Changing Blades - Krone Comprima F 155 XC X-treme Original Operating Instructions

Maintenance
17.17

Changing Blades

DANGER! -Blades are Pre-tensioned With Spring Force!
Risk of injury when attaching or removing the blades.
• The blades should only be touched with suitable gloves
• Blades are assembled and disassembled from the bottom of the machine
• Always put down the machine on the secured support
The cutting system cutters are accessible from the bale chamber.
• Open tailgate
• Close the stop cock of the tailgate, see chapter Safety Equipment, "Stop cock tailgate".
CAUTION! - Damage to the machine!
• Always raise the pick-up before lowering the blade cassette.
Fig. 241
• Lower blade cassette (1) mechanically or hydraulically.
302
1
RPN00013_3
