5 6. Check for leaks with soapy water Enabling the TMS-4: NSP software In NEXUS series ECUs the receiver is enabled through Connections > CAN > Haltech CAN System: Tyre Monitoring (TMS-4 Enable). It should also appear in the menu tree once detected on the Haltech CAN Bus and enabled from there.
- Page 6 Channels The following data channels are available in both NSP and ESP software, as shown in this image TMS-4 channels can be searched for by using the keywords “tyre”, “tire”, and “wheel”. Channels displayed: • Per Tyre Pressure •...
- Page 7 DTC based on that flag. Users can also define their own pressure drop values in the TMS-4 setup menu. If a pressure drop of that Diagnostic Trouble Codes value (or greater) occurs over a 5 second period then the ECU flags an air leak.
- Page 8 These units have an average lifespan of 3 years, which is longer than the average life of a tyre. Low battery Voltage detection A DTC will be triggered if any sensor battery falls below 2.3V. Individual battery voltages can be monitored by the associated TMS-4 battery voltage channels.
-
Page 9: Receiver Wiring
TMS-4 WIRING CONNECTIONS Receiver wiring The Haltech TMS-4 receiver uses a 6-pin TE MCON wiring connector. Both kits are supplied with a plug’n’play TE MCON to DTM adaptor cable, terminated with a four-pin DTM-4 connector. CAN Connection: DTM-4 receptacle Pin Number... - Page 10 433.92MHz + / - 50KHz Ingress Protection IP67 Operating Temperature -40°C to +85°C (-40°F to 185°F) Configuration via Haltech NSP or ESP Software CAN Connection 6-position TE MCON Connector TMS-4 Internal Sensors (HT-011600) Battery Model CR2023, 380mAh (Not Replaceable) Battery lifespan...
-
Page 11: Warranty Certificate
Always disconnect the battery when doing electrical work on your vehicle. If the Haltech product is found to be defective as mentioned above, it will be Avoid sparks, open flames or use of electrical devices near flammable sub- replaced or repaired if returned prepaid along with proof of purchase. - Page 12 08/2020 Haltech Australia 17 Durian Place, Wetherill Park NSW 2164 Australia Phone: +61 2 9729 0999 Email: aus@haltech.com Haltech New Zealand Grey Lynn Auckland, NZ 1021 Phone: 09 887 0616 Email: nz@haltech.com Haltech USA East 750 Miles Point Way, Lexington, KY 40510 USA Phone: +1 888 298 8116 Email: usa@haltech.com...
